245.02—Paper Jam service check
Step Questions / actions
Has paper been fed from an input option
1
before?
1. Turn the printer off.
2
2. Remove the rear frame cover. See
frame cover removal" on page
3. Remove the right cover. See
cover removal" on page
4. Check the connector JOPT1 for proper
connection to the system board, the cable
for pinch points, and the cable or
connector for any other damage.
Is the cable damaged?
1. Carefully lift the printer off the options, and
3
lay the printer on its back.
2. Check the option connector for damage.
Is the connector damaged?
Replace the complete tray 5 option.
4
Did the error clear?
Go to step 4.
Replace the option cable.
See
"Option cable
"Rear
removal" on page
4-37.
"Right
4-38.
Replace the option cable.
See
"Option cable
removal" on page
Problem resolved.
Yes
Go to step 2.
Go to step 3.
4-136.
Go to step 4.
4-136.
Replace the system board.
See
"System board
removal" on page
Diagnostic information
7526
Previous
No
Next
Go Back
4-165.
2-95
