Océ
User manual
Océ CS193/CS173/CS163
Copy Operations - GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS193 and is the answer not in the manual?

Questions and answers

Related Manuals for Oce CS193

Summary of Contents for Oce CS193

  • Page 1 Océ User manual Océ CS193/CS173/CS163 Copy Operations - GB...
  • Page 2 Océ-Technologies B.V. Copyright © 2007, Océ All rights reserved. No part of this work may be reproduced, copied, adapted, or transmitted in any form or by any means without written permission from Océ. Océ makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.

  • Page 3: Table Of Contents

    1.4.1 Printed manual ..........................1-12 User manual ............................ 1-12 1.4.2 User manual CD manuals........................ 1-12 Copy Operations (this manual)......................1-12 Print Operations ..........................1-12 Box Operations ..........................1-12 Network Scan/Fax/Network Fax Operations .................. 1-12 Network Administrator ........................1-12 CS193/CS173/CS163 Contents-1...
  • Page 4 Selecting the position of the binding margin (Binding Position settings) ........3-27 3.4.7 To select a Binding Position setting ....................3-28 3.4.8 Reducing the effects of dust on the left partition glass..............3-30 3.4.9 Changing scan settings for each original ..................3-31 Contents-2 CS193/CS173/CS163...
  • Page 5 Registering copy programs (Mode Memory) ................4-10 4.4.1 Deleting a copy program......................... 4-13 Copying with programmed copy settings (Mode Memory) ............4-14 Displaying function descriptions (Help) ..................4-16 4.6.1 Overview of Help screens ....................... 4-16 4.6.2 Displaying main Help screens ......................4-19 CS193/CS173/CS163 Contents-3...
  • Page 6 Automatic duplex unit........................6-4 6.1.3 Automatic document feeder DF-611 ....................6-5 Possible combinations for mixed original sizes................. 6-5 6.1.4 Paper feed cabinet PC-104 ....................... 6-5 6.1.5 Paper feed cabinet PC-204 ....................... 6-6 6.1.6 Paper feed cabinet PC-405 ....................... 6-6 Contents-4 CS193/CS173/CS163...
  • Page 7 Full-color copy and "Background Color" function ................8-20 8.1.16 "Mirror Image" function ........................8-21 Inserting paper between OHP transparencies ("OHP Interleave" function) ......................8-22 Adding cover pages ("Cover Sheet" function)................8-25 Inserting different paper into copies ("Insert Sheet" function) ....................... 8-28 CS193/CS173/CS163 Contents-5...
  • Page 8 To empty the punch scrap box in the finisher ................. 9-24 Care of the machine 10.1 Cleaning............................10-3 10.1.1 Housing............................10-3 10.1.2 Original glass ........................... 10-3 10.1.3 Left partition glass ........................... 10-4 10.1.4 Control panel ........................... 10-4 10.1.5 Original pad ............................. 10-5 10.1.6 Electrostatic charger wire ........................ 10-5 Contents-6 CS193/CS173/CS163...
  • Page 9 System Settings ..........................12-23 12.4.2 Administrator/Machine Settings....................12-28 12.4.3 One-Touch/User Box Registration ....................12-29 12.4.4 User Authentication/Account Track ....................12-29 12.4.5 Network Settings........................... 12-32 12.4.6 Copier Setting ..........................12-32 12.4.7 Printer Settings..........................12-33 12.4.8 Fax Settings ..........................12-33 CS193/CS173/CS163 Contents-7...
  • Page 10 Conditions of the password rules....................12-79 12.16 Enhanced Security Mode ......................12-81 Appendix 13.1 Entering text ........................... 13-3 13.1.1 Enlarging the keyboard........................13-5 13.1.2 To type text............................13-6 13.1.3 List of available characters ......................13-6 13.2 Glossary............................13-7 Index Contents-8 CS193/CS173/CS163...

  • Page 11: Introduction

    Introduction...

  • Page 13: Available Features

    ADF, and then all pages can be copied together as a single job. For details, refer to "Scanning the original in separate batches ("Separate Scan" setting)" on page 3-11 and "Scanning a multi-page original from the original glass" on page 3-15. CS193/CS173/CS163...

