Page 1: Operating Instructions
CORDLESS HAMMER DRILL 20.4V OPERATING INSTRUCTIONS Always Wear Eye, Face & Ear Protection www.ozito.com.au... - Page 3 SPECIFICATIONS – MODEL NO. CDG-340HK Battery Power: 20.4V Charge Time: 1 Hour No Load Speed: 0-700 rpm Chuck: 10mm, Keyless Batteries: Features: Adjustable Torque State of Charge Indicator Magnetic Screw Strip Hammer Function Accessories Included This Cordless Drill has been designed to comply with the following Australian /...
- Page 4 Hammer Drill. We aim to provide quality tools at an affordable price. We hope you will enjoy using this tool for many years. Your Ozito Cordless Hammer Drill CDG-340HK has been designed to drill timber, metal, plastic, masonry and for screw driving. It is intended for DIY use only.
- Page 5 GENERAL 1. Keep work areas clean. Cluttered areas and benches can cause accidents. 2. Consider work area environment. Do not expose your tool to high humidity or rain. Do not use your tool in damp and wet conditions. Keep the work area well lit. Do not use your tool where there is a risk of causing fire or explosion, e.g.
- Page 6 Young children should be supervised to ensure that they do not play with this appliance. 22.Replacement of the supply cord. If the supply cord is damaged, it must be replaced by the manufacturer or an authorised Ozito Service Centre in order to avoid a hazard.
- Page 7 • Do not operate charger if it has received a sharp blow, been dropped or otherwise damaged in any way, take it to an authorised Ozito Service Agent. • Do not disassemble charger, take it to an authorised Ozito Service Agent when service or repair is required.
- Page 8 CHARGER AND BATTERY PACK SAFETY INSTRUCTIONS (cont.) • DO NOT store or use the tool and battery pack in locations where the temperature may reach or exceed 40ºC (such as outside sheds or metal buildings in summer). • The charger is designed to operate on standard household electrical power (240 volts).
-
Page 9: Charging Your Batteries
2. Check to see if receptacle is connected to a light switch which turns power off when you turn out the light. 3. If charging problems persist, take or send the tool, battery pack and charger to an authorised Ozito Service Agent. -
Page 10: Tool Operation
CHARGING YOUR BATTERIES (cont.) Battery The length of service from each charging will depend on the type of work you are doing. The batteries in this tool have been designed to provide maximum trouble free life. However, like all batteries, they will eventually wear out. - Page 11 TOOL OPERATION (cont.) Torque Settings (Tightening Power of Your Cordless Drill) When using your drill for various driving applications, it becomes necessary to increase and decrease the power and torque in order to prevent the possibility of damaging screw heads, threads, work piece, etc. In general, power and torque should correspond to the difficulty of the screw to be driven.
- Page 12 TOOL OPERATION (cont.) Magnetic Screw Strip Your cordless drill is designed with a magnetic screw strip to hold the screws you are using minimising the chance of losing or misplacing them. Keyless Chuck A keyless chuck has been provided with your drill to allow for easy installation and removal of bits.
-
Page 13: Maintenance And Care
• Store machine in a dry place. NOTE: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the Drill by an unauthorised person, or mishandling or mistreatment of the tool. This tool is designed for DIY use – use in... - Page 14 1 X CDG-340K Cordless Drill 15 X Accessories 2 X 20.4V Batteries 1 X Instruction Manual 1 X 1 Hour Charger OZITO INDUSTRIES PTY LTD AUSTRALIA (Head Office) 5 Chestnut Crt, Dingley, Victoria, Australia, 3172 Telephone: 03 9558 3999 Facsimile: 03 9558 0583 www.ozito.com.au...
-
Page 16: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 3 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 36 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
