2.0 Introduction

This section covers maintenance and alignment procedures.

2.1 Maintenance

Recommended items, techniques, and schedules to keep the printer in top working order are detailed
below. The following items will help you safely and effectively maintain the printer:
Isopropyl alcohol
•
Cotton swabs
•
Clean, lint-free cloth
•
Soft-bristle brush
•
Soapy water/mild detergent
•
Compressed air
•
Printhead Cleaning Cards or Printhead Cleaning Film
•
For your safety and to avoid damaging the unit, always turn OFF the power switch
and unplug the AC power cord before servicing the printer.
Isopropyl alcohol is a flammable liquid -- take proper precautions when using this
CAUTION
solvent.
Component / Area
Printhead
Platen
Peel-Off Roller
Media Path / Media
Sensor / Peel Bar
Interior
Exterior Surfaces
Maintenance and Adjustments
Recommended Maintenance Schedule
Cleaning Interval
After every roll of
media.
After every roll of
media.
After every roll of
media.
As needed.
As needed.
As needed.
Method / Supplies
A cotton swab dampened with isopropyl alcohol
then wiped across the surface and, if necessary,
Printhead Cleaning Cards or Cleaning Film when
needed; see Section 2.1.1.
A cotton swab or cloth dampened with isopropyl
alcohol wiped across the roller, rotating as needed
to clean the entire surface; see Section 2.1.2.
Rotate the peel-off roller and clean it thoroughly
using isopropyl alcohol and a cotton swab.
Compressed air or a soft brush to remove all
debris, and isopropyl alcohol to remove adhesive
buildup; see Section 2.1.3.
Compressed air or a soft brush to remove all
debris.
A cloth dampened with mild detergent wiped
across the surface until clean.
2-1
