6.5 Vantage RZ-4 Advanced Camera Specifications

Camera Specification
Signal Format
Video Output
Universal Power Source
Power Consumption
Operating Temperature
Operating Humidity
Dimensions
Weight
7

Maintenance

The Vantage Video Detection System, once correctly installed, requires a minimal amount of
maintenance.
Camera Cleaning
Because Vantage video detection is a machine vision based system, a regular maintenance program
should be implemented to ensure the front camera glass is kept free from dirt and debris. The camera
housing glass should be cleaned at least once a year, or more frequently if required, especially under
severe environmental conditions. Cleaning the glass ensures optimal performance.
The use of a soft cotton cloth (non‐abrasive) and water is the recommended method for camera glass
cleaning. Avoid leaving streaks on the glass. Avoid anything that might scratch the glass, cloud the glass,
or leave an undesirable residue.
Connector and Cable Inspection
Periodically, it is wise to check camera power and video connections. Look for connector corrosion or
moisture damage. Replace any defective connectors. Cabinet power and video cable and connections
can also be checked for excessive wear or other defects. Repair or replace the defective cable or
connectors as needed.
8

If You Need Assistance

The Iteris Vantage Product Support Team consists of a group of highly skilled individuals that are
knowledgeable and readily available to answer your questions or assist you with any of our Vantage
products. Please do not hesitate to contact us at:
(888) 254‐5487
For more information on Iteris and the products and services that we provide, visit our website at
www.iteris.com.
North America
NTSC
Composite 1V p‐p@75ohm
85‐265V, 50/60Hz
25 W Max
o o
‐31 F to +140 F
0% to 100% relative humidity, non‐condensing
Length 14.5", Diameter 5" (Tube Only)
5.7 lbs
