4.2 Printhead

Removal:
1. Turn OFF and unplug the printer.
2. Completely loosen the Printhead Screw then carefully raise the Printhead Assembly and remove
the Printhead.
Note: If equipped with the Thermal Transfer option, it is not necessary to remove the Ribbon
Handler Assembly, as an opening in the assembly is provided for access.
Printhead
Assembly
3. Carefully disconnect the Printhead Cable from the Printhead.
4-2
rinthead
P
Screw
Removal and Replacement
