Package Contents

(1) Charge Station (including attached cord and vehicle
coupler) (EL -50600-1)
(1) Wall-mounting bracket (EL -50600-1)
(1) User Manual (EL -50600-7-2)
(1) Wiring chamber cover (EL -50600-3)
(1) Wiring chamber cover label (EL -50600-3)
(4) 3/4-in. (20-mm) No.2 square-drive screws (EL -
50600-5)
(1) Rubber grommet (EL -50600-4)
(1) Foam dust cover gasket (EL -50600-4)
(1) 3/4-in. (20-mm) plastic bushing (EL -50600-4)
(1) Small sealing plug (EL -50600-4)
(1) Knockout plug
Optional Kit #1 Contents
(1) Primary-side, 12-in. (305-mm) cable w/molded
NEMA 6-30 plug
(1) 3/4-in. (20-mm) NPT cable gland with nut and seal-
ing washer
Optional Kit #2 Contents
(6) #8 × 1 1/4-in. (32-mm) Phillips pan-head screws
with plastic drywall anchors
(3) 3/16 × 1 1/4-in. (5 × 32-mm) Phillips tapered-head
masonry fastener screws
Bosch Automotive Service Solutions LLC
Installation and Operating Instructions | Power Xpress Charge Station | 5 | en
(EL -50600-2)
(EL -50600-5)

Tools Suggested for Installation

Stud finder
Tape measure
2-ft (61-cm) level
Chalk line
Pencil
Power drill
#2 Phillips screwdriver
#2 square-head screwdriver
3/16-in. (5-mm) flat-blade screwdriver
3/32-in. (2.5-mm) flat-blade screwdriver
NM (non-metallic) wire stripper
Wire cutters
Wire stripper
Needle-nose pliers
Hammer
Clear silicone
1/16-in. (2-mm) drill bit
1 1/16-in. (28-mm) hole-saw
1/8-in. (4-mm) masonry drill bit
3/16-in. (5-mm) drill bit
Torque screwdriver with #2 Phillips-head bit and 3/16-in.
(5-mm) slotted-head bit

Possible Materials Needed

(dependent upon installation type; not provided)
90° Fitting for liquid-tight flex conduit
Male threaded EMT fitting with offset; 3/4-in. (20-mm)
Locking nut for 3/4-in. (20-mm) male EMT with binding
screw
Sealing gasket for 3/4-in. (20-mm) male EMT fitting
Male threaded PVC fitting; 3/4-in. (20-mm)
Locking nut for 3/4-in. (20-mm) male PVC fitting
Sealing gasket for 3/4-in. (20-mm) male PVC fitting
PVC jake offset; 3/4-in. (20-mm)
PVC coupler; 3/4-in. (20-mm)
NM, UF, or 3G wire
EL -50600-7-2 | REV. B | 20.10.2013
