1: Overview
I/O ports
Expansion
sockets
6
Figure 1-2 calls out the system board's major components. More detailed information on
system board components is found in Chapter 2, "Components".
Processor Processor
socket socket
Figure 1-2 Major Components of the System Board
Power and data
Memory module
connectors
sockets
CMOS/Clock
battery
007-4330-002
