AXIOMTEK IMB205 Product User Manual page 61

IMB205 LGA1156 ATX Motherboard User's Manual
IDE Configuration
You can use this screen to select options for the IDE Configuration,
and change the value of the selected option. A description of the
selected item appears on the right side of the screen. For items
marked with " ", please press <Enter> for more options.
SATA#1 IDE Configuration
Use this item to control the onboard SATA controller. Here
are the options for your selection, Compatible, Enhanced.
SATA#2 IDE Configuration
Use this item to control the onboard SATA controller. Here
are the options for your selection, Enhanced and Disabled.
Primary/Secondary IDE Master/Slave
Select one of the hard disk drives to configure IDE devices
installed in the system by pressing <Enter> for more
options.
54
AMI Bios Setup Utility