  • Page 14: Center Binding And Folding In Half

    Multi-page originals can be copied and stapled together. For details, refer to "Stapling copies (Staple settings)" on page 3-72. Punching holes in copies Holes for filing can be punched in the copies. For details, refer to "Punching holes in copies (Punch settings)" on page 3-75. CS193/CS173/CS163...

  • Page 15: Copying Multiple Original Pages Onto A Single Page

    Adding a cover page Cover pages can be added to copies, or copies can be made using different paper (for example, colored paper) for only the cover pages. For details, refer to "Adding cover pages ("Cover Sheet" function)" on page 8-25. CS193/CS173/CS163...

  • Page 16: Inserting Different Paper Into Copies

    "Full Color", copies are printed with the hues and brightness inversed. With Color setting "Black" or "Single Color", copies are printed with the hues inversed. For details, refer to "Copying with image colors inversed ("Neg./Pos. Reverse" function)" on page 8-41. CS193/CS173/CS163...

  • Page 17: Printing A Mirror Image

    Printing the enlarged image on multiple pages A single original page can be automatically split into parts with each part printed enlarged. For details, refer to "Copying an enlarged image on multiple pages ("Poster Mode" function)" on page 8-61. CS193/CS173/CS163...

  • Page 18: Creating Booklets From Copies Of Pamphlets

    Copying with the page layout of a magazine Copies can be made with the pages arranged in a layout for center binding, such as for a magazine. For details, refer to "Copying with the page layout of a booklet ("Booklet" function)" on page 8-73. CS193/CS173/CS163...

  • Page 19: Erasing Sections Of Copies

    For details, refer to "Displaying function descriptions (Help)" on page 4-16. Interrupting a copy job The copy job being printed can be interrupted in order for a different copy job to be printed. For details, refer to "Interrupting a copy job (Interrupt mode)" on page 4-9. CS193/CS173/CS163...

  • Page 20: Explanation Of Manual Conventions

    Text highlighted in this manner contains useful information and tips to ensure safe use of the machine. Reminder Text highlighted in this manner contains information that should be reminded. Detail Text highlighted in this manner contains references for more detailed information. 1-10 CS193/CS173/CS163...

  • Page 21: Special Text Markings

    If the width (Y) of the paper is shorter than the length (X), the paper has a vertical or portrait orientation, indicated by w. Crosswise (v) If the width (Y) of the paper is longer than the length (X), the paper has a horizontal or landscape orientation, indicated by v. CS193/CS173/CS163 1-11...

  • Page 22: User Manuals

    In order to use the fax functions, the optional fax kit must be purchased separately. Network Administrator This manual contains descriptions on setting methods for each function utilizing network connection, mainly using the Web Connection. Refer to this manual for details on using network functions. 1-12 CS193/CS173/CS163...

  • Page 23: Before Making Copies

    Before making copies...

  • Page 25: Part Names And Their Functions

    Main unit The original is scanned by the scanner section, and the scanned image is printed by the printer section. Referred to as the "machine", the "main unit", or the "CS193/CS173/CS163" throughout the manual. Automatic document feeder Automatically feeds one original sheet at a time for scanning, and automatical-...
  • Page 26 Fax multi line ML-501 Installed to increase the telephone lines available for faxing. Video interface kit VI-504* Used for connecting the image controller to the CS193/CS173. Stamp unit SP-501* Applies a stamp to originals that have been scanned. For details, refer to the User manual – Network scan/Fax/Network Fax Opera- tions.

  • Page 27: Outside Of Machine

    Can be loaded with up to 150 sheets of thick paper 1, thick paper 2 or thick paper 3. Front door Opened when replacing the toner cartridge, waste toner box, or imaging unit, or when cleaning the print head. Output tray Collects printed pages. Control panel Used to specify the various machine settings. CS193/CS173/CS163...
  • Page 28 Can be loaded with up to 150 sheets of thick paper 1, thick paper 2 or thick paper 3. Status indicator The machine’s current status is indicated by the color and lighting/flashing of the indicator. Flashing in blue: Printing normally Flashing in orange: Warning Lit in orange: Stopping operating CS193/CS173/CS163...
  • Page 29 USB port (type A) Used for connecting the USB cable for the authentication unit (biometric type), USB 2.0/1.1 the authentication unit (IC card type) or external memory (USB memory). RS-232C port Used for connecting the JScribe IC card reader/writer. CS193/CS173/CS163...
  • Page 30 Used for connecting the ADF hookup cord. Finisher connector Used for connecting the finisher hookup cord. Ozone filter Collects the ozone generated in the machine. Power cord Supplies power to the machine. Filter Collects the toner dust generated in the machine. CS193/CS173/CS163...

