- Page 1 Hammer Drill 1100W Operation Manual 3 Year Replacement Warranty OZHD1100WA 0209 www.ozito.com.au To view the entire range visit:...
-
Page 2: Specifications - Model No. Ozhd1100Wa
SPECIFICATIONS – MODEL NO. OZHD1100WA Motor Size: 1100W Input: 230V ~ 50 Hz Chuck Size: 13mm (1/2”) Keyed No Load Speed: 0 – 2,800 /min Impact rate: 44,800 bpm Net Weight: 2.5kg Drilling Capacity: Timber 25mm Steel 13mm Masonry 13mm... -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS - MODEL NO. OZHD1100WA ……. Page 2 TABLE OF CONTENTS…………………………………... Page 3 INTRODUCTION…………………………………………. Page 4 SAFETY INSTRUCTIONS………………………………... Page 4 OPERATION ……………………………………………… Page 7 MAINTENANCE …………….…………………………… Page 9 CONTENTS ………………………………………………. Page 10 WARRANTY……………………………………………….. Page 11... -
Page 4: Introduction
The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. - Page 5 GENERAL Warning! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “Power Tool” in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. SAVE THESE INSTRUCTIONS 1) WORK AREA a) Keep work area clean and well lit.
- Page 6 GENERAL (cont.) e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
-
Page 7: Operation
ADDITIONAL SAFETY INSTRUCTIONS FOR HAMMER DRILLS Before drilling into walls, ceilings etc, ensure that there are no concealed power cables or pipes in the cavity. Always use the side handle. This gives you greater control if the drill accessory should become jammed. - Page 8 OPERATION (cont.) Chuck Inserting Bits Open the jaws slightly larger than the bit you are inserting. Insert the drill bit up to the flutes making sure it is centred in the jaws. Tighten the chuck by turning the chuck sleeve. Once the jaws have clamped evenly around the drill bit, use the key provided to tighten the chuck fully.
-
Page 9: Maintenance
No user serviceable parts. For all exchange of parts or repairs contact the manufacturer or service agent. Note: Ozito Industries will not be responsible for any damage or injuries caused by repairing of the hammer drill by an unauthorised person or by mishandling of the tool. -
Page 10: Contents
LABELS ON YOUR TOOL CONTENTS 1 x Hammer Drill OZHD1100WA 1 x Chuck Key 1 x Side Handle 1 x Instruction Manual 1 x Depth Rod OZITO INDUSTRIES PTY LTD AUSTRALIA (Head Office) 1-23 Letcon Drive, Bangholme Victoria, Australia, 3175... -
Page 11: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 3 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 36 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
