Use

Trigger Operation with Flashlight and Laser Pointer Option Installed

Successive Trigger Pulls
First short pull
Second short pull
Third short pull
Single, long trigger pull
NOTE: The laser pointer and flashlight do not function at the same time.

Trigger Operation with Range Finder Option Installed

Trigger Pulls
Short trigger pull
Long trigger pull

Naming Conventions for Still Image Files and Video files

Still images are stored as JPG files in a directory called "Pictures" and named by date and time in
modified ISO 8601 formatting.
For example 2012_05_14-13-58-00.jpg is a still image captured at 13:58:00 (1:58 PM) on
May 14th, 2012.
Video files are stored as MPEG 4 files in a directory called "Video" and also named by date and
time.
For example: 2012_02_14-18-23-45.M4V is a video file started at 18:23:45 (6:23:45 PM) on
February 14th, 2012.
VLC Video Player from VideoLAN (free download: www.videolan.org) is recommended for open-
ing and viewing video files.

Storage Space for Saved Files

Videos are saved in a MPEG4 format. A minimum of four hours of video can be stored. Once the
video memory is full, new clips overwrite the oldest clips.
Images are saved in a JPG format. A minimum of 1000 images can be stored. Once the image
memory is full, new images overwrite the oldest images.
Video files are stored in the "Video" folder and the still images are stored in the "Pictures" folder
in the camera.
28 EVOLUTION 6000 Thermal Imaging Camera
Result
Turns flashlight ON
Turns flashlight OFF and turns laser pointer ON
Turns laser pointer OFF
Captures a still image
Result
Captures a still image
Takes a distance measurement
