Dda Data Acquisition - Ducati Superbike 848evo Corse Owner's Manual

DDA data acquisition

This function activates the DDA analyzer (not fitted
for this model, but available at Ducati sales network):
the data logger must be connected to vehicle wiring.
To enable this function, enter the menu and set the
"DDA" data acquisition to "On" by holding the
button (12, fig. 15) in position B "▼" pressed for 3
seconds. The START/STOP control for the data
logger lap separator is the high-beam flash button
FLASH (12, fig. 15) on the LH switch. If the DDA
function is active and the display is suddenly
switched off (Key-Off), the function is switched off
automatically.
Note
Online assistance is available to Ducati Data
Analyzer (DDA) owners (http://dda.prosa.com). This
service will provide anything necessary to correctly
use the DDA with your PC: both for the device and
the software for analyzing the recorded data.
Warning
After use, disconnect the DDA from the main
wiring harness.
fig. 33
53
