  • Page 1 ® UPER 6113M-i UPER ERVER USER’S MANUAL...
  • Page 2 The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product. Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document.

  • Page 3: Preface

    About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 6113M-i. Installation and maintainance should be performed by experienced technicians only. The SuperServer 6113M-i is a high-end, dual Itanium2 processor rackmount server based on the SC813Hi-500 1U rackmount server chassis and the i2DMR- iG2 serverboard.
  • Page 4 UPER ERVER 6113M-i User's Manual Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the i2DMR-iG2 serverboard, including the locations and functions of connectors, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfiguring the serverboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 6113M-i User's Manual Preface About This Manual ... iii Manual Organization ... iii Chapter 1: Introduction to the SuperServer 6113M-i Overview ... 1-1 Serverboard Features ... 1-2 Server Chassis Features ... 1-5 Contacting Supermicro ... 1-7 Chapter 2: Server Installation Overview ...
  • Page 7 Chapter 4: System Safety Electrical Safety Precautions ... 4-1 General Safety Precautions ... 4-2 ESD Precautions ... 4-3 Operating Precautions ... 4-4 Chapter 5: Advanced Serverboard Setup Handling the i2DMR-iG2 Serverboard ... 5-1 Itanium2 Processor and Heatsink Installation ... 5-2 Connecting Cables ...
  • Page 8 UPER ERVER 6113M-i User's Manual Power Fault ... 5-22 SMB ... 5-22 SMB Power (I C) Connector ... 5-22 Jumper Settings ... 5-23 Explanation of Jumpers ... 5-23 CMOS Clear ... 5-23 VGA Enable/Disable ... 5-23 GLAN Enable/Disable ... 5-24 Watch Dog Enable/Disable ...
  • Page 9 Table of Contents Appendices: Appendix A: BIOS Error Beep Codes and Common Debug Codes ... A-1 Appendix B: BIOS POST Checkpoint Codes ... B-1 Appendix C: Software Drivers and Operating System Installation ... C-1 Appendix D: System Specifications ... D-1...
  • Page 10 UPER ERVER 6113M-i User's Manual Notes...

  • Page 11: Overview

    Overview The Supermicro SuperServer 6113M-i is a high-end dual processor, 1U rackmount server that features some of the most advanced technology currently available. The SuperServer 6113M-i is comprised of two main subsystems: the SC813Hi- 500 1U rackmount chassis and the i2DMR-iG2 dual Itanium2 processor serverboard.

  • Page 12: Serverboard Features

    SuperServer 6113M-i User's Manual Note: "(B)" indicates black. Serverboard Features At the heart of the SuperServer 6113M-i lies the i2DMR-iG2, a dual Intel Itanium2 processor serverboard designed to provide maximum performance. Below are the main features of the i2DMR-iG2. Chipset The i2DMR-iG2 is based on Intel's E8870 chipset, which is a high-performance chipset designed for high-end server platforms (see Figure 1-1).

  • Page 13: Pci Expansion Slots

    GHz with a 6 MB L3 cache at a 400 MHz FSB. Please refer to the support section of our web site for a complete listing of supported processors (http:// www.supermicro.com/TechSupport.htm). Memory The i2DMR-iG2 has eight 184-pin, DIMM slots that can support up to 16 GB of low-profile, registered ECC DDR200 (PC1600) SDRAM.

  • Page 14: Other Features

    UPER ERVER 6113M-i User's Manual Other Features Other onboard features are included to promote system health. These include various voltage monitors, two CPU temperature sensors, four fan speed sensors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU overheat sensors, virus protection and BIOS rescue.

  • Page 15: Server Chassis Features

    The following is a general outline of the main features of the SC813Hi chassis. System Power When configured as a SuperServer 6113M-i, the SC813Hi chassis includes a 500W cold-swap power supply. Control Panel The SC813Hi control panel provides important system monitoring and control information.

