1.1 About this Printer
The user-assessable components of the printer are shown below. Note that some items are optional
equipment.
Front Panel
Thumbwheel
Media Hub
Printhead Assembly
Media Flange
Printhead
Media Sensor
(optional AMS shown)
Printhead Latch
Platen
