4.0 Introduction

This section details the removal and replacement of the printer parts.
Wear a wrist strap and follow standard ESD prevention measures.
Use extreme care near the Printhead; never use a sharp object on the surface.
CAUTION
Never use a sharp object on the Platen.
Note: The procedures below assume a printer empty of media and ribbon.

4.1 Cover

Removal:
1. Turn OFF and unplug the printer.
2. Open the cover then gently flex the side of the printer outward and remove the Cover from the
hinge.
Replacement:
1. Gently flex the side of the printer outward and then install the Cover onto the Hinge.
Removal and Replacement 4-1