  • Page 16: Cooling System

    UPER ERVER 6113M-i User's Manual Cooling System The SC813Hi chassis' revolutionary cooling design has been optimized to provide sufficient cooling for dual Itanium2 configurations. The SC813Hi includes two heavy duty 10-cm blower fans located in the middle of the chassis. These fans operate continuously at full rpm.

  • Page 17: Contacting Supermicro

    Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 18 UPER ERVER 6113M-i User's Manual Notes...

  • Page 19: Chapter 2: Server Installation

    Unpacking the SuperServer 6113M-i You should inspect the box the SuperServer 6113M-i was shipped in and note if it was damaged in any way. If the server itself shows damage you should file a damage claim with the carrier who delivered it.

  • Page 20: Choosing A Setup Location

    UPER ERVER 6113M-i User's Manual Choosing a Setup Location - Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). - Leave approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.

  • Page 21: Installing The Server Into A Rack

    Each of these assemblies consists of two sections: an inner fixed chassis rail that secures to the 6113M-i (A) and an outer fixed rack rail that secures directly to the rack itself (B). A pair of short brackets to be used on the front side of the outer rails are also included.

  • Page 22: Installing The Outer Rails

    UPER ERVER 6113M-i User's Manual Installing the Outer Rails Begin by measuring the distance from the front rail to the rear rail of the rack. Attach a short bracket to the front side of the right outer rail and a long bracket to the rear side of the right outer rail.

  • Page 23: Installing The Server Into The Rack

    "click". Finish by inserting and tightening the thumbscrews that hold the front of the server to the rack. The front bezel (optional) may now be installed on the front of the chassis (available from Supermicro, p/n CSE-PTFB- 813 (B)).

  • Page 24: Installing The Server Into A Telco Rack

    ERVER 6113M-i User's Manual Installing the Server into a Telco Rack If you are installing the SuperServer 6113M-i into a Telco type rack, follow the directions given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.

  • Page 25: Checking The Serverboard Setup

    Checking the Serverboard Setup After you install the 6113M-i in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. 1. Accessing the inside of the 6113M-i (see Figure 2-5): First, release the retention screws that secure the unit to the rack.
  • Page 26 UPER ERVER 6113M-i User's Manual Figure 2-5. Accessing the Inside of the SuperServer 6113M-i 6. Check all cable connections and airflow: Make sure all power and data cables are properly connected and not blocking the chassis airflow. See Chapter 5 for details on cable connections. Also, check the air seals for damage.

  • Page 27: Checking The Drive Bay Setup

    Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the IDE drives have been properly installed and all connections have been made. 1. Accessing the drive bays: All drives are accessable from the front of the server. For servicing the CD- ROM and IDE drives, you will need to remove the top chassis cover.
  • Page 28 UPER ERVER 6113M-i User's Manual Notes 2-10...

  • Page 29: Chapter 3: System Interface

    Overview There are several LEDs on the chassis control panel to keep you constantly informed of the overall status of the system as well as the activity and health of specific components. There are also two buttons on the chassis control panel and an on/off switch on the power supply.

  • Page 30: Control Panel Leds

    NIC2 NIC2: Indicates network activity on GLAN2 when flashing . NIC1 NIC1: Indicates network activity on GLAN1 when flashing. HDD: Indicates IDE channel activity. On the SuperServer 6113M-i this light indicates IDE and/or CD-ROM drive activity when flashing.

  • Page 31: Chapter 4: System Safety

    Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6113M-i from damage: ! Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 32: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: ! Keep the area around the SuperServer 6113M-i clean and free of clutter. ! The SuperServer 6113M-i weighs approximately 45 lbs (20.5 kg) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.

  • Page 33: Esd Precautions

    ! After accessing the inside of the system, close the system back up and secure it to the rack unit with the retention screws after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.

  • Page 34: Operating Precautions

    UPER ERVER 6113M-i User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6113M- i is operating to ensure proper cooling. Out of warranty damage to the 6113M- i system can occur if this practice is not strictly followed.

  • Page 35: Chapter 5: Advanced Serverboard Setup

    Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the i2DMR-iG2 serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter. Remember to close the chassis completely when you have finished working on the serverboard to protect and cool the system sufficiently.

