Ozito LHD-7100 Instruction Manual

18v li-ion cordless hammer drill
Hide thumbs

Advertisement

Table of Contents

CORDLESS
HAMMER
DRILL
18V Li-ion
INSTRUCTION MANUAL

SPECIFICATIONS

Input:
18V
Chuck Size:
13mm Keyless
No Load Speed:
0-350 / 0-1,200 /min
Impacts:
0-5,600 / 0-17,000bpm
Torque Setting:
19
Max. Torque:
30Nm
Drilling Capacity:
Timber 25mm
Steel 10mm
Masonry 10mm
Battery:
1.3Ah Lithium Ion
Charge time:
3 - 5 Hours
Weight with Battery:
1.65kg
ozito.com.au
WHAT'S IN THE BOX
Hammer Drill
2 x 18V Battery
Drill Bits x 9
50mm Screwdriver Bit
Charging Adaptor
Charging Cradle
LHD-7100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LHD-7100 and is the answer not in the manual?

Questions and answers

Ken
February 8, 2025

Drill will not stop hammering

0

Related Manuals for Ozito LHD-7100

Summary of Contents for Ozito LHD-7100

  • Page 1: Specifications

    Impacts: 0-5,600 / 0-17,000bpm 50mm Screwdriver Bit Torque Setting: Max. Torque: 30Nm Drilling Capacity: Timber 25mm Steel 10mm Masonry 10mm Battery: 1.3Ah Lithium Ion Charge time: 3 - 5 Hours Charging Adaptor Weight with Battery: 1.65kg ozito.com.au Charging Cradle LHD-7100...

  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION HAMMER DRILL 1. BATTERY 1 Keyless Chuck 5 Forward/Reverse Lever 2 Torque Adjustment Collar 6 Battery 18V This charger is recommended for use with a residual current device with a rated residual current of 30mA or less. 3 LED Light 7 Battery Release Button 4 Variable Speed Trigger...

  • Page 3: Operation

    OPERATION 2. CHUCK 3. CONTROLS Keyless Chuck Forward/Reverse Lever 1. To set the drill to forward rotation, move fwd/rev lever to the Caution: Do not handle drill bits or other accessories without gloves as they are sharp and can become hot after use, potentially right.
  • Page 4 6. Move the drill bit into the workpiece. 3. Repeat until you reach the correct setting/ screw depth. Use this setting for the remaining screws. Note: Do not force the drill or apply side pressure to elongate the hole. Let the drill do the work. LHD-7100...

  • Page 5: Maintenance

    5 hours of charging. Subsequent charging only requires 3-5 hours. Note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the drill by an unauthorised person Variable speed trigger is locked or by mishandling.
  • Page 6 Tool: 18V Li-ion Hammer Drill SPARE PARTS Model No. LHD-7100 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. 16 18V Li-ion Battery SPLCD5000-16 Charging Cradle &...

  • Page 7: Electrical Safety

    Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.

  • Page 8: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0113...
