Lexmark C540n Service Manual page 53

Service error messages (1xx, 9xx) (continued)
Error code Description
150.05 Service Lost lock for motor.
Black/ITU cartridge
Motor
150.06 Service Excessive SAP BLDC PWM.
Black/ITU cartridge
Motor
150.07 Service Motor stalled in time-based
Black/ITU cartridge commutation.
Motor
152.xx Service
CMY Cartridge Motor
152.01 Service Failed to achieve lock for motor within
CMY Cartridge Motor allotted time.
152.02 Service Timeout waiting for SAP BLDC motor
CMY Cartridge Motor to reach valid FG speed.
152.03 Service Timeout waiting for
CMY Cartridge Motor MP_NUM_INITIAL_SAP_HALLS.
152.04 Service Timeout waiting for SAP BLDC motor
CMY Cartridge Motor FG.
152.05 Service Lost lock for motor.
CMY Cartridge Motor
152.06 Service Excessive SAP BLDC PWM.
CMY Cartridge Motor
152.07 Service Motor stalled in time-based
CMY Cartridge Motor commutation.
900.xx Service Unrecoverable RIP software error/
RIP Software illegal trap.
902.xx Service A general engine software error.
Engine Software
903.xx Service A general engine software error.
Engine Software
904.xx Service A general engine software error.
Engine Software
905.xx Service A general engine software error.
Engine Software
906.xx Service A general engine software error.
Engine Software
907.xx Service A general engine software error.
Engine Software
908.01 Service Board level was not obtained.
Engine Software
908.02 Service Timeout waiting for bullet serial data to
Engine Software be updated.
Action
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"Main drive gear assembly (EP
drive) service check" on page
Go to
"900.xx—System software error"
on page 2-22.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Go to
"90x.xx error (902.xx–907.xx)" on
page 2-24.
Diagnostic information
5025-2xx, 4xx
Previous
2-33.
Next
2-33.
Go Back
2-33.
2-33.
2-33.
2-33.
2-33.
2-33.
2-33.
2-33.
2-33.
2-17