  • Page 36: Itanium2 Processor And Heatsink Installation

    CPU socket before you install the CPU heatsink. To optimize the functionality and capability of the i2DMR-iG2, we recommend it be installed in Supermicro chassis only. Warning: The heatsink on the MRH-D chip has been pre-installed by the manufacturer.
  • Page 37 Installing the Heatsink Retention Mechanism 1. Place the retention mechanism (SKT-0147-RM-IT2) on the serverboard as shown in the picture below: 2. Secure the retention mechanism to the serverboard by screwing three 6-32, 4.5-mm screws into the mounting holes on the back of the serverboard. (Rec- ommended torque: not to exceed 6 in-lbf.) Figure 5-1.
  • Page 38 Installing the Serverboard into the Chassis Note: To optimize the functionality and capability of the i2DMR-iG2, we strongly recommend that it be installed in Supermicro's SC813Hi-500W proprietary chassis. 1. Locate the six 6-32 9-mm screws (included in the retention mechanism shipping package).
  • Page 39 Chapter 5: Advanced Serverboard Setup Installing Itanium2 CPUs 1. Insert an Itanium2 CPU into the CPU1 socket. Make sure that CPU Pin 1 is aligned with the cut angle of the CPU socket, as shown in the picture below.* Itanium2 CPU CPU1 Socket 2.
  • Page 40 UPER ERVER 6113M-i User's Manual Installing the Power Pods The CPU power pod is a VRM mechanism specially designed for Itanium2 pro- cessors. 1. Locate the slot on the CPU power pod and align it with the Itanium2 CPU installed on the serverboard.
  • Page 41 Chapter 5: Advanced Serverboard Setup 3. Locate four of the M3 screws in the VRM-008 package and use them to secure the power pod onto the serverboard as shown in the picture below. (Recom- mended torque: not to exceed 2.5 in-lbf.) Securing the power pod with four M3 screws.
  • Page 42 To maximizing the cooling effect of the i2DMR-iG2, we strongly recommend that Supermicro's proprietary heatsinks (SNK-0046) be used with Itanium2 CPUs. 1. Place a heatsink (SNK-0046) on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism as shown in Figure 1 below.

  • Page 43: Connecting Ac Power

    Chapter 5: Advanced Serverboard Setup 3. Secure the heatsink onto the CPU by tightening all four screws. 4. Repeat the above steps to install a second heatsink on a second CPU if needed. Figure 5-3. CPUs with Heatsinks Installed Connecting AC Power 1.

  • Page 44: Connecting Cables

    UPER ERVER 6113M-i User's Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables.

  • Page 45: Connecting The Control Panel

    The U66 header contains pins for various buttons and indicators that are normally located on the chassis control panel. These connectors are designed specifi- cally for use with Supermicro server chassis. All U66 wires have been bundled into single ribbon cable to simplify their connection. The red wire should plug into pin 1 as marked on the serverboard.

  • Page 46: I/O Ports

    Figure 5-5 below for the locations of the various I/O ports. Figure 5-5. Back Panel I/O Ports Installing Memory Note: Check the Supermicro web site for recommended memory modules: http:// www.supermicro.com/TECHSUPPORT/FAQs/Memory_vendors.htm Exercise extreme care when installing or removing DIMM modules to prevent any possible damage.
  • Page 47 Memory Support The i2DMR-iG2 supports up to 16 GB of buffered, reistered ECC DDR200 (DDR266 memory can be used but will operate at DDR200 speed). serverboard was designed to support 2 GB modules in each socket. You should not mix DIMMs of different sizes and speeds. See Figures 5-6a and 5-6b for installing and removing memory modules.

  • Page 48: Adding Pci Cards

    UPER ERVER 6113M-i User's Manual Adding PCI Cards PCI slots: The i2DMR-iG2 has one 64-bit 133 MHz PCI-X slot for a full-length (standard) PCI card and one slim 64-bit 66 MHz PCI slot. The 64-bit 133 MHz PCI-X slot should have a riser card installed, which can accept a standard sized PCI card (see Figure 5-7).

