CORDLESS
DRILL
DRIVER
12V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
12V
Chuck Size:
10mm Keyless
No Load Speed:
0-700/min
Torque Setting:
17
Max. Torque:
10Nm
Battery:
1.5Ah Li-ion
Charge Time:
3-5 Hours
Weight:
0.94 kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Drill Driver
Charging Adaptor
CDL-1200
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito CDL-1200
Summary of Contents for Ozito CDL-1200
- Page 1 CORDLESS DRILL DRIVER Cordless Drill Driver 12V Lithium Ion INSTRUCTION MANUAL SPECIFICATIONS Charging Adaptor Input: Chuck Size: 10mm Keyless No Load Speed: 0-700/min Torque Setting: Max. Torque: 10Nm Battery: 1.5Ah Li-ion Charge Time: 3-5 Hours Weight: 0.94 kg ozito.com.au CDL-1200...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS DRILL DRIVER 1. BATTERY 1 Keyless Chuck 5 Forward/ Reverse Lever 2 Torque Adjustment Collar 6 Charging Socket WARNING! THE POWER SUPPLY FOR THIS CHARGER SHOULD BE PROTECTED BY A RESIDUAL CURRENT 3 LED Light 7 Sure Grip Handle DEVICE (RATED AT 30MA OR LESS).
- Page 3 OPERATION 2. KEYLESS CHUCK 3. CONTROLS Forward/ Reverse Lever WARNING: ENSURE THE TOOL IS TURNED OFF AND 1 For forward rotation, push the fwd/rev lever towards the left side of DISCONNECTED FROM THE POWER SUPPLY BEFORE the drill. For reverse rotation push fwd/rev lever to the right. PERFORMING ANY OF THE FOLLOWING OPERATIONS.
- Page 4 Do not force the drill or apply side pressure to elongate the hole. Let the drill do all the work. When drilling metals, use light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase drilling action. CDL-1200...
- Page 5 Blow out the ventilation slots with compressed air periodically . Ensure the battery is properly charged. It will take 4-5 charging cycles Note: Ozito Industries will not be responsible for any damage or before the battery reaches optimum charge and run time.
- Page 6 Model No. CDL-1200 How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any further questions, please contact Ozito Customer Service on: Australia: 1800 069 486 New Zealand: 0508 069 486...
- Page 7 ELECTRICAL SAFETY WARNING! The power supply for this product should be protected by a residual current device (rated at 30mA or less). A When using mains-powered tools, basic safety precautions, including the residual current device reduces the risk of electric shock. following, should always be followed to reduce risk of fire, electric shock, personal injury and material damage.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0715...
