Before installing the processor, please access Intel
detailed information http://www.intel.com .
3.1
Installing the Processor
NOTE
Before installing the CPU, make sure to turn off the
computer and unplug the power cord from the power
outlet to prevent damage to the CPU.
Introduction to LGA1156 CPU
The pin-pad side of LGA1156 CPU
Hardware Installation
IMB205 LGA775 ATX Motherboard User's Manual
HARDWARE INSTALLATION
®
The pin-pad side of LGA1156 CPU
CHAPTER 3
website for more
33