  • Page 49: Serverboard Details

    Serverboard Details Figure 5-8. SUPER i2DMR-iG2 Layout Fan7 DIMM1 DIMM5 DIMM2 DIMM6 MRH-D DIMM3 DIMM7 DIMM4 DIMM8 J 3 8 COM2 MRH-D LAN1 PCI-X (256 Pin) LAN2 P64H 82546 BIOS4 BIOS3 Fan8 Notes: Jumpers not indicated are for test purposes only. "...

  • Page 50: I2Dmr-Ig2 Quick Reference

    UPER ERVER 6113M-i User's Manual i2DMR-iG2 Quick Reference Jumper Description Power Fail Alarm Enable/Disable Closed (Disabled) GLAN Enable/Disable Watch Dog JBT1 CMOS Clear VGA Enable/Disable Connector Fan1 - 8 J9 - J16* J30/J29 J37/J35 S1-6 * See Section 5-5 for details on installing memory...

  • Page 51: Connector Definitions

    Connector Definitions EPS 12V Power Connector There are two 24-pin main power sup- ply connectors on the serverboard. These power connectors meet the SSI EPS 12V specification. See the table on the right for pin definitions. (Only one of the two connections need to be made.) Processor Power Connectors...

  • Page 52: Hdd Led

    UPER ERVER 6113M-i User's Manual HDD LED The HDD LED connection is located on pins 13 and 14 of U66. Attach the hard drive LED cable here to display disk activity for any hard drives on the system. See the table on the right for pin definitions.

  • Page 53: Reset Button

    Reset Button The Reset Button connection is lo- cated on pins 3 and 4 of U66. Attach it the hardware reset switch on the computer case to these pins. Refer to the table on the right for pin defi- nitions. Power Button The Power Button connection is lo- cated on pins 1 and 2 of U66.

  • Page 54: Serial Ports

    UPER ERVER 6113M-i User's Manual Front Panel Universal Serial Bus Headers Two extra USB headers (USB4/ USB5 located at J21) can be used for front side USB access. You will need a USB cable to use either con- nection. Refer to the table on the right for pin definitions.

  • Page 55: Fan Headers

    Fan Headers The i2DMR-iG2 has eight fan head- ers, designated Fan1 through Fan8. See the table on the right for pin defi- nitions. Speaker Header The speaker header is located on CN4. See the table on the right for speaker pin definitions. Note: The speaker connector pins are for use with an external speaker.

  • Page 56: Power Fault

    UPER ERVER 6113M-i User's Manual Power Fault Connect a cable from your power supply to the U62 header to provide warning of power supply failure. This warning signal is passed through the PWR_LED pin on U66 to indicate a power failure on the chassis. See the table on the right for pin defini- tions.

  • Page 57: Jumper Settings

    Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.

  • Page 58: Glan Enable/Disable

    UPER ERVER 6113M-i User's Manual GLAN Enable/Disable Change the setting of jumper J7 to enable or disable the onboard GLAN ports (GLAN1 and GLAN2) on the serverboard. See the table on the right for jumper settings. The default setting is enabled...

  • Page 59: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup 5-10 Onboard Indicators GLAN LEDs Gb LAN Right LED Indicator Each of the Gigabit Ethernet LAN Color Definition ports (located beside the COM2 port No Connection on the back panel) has two LEDs. Green 100 Mb Orange 1 Gb The yellow LED indicates activity...

  • Page 60: 5-11 Ide Disk Drive Connections

    UPER ERVER 6113M-i User's Manual 5-11 IDE Disk Drive Connections When connecting the hard disk drive cables, please note that a red mark on a wire typically designates the location of pin 1. IDE Connectors There are no jumpers to con- figure the onboard IDE#1 and #2 connectors.

  • Page 61: Chapter 6: Advanced Chassis Setup

    Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC813Hi-500 chassis. For component installation, follow the steps in the order given to eliminate the most common problems encoun- tered. If some steps are unnecessary, skip ahead to the next step. Tools Required The only tool you will need to install components and perform maintenance is a Philips screwdriver.

