USB Interface
Tweleve USB ports (four on the Rear I/O, eight ports by
2x5-pin 2.54 pin-header)
Onboard Graphics
®
Intel Clarkdale integrated Graphics Processing Unit
(GPU) processors which goes with Intel® Q57 chipset
with VGA,DisplayPort out(Note 2)
Memory Size -- Intel
Resolution -- VGA output up to a resolution of 2048x1536
pixels with 32-bit color at 75 Hz and DisplayPort output up
to 2560x 1600 at 60 Hz.
Output Interface -- VGA from DAC output via 15-pin D-Sub
connector and DisplayPort from DAC output via DisplayPort
connector on the Rear I/O
Ethernet
LAN1 – Intel
Base-T Gigabit Ethernet, RJ-45 connector on the Rear I/O,
with AMT6.0 supported with 5-pin 2.0 pitch wafer for LED
LAN2 -- Intel
Base-T Gigabit Ethernet, RJ-45 connector on the Rear I/O
with 5-pin 2.0 pitch wafer for LED
Serial ATA
Six Serial ATA-II ports (3 Gb/s performance) and SATARAID
0/1/5/10 by Intel® Q57
Audio
HD Audio codec Realtek ALC888 for Line/speaker-out &
MIC-in on the rear I/O triple deck connector, with LM1877
audio amplifier
Support Jack-Detection
Support CD In
Expansion Slot
1 x PCI Express2.0 x16 Slot
1 x PCI Express x4 Slot
2 x PCI Express x1 Slot
3 x PCI Slot (32bit/33MHz)
Introduction
IMB205 LGA1156 ATX Motherboard User's Manual
®
DVMT supported
®
WG82578DM PHY, supports 10/100/1000
®
WG82574L NIC, supports 10/100/1000
