Page 1: Operating Instructions
CORDLESS DRILL KIT 14.4V OZCD144V1BK OPERATING INSTRUCTIONS w w w. o z i t o . c o m . a u To view our entire range visit... -
Page 2: Specifications
SPECIFICATIONS – MODEL NO. OZCD144V1BK Battery power: 14.4V Charge time: 3 - 5 hours No load speed: 0 – 550 rpm Chuck: 10mm, keyless Batteries: Weight with 1 battery: 1.6kg Features: Adjustable torque 20 torque settings Accessories included 10. Battery power indicator 1. -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ……………………………………….. Page 2 TABLE OF CONTENTS………………………………….. Page 3 INTRODUCTION………………………………………… Page 4 SAFETY INSTRUCTIONS……………………………….. Page 4 OPERATION …………………………………………….. Page 9 MAINTENANCE …………….………………………….. Page 11 CONTENTS ……………………………………………... Page 11 WARRANTY……………………………………………… Page 13... -
Page 4: Introduction
We aim to provide quality tools at an affordable price. We hope you will enjoy using this tool for many years. Your Ozito Cordless Drill OZCD144V1BK has been designed to drill timber, metal, plastic and for screw driving. It is intended for DIY use only. - Page 5 GENERAL (cont.) 5. Head protection. Always use safety glasses. Use a face or dust mask whenever the operations may produce dust or flying particles. Wear ear protection whenever the sound level seems uncomfortable. 6. Guard against electric shock. Prevent body contact with earthed or grounded surfaces (e.g.
- Page 6 GENERAL (cont.) 17. Do not abuse the cord. Never carry the tool by its cord or pull it to disconnect from the socket. Keep the cord away from heat, oil and sharp edges. 18. Store idle tools. When not in use, tools should be stored in a dry, locked up or high place, out of reach of children.
- Page 7 CHARGER AND BATTERY PACK SAFETY INSTRUCTIONS (cont.) • An extension cord should not be used unless absolutely necessary. Use of an improper extension cord could result in the risk of fire, electric shock or electrocution. • Do not operate charger if it has received a sharp blow, been dropped or otherwise damaged in any way.
- Page 8 CHARGING YOUR BATTERIES This tool has been shipped in a low charge condition. You should charge it prior to use. • Plug the charger into a 240V power outlet. Connect the charger jack to the charger cradle socket. • With the battery sitting flat on a bench/table, slide the charging cradle into the recess of the battery terminals ensuring a firm connection.
-
Page 9: Operation
CHARGING YOUR BATTERIES (cont.) • Never store batteries in a discharged condition. Recharge them immediately after they are discharged. • All batteries gradually lose their charge. The higher the temperature the quicker they lose their charge. If you store your tool for long periods of time without using it, recharge the batteries every month or two. - Page 10 TOOL OPERATION (cont.) Keyless Chuck A keyless chuck (1) has been provided with your drill to allow for easy installation and removal of bits. The chuck is divided into two parts, the rear is called the collar and the front is the body. To open and close the keyless chuck (1) grasp and hold the collar of the chuck with one hand and rotate the chuck body with your other hand.
-
Page 11: Maintenance
• Blow out the ventilation slots with compressed air periodically . Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the sander by an unauthorised person or by mishandling of the tool. CARING FOR THE ENVIRONMENT... - Page 12 OZITO INDUSTRIES PTY LTD AUSTRALIA (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175 Telephone:1800 069 486 Website: www.ozito.com.au Email: enquiries@ozito.com.au...
-
Page 13: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 3 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 36 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
