Table 1-1 (continued)
Main Features Components
Fan headers with monitoring and control functions
Chassis intrusion alert header
Temperature and voltage monitoring
Wake-on-Modem header
Wake-on-LAN header
Regulatory FCC Class B (Declaration of Conformity)
Compliance
European Community CE (Declaration of Conformity)
Underwriter's Laboratories
Figure 1-1 on the following page shows the major system board components and
connections.