  • Page 62: Control Panel

    UPER ERVER 6113M-i User's Manual CD-ROM Drive USB Ports Figure 6-1. Chassis: Front and Rear Views Control Panel The control panel (located on the front of the chassis) must be connected to the JF2 connector on the serverboard to provide you with system status indications.

  • Page 63: System Fans

    Two 10-cm blower fans and a high-speed 4-cm fan provide all the cooling needed for the SuperServer 6113M-i. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 64: Drive Bay Installation/Removal

    6-3). Carefully remove the bezel with both hands. A filter located within the bezel can be removed for replacement/cleaning. It is recommended that you keep a maintenance log of filter cleaning/replacement, since its condition will affect the airflow throughout the whole system. The front bezel is available from Supermicro: p/n CSE-PTFB-813 (B).

  • Page 65: Accessing The Drive Bays

    IDE Drives: For installing/removing the IDE drives, you will need to gain access to the inside of the 6113M-i by removing the top cover of the chassis. Proceed to the "IDE Drive Installation" section later in this chapter for instructions.

  • Page 66: Hard Drive Installation

    UPER ERVER 6113M-i User's Manual Hard Drive Installation Hard drive support: The SC813Hi-500 has four drive bays to accommodate IDE type hard disk drives. Hard drives should be mounted in drive carriers for installation, to help promote proper airflow and to shield against EMI. For this reason, even empty carriers without hard drives installed should remain in the chassis.

  • Page 67: Cd-Rom Drive Installation

    The top cover of the chassis must be opened to gain full access to the CD-ROM drive bay. The 6113M-i accomodates only slim CD-ROM drives. Side mounting brackets are needed to mount a slim CD-ROM drive in the 6113M-i server. You must power down the system before installing or removing a CD-ROM drive.

  • Page 68: Power Supply

    ERVER 6113M-i User's Manual Power Supply The SuperServer 6113M-i has a single 500 watt power supply, which is auto- switching capable. This enables it to automatically sense and operate with either a 100v or 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
  • Page 69 Chapter 6: Advanced Chassis Setup Figure 6-4. Removing/Replacing the Power Supply...
  • Page 70 UPER ERVER 6113M-i User's Manual Notes 6-10...

  • Page 71: Chapter 7: Bios

    (AMIBIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) When an option is selected in the left frame, it is highlighted in white.

  • Page 72: Main Bios Setup Screen

    UPER ERVER 6113M-i User's Manual Main Setup Screen When you first enter the BIOS Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen. The Main BIOS Setup screen is shown below.

  • Page 73: Advanced Setup

    Chapter 7: BIOS Advanced Setup Screen Selecting the Advanced tab takes you to the Advanced setup screen. The Advanced BIOS Setup screen and sub menus are listed below: When you first enter the Advanced Setup screen, the Setup Warning will be displayed.
  • Page 74 UPER ERVER 6113M-i User's Manual Serial Port1 Address/Serial Port2 Address This option specifies the base I/O port addresses and Interrupt Request addresses of Serial Port 1 and Serial Port2. Select "Disabled" to prevent the serial ports from accessing any system resources. When this option is set to Disabled, the serial ports become physically unavailable.
  • Page 75 Chapter 7: BIOS Primary IDE Master/Slave, Secondary IDE Master/Slave From the Advanced Setup screen, press <Enter> on the appropriate option to access primary and secondary IDE master and slave drives submenu. Use this screen to select options for the Primary and Secondary IDE drives. Use the up and down <Arrow>...
  • Page 76 UPER ERVER 6113M-i User's Manual DMA Mode Select the default setting of Auto to allow the BIOS to auto detect the DMA mode. Use this value if the IDE disk drive support cannot be determined. Other- wise, select from one of the following options: SWDMA0 (Single Word DMA mode 0, 2.1 MBs data transfer rate), SWDMA1 (Single Word DMA mode 1, 4.2 MBs...
  • Page 77 Chapter 7: BIOS ATA(PI) 80-Pin Cable Detection This feature allows the BIOS to auto-detect the 80-pin ATA(PI) Cable. The options are "Host & Device", "Host" and "Device." ! ! ! ! ! BIOS Settings Configuration This item allows the user to configure the system's boot settings. Quiet Boot Set this value to allow the boot up screen options to be modified between POST messages or OEM logo.

  • Page 78: System Health Monitor

    UPER ERVER 6113M-i User's Manual System Health Monitor This feature allows the BIOS to automatically display the status of the following items: CPU Overheat Temperature, CPU1/CPU2 Temperature, various voltage levels and fan speeds. See screen shot below.

  • Page 79: Peripheral Device Configuration

    Peripheral Device Configuration This screen allows the user to configure the Peripheral Device settings Power Loss Control This setting allows you to choose how the system will react when power is returned to the system after being unexpectedly lost. Options are "Stay Off", "Power On"...

  • Page 80: Usb Configuration

    UPER ERVER 6113M-i User's Manual USB Configuration This feature allows the user to configure the USB settings. USB Function Select "Enabled" to enable the USB Host Controller. The options are "Disabled" and "Enabled." Legacy USB Support Select "Enabled" to enable support for USB Legacy. The options are "Disabled"...

  • Page 81: 7-4 Pci/Pnp Configuration

    Chapter 7: BIOS 7-4 PCI/PnP Configuration This feature allows the user to set the PCI/PnP configuration. PCI Latency Timer This option sets the latency time for all PCI devices on the PCI bus. The default setting is "64." Select one of the following to set latency to the desired number of PCI clock cycles: "32", "64", "96", "128", "160", "192", "224"...

  • Page 82: Security Settings

    UPER ERVER 6113M-i User's Manual !Hardware Health Monitoring H/W Health Function Select "Enabled" to enable the Hardware Health Monitoring function. The options are "Enabled" and "Disabled". Overheat Temperature Trips This feature allows the user to set the CPU temperature threshold. The options range from "65...

  • Page 83: Exit Options

    Chapter 7: BIOS Change User Password Select this option and press <Enter> to access the submenu, then type in the password. Clear User Password Select this option and press <Enter> to access the submenu. You can use the sub menu to clear the user password. Exit Options Select the Exit tab from the BIOS Setup Utility screen to enter the Exit BIOS Setup screen.
  • Page 84 UPER ERVER 6113M-i User's Manual Load Optimal Defaults Select Load Optimal Defaults from the Exit menu and press <Enter> then "OK" to have BIOS automatically load all Optimal Defaults for the BIOS settings. The optimal settings are designed for maximum system performance, but may not work best for all computer applications.

  • Page 85: Appendix A: Bios Error Beep Codes And Common Debug Codes

    BIOS Error Beep Codes and Common Debug During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process. The error messages normally appear on the screen.
  • Page 86 UPER ERVER 6113M-i User's Manual A-2 IA-64 Common Debug Codes Common Debug Codes for IA-64 systems are listed below: Checkpoints Off: Off: Note: The debug code LEDs (DS3 and DS4) are located next to the IDE2 connector. Please refer to the serverboard layout in Chapter 5 for DS3 and DS4 locations.