  • Page 31: Inside Of Machine

    Used to scan the original image in this area when the ADF is used. Original scales Position the original so that it is aligned with the scales. Also, use the scales to measure the loaded original. Misfeed-clearing dial Turned when clearing paper misfeeds within the ADF. CS193/CS173/CS163...

  • Page 32: Finisher Fs-519/Output Tray Ot-602/Punch Kit Pk-515

    Before making copies 2.1.4 Finisher FS-519/Output tray OT-602/Punch kit PK-515 2-10 CS193/CS173/CS163...
  • Page 33 Punch kit PK-515 Part name Description Punch kit* Punches holes for filing printed pages when the punch kit is installed onto fin- isher. Parts marked with an asterisk are internal options and therefore are not shown in the illustration. CS193/CS173/CS163 2-11...

  • Page 34: Saddle Stitcher Sd-505/Mailbin Kit Mt-502

    Saddle stitcher SD-505/Mailbin kit MT-502 Saddle stitcher SD-505 Part name Description Output tray Collects printed pages. Misfeed-clearing door Opened when clearing paper misfeeds within the saddle stitcher. Misfeed-clearing door re- Used to open the Misfeed-clearing door. lease lever 2-12 CS193/CS173/CS163...
  • Page 35 Before making copies Mailbin kit MT-502 Part name Description Mailbins Collects printed pages. Misfeed-clearing door Opened when clearing paper misfeeds within the mailbin kit. Guide lever FN7 Moved when clearing paper misfeeds within the mailbin kit. CS193/CS173/CS163 2-13...

  • Page 36: Job Separator Js-505

    Turned when clearing paper misfeeds within the separator. Assist lever Used when removing printed pages. Output tray 1 Collects printed pages. Output tray 2 Collects printed pages. Tray extension Pulled out when feeding papers longer than A4 w size. 2-14 CS193/CS173/CS163...
  • Page 37 Do not place objects on top of the finisher and below the paper output trays, otherwise the machine may be damaged. Do not place your hand below or rest your foot on top of the output trays for finisher. CS193/CS173/CS163 2-15...

  • Page 38: Control Panel

    The indicator lights up in blue when there is saved fax data or unprinted fax data. [C] (clear) key Press to clear a value (such as the number of copies, a zoom ratio, or a size) entered using the keypad. 2-16 CS193/CS173/CS163...
  • Page 39 Do not apply extreme pressure to the touch panel, otherwise it may be scratched or damaged. Never push down on the touch panel with force, and never use a hard or pointed object to make a selection in the touch panel. CS193/CS173/CS163 2-17...

  • Page 40: Basic Settings Screens

    When the machine is ready to begin making copies after being turned on, the Basic screen appears. To activate a function or to select a setting, lightly touch the desired button in the touch panel. Basic screen Quick Copy screen 2-18 CS193/CS173/CS163...
  • Page 41 [Check Job] button The result of the specified settings is displayed. [Job List] button Jobs currently being performed or waiting to be performed are displayed. Various commands for checking and managing jobs are available. CS193/CS173/CS163 2-19...

  • Page 42: Icons That Appear In The Screen

    Indicates that paper is not loaded in the paper tray. Indicates that very little paper remains in the paper tray. When the optional image controller has been installed onto CS193/CS173, touch this icon to display the image controller screen. Indicates that "Enhanced Security Mode" is set to "ON".

  • Page 43: Adjusting The Angle Of The Control Panel

    4 Left tilt position 2.2.1 To adjust the angle of the control panel Pull the control panel release lever toward you, and then push down on the control panel. Control panel release lever The control panel stops at the middle position. CS193/CS173/CS163 2-21...
  • Page 44 To return the control panel to the upper position, pull the control panel release lever toward you, and then pull up on the control panel. Reminder When tilting the control panel, do not grab the touch panel. 2-22 CS193/CS173/CS163...

