Cleaning the interior components
Electrical Shock Hazard
Disconnect power before cleaning.
Replace all panels before operating.
Failure to do so can result in death or electrical shock.
1. Unplug ice maker or disconnect power.
2. Open the storage bin door and remove
any ice that is in the bin.
3. Remove ice retainer baffle by flexing it
and then slide it off the studs.
4. Remove the ice cutter grid by unscrewing
the 2 thumb screws, sliding the grid
forward, and unplugging the electrical
wire harness.
5. Remove the water pan by unscrewing
and removing the 2 thumb screws and
washers.
6. Remove the hose from the water pump.
r
i
continued on next page
