EUROCOM M220S Service Manual page 39

Disassembly
3. Remove screw
Figure 2 - 10
4. Turn the computer around and remove screws
Bottom Case
Removal
a.
Sequence
(Cont.)
a. Remove the screw
located inside the
CD drive.
b. Remove the screws
b.
from the rear of the
computer.
5. Remove screws
• 5 Screws
6. Disconnect the inverter cable
7. Carefully lift the LCD and top case assembly off the bottom case assembly.
Figure 2 - 11
Bottom Case
Removal
Sequence
(Cont.)
a. Remove the 2
screws.
b. Disconnect the in-
verter, LCD and mi-
crophone cables.
• 2 Screws
2 - 14 Removing the Bottom Case
located inside the CD drive (Figure 2 -
1
2
2 3
(Figure 2 - 11a) and (Figure 2 -
1 2
, LCD cable and microphone cable
3 4
a.
1
b.
5
10a) on the right side of the computer.
- (Figure 2 - 10b) from the rear of the computer.
5
1
4 5
11b).
(Figure 2 -
5
2
4 3
11b).