  • Page 45: Turning On The Main Power And The Auxiliary Power

    A job can also be queued while the machine is warming up after the [Power] (auxiliary power) key is turned on. For details, refer to "Scanning during warm-up" on page 2-24. After the machine has finished warming up, the scanned image will be printed. Refer to "Main unit" on page 6-3 for warm-up time. CS193/CS173/CS163 2-23...

  • Page 46: Scanning During Warm-Up

    The original is scanned, and the job is added to the list of queued jobs. – If the "Copy Operating Screen" parameter in Utility mode was set to "Yes", touch [Next Copy Job] to display the Basic screen. 2-24 CS193/CS173/CS163...

  • Page 47: Turning Off The Machine

    Do not turn off the machine with the main power switch while a queued job or stored data is waiting to be printed, otherwise the jobs will be deleted. Detail The following are cleared when the main power switch and [Power] (auxiliary power) key are turned off. Settings that have not been programmed Jobs queued to be printed CS193/CS173/CS163 2-25...

  • Page 48: Automatically Clearing Settings (Automatic Panel Reset)

    As the factory default, the Copy mode screen is displayed after 1 minute. Detail The mode screen that is displayed when the System Auto Reset operation is performed can be changed from the Utility mode. For details, refer to "System Settings" on page 12-23. 2-26 CS193/CS173/CS163...

  • Page 49: Automatically Conserving Energy (Low Power Mode)

    The Low Power mode can also be canceled by pressing any key in the control panel or by touching the touch panel. Detail The length of time until the machine enters Low Power mode can be changed. For details, refer to "System Settings" on page 12-15 and page 12-23. CS193/CS173/CS163 2-27...

  • Page 50: Automatically Conserving Energy (Sleep Mode)

    As the factory default, the machine enters Low Power mode. Detail Whether the machine enters Low Power mode or Sleep mode when the [Power Save] key is pressed can be set from the Administrator Settings mode. For details, refer to "System Settings" on page 12-23. 2-28 CS193/CS173/CS163...

  • Page 51: Automatically Turning The Machine On/Off (Weekly Timer)

    Type in the password (up to 8 digits) for non-business hours. – For details on setting the password for non-business hours, refer to "System Settings" on page 12-23. Touch [OK]. The message "It is now non-business hour. Set the Sleep Mode time." appears. CS193/CS173/CS163 2-29...
  • Page 52 From the Password for Non-Business Hours screen (displayed from Administrator Settings mode), the machine can be set so that the screen for entering the password for non-business hours is not displayed. The default setting for the "Password for Non-Business Hours" parameter is "No" (the screen is not displayed). 2-30 CS193/CS173/CS163...

  • Page 53: Controlling Each User's Use Of This Machine (User Authentication)

    For details on specifying public user settings, refer to "Selecting an authentication method" on page 12-61 and "Public User Access" on page 12-65. – If "Enhanced Security Mode" is set to "ON", [Public User Access] and [User Name List] do not appear. CS193/CS173/CS163 2-31...
  • Page 54 Touch [Server Name] to display the names of the registered servers, and then select the desired server. For details on specifying settings for an external server authentication, refer to "Selecting an authentication method" on page 12-61. Type in the user name, and then touch [OK]. Touch [Password]. 2-32 CS193/CS173/CS163...
  • Page 55 Make copies using the desired copy settings. When you are finished printing, press the [Access] key. A message appears, requesting confirmation to log off. Touch [Yes], and then touch [OK]. The user authentication screen appears. CS193/CS173/CS163 2-33...
  • Page 56 User authentication settings can be specified using the User Authentication parameters in Administrator Settings mode, available from the Utility mode. Settings should be specified by the administrator. 2-34 CS193/CS173/CS163...

