External Wide Ultra2 SCSI (LVDS)

007-4330-002
The external Wide Ultra2 SCSI (LVDS) port is a 68-pin female SCSI connector. Pins not
listed are connected to ground.
34
68
35 1
Figure 2-21 External Wide Ultra2 SCSI (LVDS) Port
Table 2-9 External Wide Ultra2 SCSI (LVDS) Port
Pin Signal Pin
17 TERMPWR 50
18 TERMPWR 52
35 SD-(12) 53
36 SD-(13) 54
37 SD-(14) 55
38 SD-(15) 56
39 SDP1- 57
Signal
Ground
TERMPWR
No connection
Ground
SATII-
Ground
SBSY-
I/O Port Connectors
31
