Ethernet Network; Figure 2-20 Ethenet Network Port; Table 2-8 Ethernet Network Port - Silicon Graphics Zx10 User Manual

2: Components

Ethernet Network

30
The Ethernet Network port is an 8-pin RJ45 connector.
1
8
Figure 2-20 Ethenet Network Port
Table 2-8 Ethernet Network Port
Pin Signal
1 Transmit (TD+)
2 Transmit (TD-)
3 Receive (RD+)
4 Reserved
Pin Signal
5 Reserved
6 Receive (RD-)
7 Reserved
8 Reserved
