Printhead
Assembly
4. Latch the Printhead Assembly then lift the Print Mechanism out of the Bottom Enclosure, taking
care to guide the Cables through the Cutout.
Cutout
Cables
Removal and Replacement
Screws
Mechanism
Mechanism
Print
Bottom
Enclosure
Print
Bottom
Enclosure
4-5
