Hardware Monitoring and Power Management

007-4330-002
• 8-bit and 16-bit, mono and stereo recording and playback
• Sampling rates up to 48 kHz
• 16 MIDI channels
• Full-duplex operation
• Line in, line out, and microphone in jacks
• MIDI/game port
• ATAPI connectors for CD-ROM input, video input, and monaural audio (telephony)
input
• PCI bus interface
The system board features advanced hardware monitoring capabilities. These features
help save energy, prolong system life, and provide for functionality such as remote
system wakeup.
When used with the hardware monitoring software on a system, these features enable
you to monitor:
• Major system voltages, including +1.5 V, +2.5 V, +3.3 V, +3.3 V standby, +5 V, +5 V
standby, -5 V, +12 V, -12 V, processor (CPU) cores, and AGP input/output (I/O)
• Temperature of processor (CPU) cores, and ambient temperature near the
processors and in the chassis
• Presence and location of fans – front (Fan 1 and Fan 2) and rear (Fan 3 and Fan 4);
presence varies by system
• Chassis intrusion
The system board includes integrated temperature sensors. These sensors provide
signals for reporting temperature readout data and for controlling cooling fan speed.
The Power LED on the front of the system base unit indicates the system's normal power
states:
