Use
3.10 Battery Installation
Risk of injury!
Never replace the batteries in a hazardous location or an explosive atmosphere. There is a risk
of explosion since the batteries can spark when being changed!
The EVOLUTION 6000 series cameras run on a single lithium Ion battery pack.
Replacement batteries must have the same power and layout as those delivered by MSA with the
camera. Unsuitable batteries can lead to a system failure.
NOTE: To remove battery, reverse the above Battery Installation procedure.
30
WARNING
(1)
Place the camera on a clean, non-abrasive surface.
(2)
Open the battery compartment by pulling down on
the battery latch and swinging the battery compart-
ment door forward.
(3)
Place the battery inside the battery compartment
with the battery logo and arrow pointing toward the
top of the camera. The battery compartment is de-
signed to prevent incorrect battery insertion.
(4)
Gently push the battery into place.
(5)
Close and latch the battery compartment.
EVOLUTION 6000 Thermal Imaging Camera
MSA
US