  • Page 87: Appendix B: Bios Post Checkpoint Codes

    BIOS POST Checkpoint Codes When AMIBIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. Checkpoint Code Description The NMI is disabled.
  • Page 88 UPER ERVER 6113M-i User's Manual Checkpoint Code Description The NMI is disabled. Next, checking for a soft reset or a power on condition. The BIOS stack has been built. Next, disabling cache memory. Uncompressing the POST code next. Next, initializing the CPU and the CPU data area.
  • Page 89 Checkpoint Code Description The configuration required before interrupt vector initialization has completed. Interrupt vector initialization is about to begin. Interrupt vector initialization is done. Clearing the password if the POST DIAG switch is on. Any initialization before setting video mode will be done next. Initialization before setting the video mode is complete.
  • Page 90 UPER ERVER 6113M-i User's Manual Checkpoint Code Description The memory pattern has been written to extended memory. Writing patterns to the base 640 KB memory next. Patterns written in base memory. Determining the amount of memory below 1 MB next.
  • Page 91 Checkpoint Code Description The DMA page register test passed. Performing the DMA Controller 1 base register test next. The DMA controller 1 base register test passed. Performing the DMA controller 2 base register test next. The DMA controller 2 base register test passed. Programming DMA controllers 1 and 2 next.
  • Page 92 UPER ERVER 6113M-i User's Manual Checkpoint Code Description Initializing the bus option ROMs from C800 next. See the last page of this chapter for additional information. Initializing before passing control to the adaptor ROM at C800. Initialization before the C800 adaptor ROM gains control has com- pleted.

  • Page 93: Appendix C: Software Drivers And Operating System Installation

    After all the hardware has been installed, you will need to install the operating system and other software drivers. The necessary drivers are all included on the Supermicro CDs that came packaged with your system. Introduction to the EFI Platform...
  • Page 94 AMIBIOS Flash 1. Obtain a USB Pen or a USB storage device (a USB 2.0 device is recommended). 2. From our web site (www.supermicro.com), download the following two files into the USB pen or device: [amiflash.efi], and [bios.rom]. 3. Connect the USB device to one of the USB ports (see Chapter 5 for USB port locations).
  • Page 95 Location of the USB device (example) 6. At the shell command prompt, type: Shell> fsX: (where X is the number of the sector in which your USB pen or device is located). This command will change the directory from [Shell] to [fsX]. 7.
  • Page 96 UPER 6113M-i User's Manual 9. When the fsx directory appears, type in the file name at the prompt: fsx:\ amiflash ami64.rom (eg. in the example shown above, at the prompt type fs0:\> amiflash ami64.rom and press <Enter> as shown below).
  • Page 97 Appendix C: Software Installation After the BIOS Image file is loaded, the following screen will appear: 10. When "Reset NVRAM to default value? (y/n)" is displayed, type "y" at the prompt if you want to reset all default values after flashing the BIOS. (Yes: this will reset your NVRAM, which typically resets your boot options in EFI to the manufacturer defaults.
  • Page 98 UPER 6113M-i User's Manual Adding the CD-ROM Boot Option in EFI 1. Power on the system and enter the “EFI Boot Manager”. 2. Select “Boot Option Maintenance Menu." 3. Select “Add a Boot Option.” 4. Select “Removable Media Boot [Acpi(PNP0A03,0)/Pci(1F|1)/ ATA(Secondary,Master)]”.
  • Page 99 Appendix C: Software Installation IA64 OS Installation For installation on an IDE hard drive. (Note: The Itanium2 board does not have a floppy connector, so the user cannot install Windows driver through a floppy device. This procedure uses ramdisk to add the boot device driver in EFI so that Windows OS will automatically pick up driver from there.) 1.
  • Page 100 UPER 6113M-i User's Manual 11. At the Shell command prompt, type: "Shell> exit". This command will exit the EFI Shell and return to the EFI Boot Manager.” 12. Select the “CD-ROM” boot option to boot from a Windows OS installation CD after you have added the CD-ROM boot option in the EFI Boot Manager.

  • Page 101: Appendix D: System Specifications

    2 processors of up to 1.50 GHz with a 6 MB L3 cache at a front side (system) bus speed of 400 MHz Note: Please refer to the support section of our web site for a complete listing of supported processors. (http://www.supermicro.com/TechSupport.htm) Chipset Intel E8870 chipset BIOS ®...
  • Page 102 UPER ERVER 6113M-i User's Manual Weight Net (Bare Bone): 32 lbs. (14.5 kg.) Gross (Bare Bone): 42 lbs. (19.1 kg.) System Cooling Two (2) 10-cm blower fans and one (1) high-speed 4-cm fan System Input Requirements AC Input Voltage: 100-240V AC auto-range...