  • Page 57: Controlling Each Account's Use Of This Machine (Account Track)

    If you do not know the account name or password, contact your administrator. A total of 1,000 users and accounts can be registered. Touch [Account Name]. – If the Administrator Settings mode settings have been set to "Password Only", touch [Password], and then continue with step 4. CS193/CS173/CS163 2-35...
  • Page 58 Before making copies Type in the account name, and then touch [OK]. Touch [Password]. Type in the password, and then touch [OK]. 2-36 CS193/CS173/CS163...
  • Page 59 "Password Only", log on is possible by only entering the password. For details, refer to "User Authentication/Account Track" on page 12-29. For details on specifying account track settings, refer to "Selecting an authentication method" on page 12-61. CS193/CS173/CS163 2-37...

  • Page 60: Controlling Use Of This Machine With Authentication Unit (Biometric Type)

    For details on specifying authentication settings for the authentication unit (biometric type) and on registering finger vein patterns, refer to the user manual provided with the authentication unit (biometric type). When "1-to-many authentication" has been specified Place your finger on the authentication unit (biometric type). 2-38 CS193/CS173/CS163...

  • Page 61: When "1-To-1 Authentication" Has Been Specified

    Before making copies The basic screen appears. When "1-to-1 authentication" has been specified Type in the user name. Place your finger on the authentication unit (biometric type). CS193/CS173/CS163 2-39...

  • Page 62: Controlling Use Of This Machine With The Authentication Unit (Ic Card Type)

    To use card authentication, register the card information in advance. For details on specifying authentication settings for the authentication unit (IC card type) and on registering IC card information, refer to the manual provided with the authentication unit (IC card type). When "Card Authentication" has been specified 2-40 CS193/CS173/CS163...
  • Page 63 Before making copies Place the IC card horizontally on the card scanning area of the authentication unit (IC card type). The Basic screen appears. CS193/CS173/CS163 2-41...

  • Page 64: When "Card Authentication + Password" Has Been Specified

    Type in the password and then touch [Login] or press the [Access] key. The Basic screen appears. Note If the authentication unit (IC card type) cannot be used, it is possible to use this machine by entering a user name and password. 2-42 CS193/CS173/CS163...

  • Page 65: Loading Paper Into Tray 1/2/3/4

    Load the paper into the tray so that the side of the paper to be , mark printed on (the side facing up when the package was unwrapped) faces up. – Load letterhead paper so that the side to be printed on faces down. How is curled paper loaded? CS193/CS173/CS163 2-43...
  • Page 66 Be careful not to touch the film. For details on selecting the size and type of paper loaded in tray 1/2/3/4, refer to "Copy paper" on page 7-3. To print on OHP transparencies, thick paper 4, envelopes or postcards, use the bypass tray. 2-44 CS193/CS173/CS163...

  • Page 67: Loading Paper Into The Lct

    Load letterhead paper so that the side to be printed on faces down. – To print on OHP transparencies, thick paper 4, envelopes or postcards, use the bypass tray. How is curled paper loaded? % Flatten the paper before loading it. CS193/CS173/CS163 2-45...
  • Page 68 For details on the paper that can be loaded into the LCT, refer to "Copy paper" on page 7-3. Note If the machine has entered Low Power mode or Sleep mode, the LCT cannot be pulled out, even after the tray release button is pressed. Be sure to first cancel Low Power mode or Sleep mode. 2-46 CS193/CS173/CS163...

  • Page 69: Loading Paper Into The Bypass Tray

    How many sheets of paper and other media can be loaded? % Do not load so many sheets of plain paper that the top of the stack is higher than the , mark. Lateral guides Select the paper type. CS193/CS173/CS163 2-47...
  • Page 70 If label sheets are loaded, select "Thick 1". Printing on OHP transparencies is possible only in black. When selecting OHP transparencies, select the "Black" Color setting, and then select the paper type. A maximum of 20 postcards can be loaded into the bypass tray. 2-48 CS193/CS173/CS163...
  • Page 71 When loading envelopes, load them with the flap side up, as shown in the illustration. If the envelopes are loaded with the flap side down, a paper misfeed may occur. The flap side of envelopes cannot be printed on. A maximum of 10 envelopes can be loaded into the bypass tray. Flap side CS193/CS173/CS163 2-49...
  • Page 72 Detail For details on specifying the paper size for the bypass tray, refer to "Selecting a paper size setting (Size Setting)" on page 7-8. For details on the paper sizes, refer to "Copy paper" on page 7-3. 2-50 CS193/CS173/CS163...

