2: Components
38
Table 2-12 Base Unit Power LED
LED Power State
Unlit Off
Amber Auxiliary
Blinking Managed
Green Power
Steady Full
Green
The Power/Status LED on the system board indicates the system's operational status:
Table 2-13 System Board Power/Status LED
LED Status
Unlit Auxiliary power is off (fans are not running)
Bright System failure (fans are running)
Amber Auxiliary power is on
Green Full power is on
Explanation
Auxiliary power is off (fans are not running) or there is a system failure (fans
are running)
Auxiliary power is on; power consumption is reduced
The system is in an ACPI-compliant power conservation state managed by
the operating system; power consumption is reduced
Full power is on; power conservation is per device
