Removing The Battery - EUROCOM M220S Service Manual

Disassembly

Removing the Battery

Figure 2 - 1
Battery Removal
1. Turn the computer OFF and turn it over.
Sequence
2. Remove screws
3. Separate the battery connector
a. Remove the two
screws and release
the battery cover.
b. Release connector
and pull battery out.
5. Battery
• 2 Screws
2 - 6 Removing the Battery
- in Figure 2 - 1a and release the battery cover
1 2
from the computer and pull the battery
4
a.
1
2
b.
4
.
3
out.
5
3
5
