- Page 1 Hammer Drill 1050W Operation Manual 3 Year Replacement Warranty OZHD1050WA 0112 www.ozito.com.au To view the entire range visit:...
-
Page 2: Specifications
SPECIFICATIONS – MODEL NO. OZHD1050WA Motor size: 1050 Watt Input: 230V ~ 50 Hz Chuck size: 13mm (1/2”) Keyed No load speed: 0 – 1,000 / 0 – 3,000/min Impact rate: 0 – 16,500 / 0 – 45,000bpm Weight: 3.35kg... -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS…………………………………………. Page 2 INTRODUCTION…………………………………………. Page 4 SAFETY INSTRUCTIONS………………………………... Page 4 OPERATION ……………………………………………… Page 7 MAINTENANCE …………….…………………………… Page 9 DESCRIPTION OF SYMBOLS………………………..Page 10 CARING FOR THE ENVIRONMENT…………………… Page 10 CONTENTS ………………………………………………. Page 10 WARRANTY……………………………………………….. Page 11... -
Page 4: Introduction
The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. - Page 5 GENERAL SAFETY Warning! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “Power Tool” in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. SAVE THESE INSTRUCTIONS 1) WORK AREA a) Keep work area clean and well lit.
- Page 6 GENERAL SAFETY (cont.) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
-
Page 7: Operation
ADDITIONAL SAFETY INSTRUCTIONS FOR HAMMER DRILLS Before drilling into walls, ceilings etc, ensure that there are no concealed power cables or pipes in the cavity. Always use the side handle. This gives you greater control if the drill accessory should become jammed. - Page 8 OPERATION (cont.) Chuck Inserting Bits Open the jaws slightly larger than the bit you are inserting. Insert the drill bit up to the flutes making sure it is centred in the jaws. Tighten the chuck by turning the chuck sleeve. Once the jaws have clamped evenly around the drill bit, use the key provided to tighten the chuck fully.
-
Page 9: Maintenance
No user serviceable parts. For all exchange of parts or repairs contact the manufacturer or service agent. Note: Ozito Industries will not be responsible for any damage or injuries caused by repairing of the hammer drill by an unauthorised person or by mishandling of the tool. -
Page 10: Description Of Symbols
Reuse of recycled material decreases pollution in the environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice. CONTENTS 1 x Hammer Drill OZHD1050WA 1 x Chuck Key 1 x Side Handle 1 x Operating Instructions... -
Page 11: Warranty
If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations. • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175...