  • Page 73: Basic Copy Operations

    Basic copy operations...

  • Page 75: General Copy Operation

    Some settings cannot be used together. For details on the settings that cannot be combined, refer to "Operations that cannot be combined" on page 3-6. Press the [Copy] key to display the Basic screen in Copy mode. Position the original to be copied. – For details on positioning the original, refer to page 3-8. CS193/CS173/CS163...
  • Page 76 For details on specifying settings for the Application functions, refer to page 8-3. Using the keypad, type in the desired number of copies. – If the number of copies was incorrectly entered, press the [C] (clear) key in the keypad, and then specify the correct number of copies. CS193/CS173/CS163...
  • Page 77 – To stop the copy operation being performed, press the [Stop] key. For details, refer to page 3-83. – The next copy operation can be queued while a copy operation is being performed. For details, refer to page 3-82. CS193/CS173/CS163...

  • Page 78: Operations That Cannot Be Combined

    The setting specified first is given priority. (A warning message appears.) 3.2.1 Operations where the setting specified last is given priority The procedure for setting the "Booklet" function after selecting the "2 Position" Staple setting is described below. Select the "2 Position" Staple setting. Set the "Booklet" function. CS193/CS173/CS163...

  • Page 79: Operations Where The Setting Specified First Is Given Priority

    The message "Cannot be set with Booklet." appears and the "2 Position" Staple setting cannot be selected. The "Booklet" function remains selected and the "2 Position" Staple setting is canceled. To select the "2 Position" Staple setting, cancel the "Booklet" function, and then select the "2 Position" Staple setting. CS193/CS173/CS163...

  • Page 80: Feeding The Original

    Place the original in the original feed tray in the order to be scanned with the side to be scanned faces up. – Load the original pages so that the top of the original is toward the back or the right side of the machine. CS193/CS173/CS163...

  • Page 81: Placing The Original On The Original Glass

    When loaded in the w orientation 20° 20° Align the original with the mark in the back-left corner of the original scales. – For details on selecting the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. CS193/CS173/CS163...
  • Page 82 Close the ADF or the original cover. 3-10 CS193/CS173/CS163...

  • Page 83: Scanning The Original In Separate Batches ("Separate Scan" Setting)

    Position the original to be copied. – For details on positioning the original, refer to "Feeding the original" on page 3-8. In the Basic screen, touch [Separate Scan]. – To cancel the "Separate Scan" setting, touch [Separate Scan] again to deselect it. CS193/CS173/CS163 3-11...
  • Page 84 ADF, refer to "Originals" on page 7-21. – To change the scanning settings, touch [Change Setting]. For details on changing the scanning settings, refer to "Changing scan settings for each original" on page 3-31. 3-12 CS193/CS173/CS163...
  • Page 85 The amount of memory available can be checked beside "Memory" in the lower-left corner of the screen. To delete the image data, press the [Stop] key, and then delete the job. For details, refer to "Temporarily stopping scanning/printing" on page 3-83. After all original pages have been scanned, touch [Finish]. CS193/CS173/CS163 3-13...
  • Page 86 [Start] key. – If the "Separate Scan Output Method" parameter is set to "Batch Print", the copy settings can be changed. To change the copy settings, touch [Change Setting], and then touch [OK] after changing the settings as desired. 3-14 CS193/CS173/CS163...

  • Page 87: Scanning A Multi-Page Original From The Original Glass

    For details on positioning the original, refer to "Placing the original on the original glass" on page 3-9. When loaded in the v orientation When loaded in the w orientation 20° 20° Close the ADF or the original cover. In the Basic screen, touch [Duplex/Combine]. The Duplex/Combine screen appears. CS193/CS173/CS163 3-15...
  • Page 88 3-53. Touch [Original Direction], select the orientation of the loaded original, and then touch [OK]. – For details on specifying the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. Touch [OK]. 3-16 CS193/CS173/CS163...
  • Page 89 The buttons that appear in the screen for changing the settings differ depending on the specified settings. Settings for the following can be changed. 1-Sided/2-Sided, Binding Position, Zoom, Frame Erase, Center Erase, Original Size – To cancel changes to the settings, touch [Cancel]. CS193/CS173/CS163 3-17...
  • Page 90 [Start] key. – If the "Separate Scan Output Method" parameter is set to "Batch Print", the copy settings can be changed. To change the copy settings, touch [Change Setting], and then touch [OK] after changing the settings as desired. 3-18 CS193/CS173/CS163...

