CORDLESS
DRILL
DRIVER
18V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
18V
Chuck Size:
10mm Keyless
No Load Speed:
0-550/min
Torque Setting:
21
Max. Torque:
16Nm
Battery Power:
1.5Ah Lithium Ion
Charge time:
1 Hour
Weight:
0.9kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Drill Driver
18V Battery x2
Charging Adaptor
Charging Cradle
CDL-7100
Advertisement
Table of Contents
Related Manuals for Ozito CDL-7100
Summary of Contents for Ozito CDL-7100
- Page 1 18V Lithium Ion INSTRUCTION MANUAL 18V Battery x2 SPECIFICATIONS Input: Chuck Size: 10mm Keyless No Load Speed: 0-550/min Torque Setting: Max. Torque: 16Nm Battery Power: 1.5Ah Lithium Ion Charge time: 1 Hour Charging Adaptor Weight: 0.9kg ozito.com.au Charging Cradle CDL-7100...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS DRILL DRIVER 1. BATTERY 1 Keyless Chuck 5 Battery Release Button 2 Torque Adjustment Collar 6 Battery 18V WARNING! THE POWER SUPPLY FOR THIS CHARGER 3 LED Light 7 Forward/ Reverse Lever SHOULD BE PROTECTED BY A RESIDUAL CURRENT DEVICE (RATED AT 30MA OR LESS).
- Page 3 OPERATION 2. KEYLESS CHUCK 3. CONTROLS WARNING! Ensure the tool is turned off & disconnected from the power supply before performing any of the following operations. Forward/ Reverse Lever Installing a Drill Bit 1 For forward rotation, push the fwd/rev lever towards the left side of the drill.
- Page 4 Let the drill do all the work. slipping off centre as you start the hole. When drilling metals, use light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase drilling action. CDL-7100...
- Page 5 Variable speed trigger is locked Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the drill by an unauthorised person or by Ensure that the forward / reverse lever is in the correct position; pressed mishandling.
- Page 6 Tool:18V Cordless Drill Driver SPARE PARTS Model No. CDL-7100 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. 18V Li-ion Battery Pack...
- Page 7 ELECTRICAL SAFETY WARNING! The power supply for this product should be protected by a residual current device (rated at 30mA or less). A When using mains-powered tools, basic safety precautions, including the residual current device reduces the risk of electric shock. following, should always be followed to reduce risk of fire, electric shock, personal injury and material damage.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0514...
