Silicon Graphics Zx10 User Manual page 17

007-4330-002
Table 1-1 (continued)
Main Features Components
One PS/2 keyboard port (6-pin mini-DIN)
One parallel (LPT) port (25-pin D-sub)
Two serial (COM) ports (9-pin D-sub)
Two USB ports (self-identifying, hot-pluggable, 12 MB/sec)
One SCSI port (68-pin HD) – Ultra 3
One Ethernet port (8-pin RJ-45)
One each microphone in, line in, and line out audio ports (PC standard
1/8-inch phone jacks)
One MIDI/game port (15-pin D-sub)
Four ATAPI connectors (internal) – CD IN, VIDEO IN, MONO IN, MPEG
IN
BIOS Phoenix BIOS
Supports Advanced Configuration and Power Interface (ACPI)
Supports Desktop Management Interface (DMI)
Supports PC99
Supports S0, S1, S3, and S5 system states
Auto-configuration of IDE hard disk types
Form Factor Extended ATX (12 in x 13 in)
Two 20-pin ATX power connectors
Stacked input/output ports
Voltage and Power ATX power supply connectors
+12V variable power source for DC fans
3.3 V SDRAM memory support
System Monitoring of all system voltages and four temperature points
Management
Main Features and Components
Features and Components
3
