Ozito OZSHD1050WA Instruction Manual

Spade handle drill 1050w
Hide thumbs Also See for OZSHD1050WA:

Advertisement

Quick Links

See also: Operating Manual
Spade Handle Drill
1050W
Instruction Manual
3 Year Replacement Warranty
OZSHD1050WA
! !
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
0212
www.ozito.com.au
To view the full range visit:

Advertisement

loading
Need help?

Need help?

Do you have a question about the OZSHD1050WA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ozito OZSHD1050WA

Summary of Contents for Ozito OZSHD1050WA

  • Page 1 1050W Instruction Manual 3 Year Replacement Warranty OZSHD1050WA WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.

  • Page 2: Specifications

    SPECIFICATIONS - MODEL NO. OZSHD1050WA Motor: 1050W Input: 230-240V~ 50Hz No load speed: 0 - 550 /min Max. torque: 119 Nm Net weight: 3.7kg Drilling capacities: Steel 13mm Timber 50mm KNOW YOUR PRODUCT 1. Keyed Chuck (13mm) 6. Rear Spade Handle (with soft grip) 2.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS………………………………………… Page 2 TABLE OF CONTENTS………………………………….. Page 3 INTRODUCTION………………………………………... Page 4 SAFETY INSTRUCTIONS……………………………….. Page 4 OPERATION …………………………………………….. Page 8 MAINTENANCE …………….………………………….. Page 11 CONTENTS ……………………………………………... Page 12 WARRANTY……………………………………………… Page 13...

  • Page 4: Introduction

    The electric motor has been designed for 230 - 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
  • Page 5 General Power Tool Safety Warnings WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in all of the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 6 General Power Tool Safety Warnings d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
  • Page 7 Drill Safety Warnings Wear ear protectors when impact drilling. Exposure to noise can • cause hearing loss. Use auxiliary handle(s), if supplied with the tool. Loss of control can • cause personal injury. Hold power tool by insulated gripping surfaces, when performing •...

  • Page 8: Operation

    OPERATION WARNING! Always turn off the tool and disconnect from the power supply prior to change any accessories or making any handle adjustments. Side Handle The 3 position side handle (3) will provide additional control, support and guidance when using the tool. The side handle (3) can be assembled to the left, top or right side of the metal gear casing.
  • Page 9 This feature is intended for use when the drill has been mounted in a drill stand or otherwise firmly held, not by hand (drill stand not manufactured by Ozito). Avoid locking the On/off trigger switch (7) 'ON' when drilling by hand so that you can always instantly release the On/off trigger switch (7) should the bit bind in the hole.
  • Page 10 OPERATION (cont.) Variable Speed Dial The On/off trigger switch (7) has a variable speed dial (8). By rotating the variable speed dial (8) you are able to limit the maximum speed of the drill. See the variable speed dial (8) for the direction of which to rotate for higher or lower speeds.

  • Page 11: Maintenance

    Agent for quick and low cost replacement. Always replace both brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the tool by an unauthorised person or by mishandling of the tool.

  • Page 12: Contents

    Reuse of recycled material decreases pollution in the environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice. CONTENTS 1 x Spade Handle Drill OZSHD1050WA 1 x Spade handle 1 x Auger bit 1 x Chuck key...

  • Page 13: Warranty

    If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations. • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175...