  • Page 91: Specifying Original Settings

    Position the original to be copied. – For details on positioning the original, refer to "Feeding the original" on page 3-8. In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Original Size]. The Original Size screen appears. CS193/CS173/CS163 3-19...
  • Page 92 If a value outside the allowable range is specified in the Custom Size screen, the message "Input Error" appears. If "Input Error" appeared or if the value was incorrectly entered, press the [C] (clear) key, and then specify the correct value. – To cancel changes to the settings, touch [Cancel]. Custom Size screen 3-20 CS193/CS173/CS163...

  • Page 93: Copying Originals Of Mixed Sizes ("Mixed Original" Setting)

    For details on the mixed original sizes that can be loaded in the ADF, refer to "Originals that can be loaded into the ADF" on page 7-21. Align the originals as the references so that the side to be scanned faces up. CS193/CS173/CS163 3-21...
  • Page 94 Lateral guide In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Mixed Original]. – To cancel the "Mixed Original" setting, touch [Mixed Original] again to deselect it. 3-22 CS193/CS173/CS163...

  • Page 95: Loading Folded (Z-Folded) Originals

    – For details on loading the original, refer to "Loading the original into the ADF" on page 3-8. In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Z-Folded Original]. CS193/CS173/CS163 3-23...

  • Page 96: Selecting The Original Orientation (Original Direction Settings)

    ADF with the top of the original toward the right side of this machine. • Select this setting for an original placed on the original glass with the top of the original toward the left side of this machine. 3-24 CS193/CS173/CS163...

  • Page 97: To Select An Original Direction Setting

    Position the original to be copied. – For details on positioning the original, refer to "Feeding the original" on page 3-8. In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Original Direction]. The Original Direction screen appears. CS193/CS173/CS163 3-25...
  • Page 98 Basic copy operations Touch the button for the orientation of the loaded original, and then touch [OK]. – To cancel the setting and select the default, press the [Reset] key. 3-26 CS193/CS173/CS163...

  • Page 99: Selecting The Position Of The Binding Margin (Binding Position Settings)

    If the original length is more than 297 mm, a binding position along the short side of the paper is selected. If "Auto" is selected, the binding margin is set at the top or at the left. When the original length is more than 297 mm: CS193/CS173/CS163 3-27...

  • Page 100: To Select A Binding Position Setting

    When loading an original with a binding margin, position the top of the original toward the back of the machine. In the Basic screen, touch [Original Setting]. The Original Setting screen appears. Touch [Binding Position]. The Binding Position screen appears. 3-28 CS193/CS173/CS163...
  • Page 101 Basic copy operations Touch the button for the desired binding margin position, and then touch [OK]. – To cancel the setting and select the default, press the [Reset] key. CS193/CS173/CS163 3-29...

  • Page 102: Reducing The Effects Of Dust On The Left Partition Glass

    For details on loading the original, refer to "Loading the original into the ADF" on page 3-8. In the Basic screen, touch [Original Setting]. Touch [Despeckle]. – To cancel the "Despeckle" setting, touch [Despeckle] again to deselect it. Note The scanning speed will be reduced. 3-30 CS193/CS173/CS163...

  • Page 103: Changing Scan Settings For Each Original

    "Separate Scan" setting is used. Position the original to be copied. In the Basic screen, touch [Separate Scan]. Press the [Start] key. Scanning begins. Touch [Change Setting]. A screen appears, allowing you to change the settings. CS193/CS173/CS163 3-31...
  • Page 104 The buttons that appear in the screen for changing the settings differ depending on the specified settings. Settings for the following can be changed. 1-Sided/2-Sided, Binding Position, Zoom, Frame Erase, Center Erase, Original Size – To cancel changes to the settings, touch [Cancel]. Binding Position screen Zoom screen 3-32 CS193/CS173/CS163...
  • Page 105 "Frame Erase" setting, refer to "Erasing specified areas of copies ("Frame Erase" function)" on page 8-75. – The Center Erase screen appears only when the "Book Copy" function is selected. – The Original Size screen appears only when the "Mixed Original" setting is selected. Touch [OK]. CS193/CS173/CS163 3-33...

