- Page 1 Power Xpress™ Dual Bollard Charge Station Installation Guide en Installation Instructions...
- Page 2 Copyright © 2016 Bosch Automotive Service Solutions Inc. All rights reserved. The information, specifications, and illustrations in this guide are based on the latest information available at the time of printing. Bosch Automotive Service Solutions Inc. reserves the right to make changes at any time, without notice.
-
Page 3: Table Of Contents
7.0 Amperage and Breaker Parameters 8.0 Standard Installation 9.0 EVSE Power and Status LED Indications 10.0 Troubleshooting 10.1 Ground Fault Circuit Interrupt (GFCI) Tripped 10.2 Missing Ground 11. Limited Warranty 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc. -
Page 4: Installation Safety
Charge Station itself. These damages will void the warranty for the vehicle and the EVSE. CAUTION: Do not operate the EVSE in temperatures beyond its operating range of -40°F to +122°F (-40°C to +50°C). 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc. -
Page 5: Tools Suggested For Installation (Not Provided)
EVSE. If you are unsure of the NEUTRAL available service connection, consult the (NOT USED) local utility company or contact Bosch Electric Vehicle Solutions at 1-877-805- 120V EVSE (3873). 208V 3-Phase Wye Connection NOTE: The L1, L2, and Ground outputs (H, N for Europe) in the... -
Page 6: 240V 3-Phase Delta Connection (North America) With Center Tap On One Leg
576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc. -
Page 7: Amperage And Breaker Parameters
Conduit must carry conductors for both charge stations each on a dedicated circuit breaker.. NOTE: Positions 6, 7, 8, 9, 0 are not used (X) and are non- operational. The EVSE will not function under these settings. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc. -
Page 8: Standard Installation
Lift the top off the box and remove the bollard from the packaging material. Remove the upper cover from the bollard assembly by removing the cable-management retaining screws (E) on the rear of the bollard. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc. - Page 9 13. Feed the length of the charging cable through the exit hole in the side of the bollard. NOTE: Fish tape can be used to pass the service cord through the bollard and past the EVSE units. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc.
- Page 10 17. Pass the charging cable through the exit hole on the side of the bollard. 18. Feed the cord past the side of the EVSE and slide into posi- tion. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc.
- Page 11 23. Tighten the inner strain-relief nut (A) inside the bollard hand tight. Using expandable pliers, tighten the nut an additional 1/4 turn. NOTE: Do not overtighten the strain-relief nut. The grom- met may pull through. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc.
- Page 12 29. Wire cords to the supply wires and seal the junction box with a cover suitable for wet location. 30. With assistance, lift bollard onto mounting bolts. 31. Level, adjust, and tighten mounting nuts according to anchor manufacturer specification. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc.
- Page 13 40. Tighten terminal screws to 1.2 Nm (10.62 in-lb). 35. Strip back 1 1/4 in. (32 mm) of the wire jacket and 3/8 in. (10 mm) from the ends of the individual conductors. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc.
- Page 14 44. Switch the main circuit breaker to the ON position and verify that the Power LED is illuminated solid green and the Status LED is illuminated solid amber on the EVSE. 576414 | REV. A | 28.10.2016 Bosch Automotive Service Solutions Inc.
-
Page 15: Evse Power And Status Led Indications
Power Xpress™ Dual Bollard Charge Station Installation Guide | 13 | en 10.0 Troubleshooting Power and Status LED If there is a charging issue proceed with the following steps. If the issue Indications persists after three attempts call Bosch at 1-877-805-EVSE (3873) for assistance. Power LED Status LED Condition... -
Page 16: Ground Fault Circuit Interrupt (Gfci) Tripped
This warranty does not cover the cost of freight to return the Charg- 10.1 Ground Fault Circuit Interrupt (GFCI) Tripped ing Station to Bosch. This warranty does include freight to ship repair parts and or a replacement Charging Station to the Purchaser, using a If the Charge Station detects a ground fault, power will be inter- shipping carrier of Bosch’s choice. - Page 17 Charging Station, at its expense. If you do not contact Bosch within five (5) business days of its delivery, Bosch will dispose of the shipment in a manner of its choice without any liability to you. Any damage incurred returning an unauthorized shipment back to you is not Bosch’s responsibil-...
- Page 18 Bosch Automotive Service Solutions Inc. 28635 Mound Road Warren, MI 48092 USA Phone: (877) 805-EVSE (3873) www.pluginnow.com...