  • Page 106: Selecting A Color Setting

    This is useful for producing monocolor copies of originals containing gradation differences, such as magazines and newspapers, and for offsetting the yellow tint in originals that have yellowed. 3-34 CS193/CS173/CS163...

  • Page 107: To Select A Color Setting

    The following procedure describes how to select a Color setting. In the Basic screen, touch [Color]. The Color screen appears. Select the desired Color setting. – If the "2 Color" setting was selected, touch the button for the desired colors, and then touch [OK]. CS193/CS173/CS163 3-35...
  • Page 108 – To use the average brightness method for reproducing gradations in monocolor originals, touch [Solid]. – If the "Solid" setting is not selected, the relative luminosity method is selected. Touch [OK]. The Basic screen appears again. 3-36 CS193/CS173/CS163...

  • Page 109: Selecting A Paper Setting

    If the "Auto Paper Select" was selected at the "Auto Zoom" setting, the Zoom screen appears. Touch the button for the desired zoom ratio. The "Auto" Paper setting cannot be combined with the "Auto" Zoom Setting. For details on specifying the priority of paper trays, refer to "Specifying user settings" on page 12-15. CS193/CS173/CS163 3-37...

  • Page 110: Automatically Selecting The Paper Size ("Auto" Paper Setting)

    If the zoom ratio was increased or decreased, a paper size that corresponds to the specified zoom ratio is automatically selected. In the Basic screen, touch [Paper]. The Paper screen appears. Touch [Auto]. Touch [OK]. The Basic screen appears again. 3-38 CS193/CS173/CS163...

  • Page 111: Manually Selecting The Desired Paper Size

    "Automatically selecting the zoom ratio ("Auto" Zoom Setting)" on page 3-40. Load the appropriate papers into the paper tray in advance. In the Basic screen, touch [Paper]. The Paper screen appears. Select the paper tray loaded with the desired paper. Touch [OK]. The Basic screen appears again. CS193/CS173/CS163 3-39...

  • Page 112: Specifying A Zoom Setting

    If the "Auto Zoom" was selected at the "Auto Paper Select" setting, the Paper screen appears. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [Auto]. Touch [OK]. The Basic screen appears again. 3-40 CS193/CS173/CS163...

  • Page 113: Specifying The Zoom Ratio Of The Original ("Full Size" Setting)

    If the value was incorrectly entered, press the [C] (clear) key to erase the value, and then specify the correct value. The entered zoom ratio can be stored. For details on storing zoom ratios, refer to "Storing the desired zoom ratio" on page 3-48. CS193/CS173/CS163 3-41...
  • Page 114 In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [XY Zoom]. Using the keypad, type in the desired zoom ratio (between 25.0% and 400.0%). Touch [OK], and then touch [OK] in the next screen that appears. The Basic screen appears again. 3-42 CS193/CS173/CS163...

  • Page 115: Slightly Reducing The Copy ("Minimal" Setting)

    "Minimal" setting or programming custom zoom ratios, refer to "Storing the desired zoom ratio" on page 3-48. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [Minimal]. Touch [OK]. The Basic screen appears again. CS193/CS173/CS163 3-43...

  • Page 116: Selecting A Preset Zoom Ratio (Enlarge And Reduce Settings)

    The most suitable zoom ratios for copying from common standard original sizes to standard paper sizes are preset. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch the button for the appropriate zoom ratio beside "Enlarge" and "Reduce", depending on the original and paper sizes. Touch [OK]. The Basic screen appears again. 3-44 CS193/CS173/CS163...

  • Page 117: Typing In Separate X And Y Zoom Ratios (Individual Zoom Settings)

    If the value was incorrectly entered, press the [C] (clear) key to erase the value, and then specify the correct value. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [XY Zoom]. CS193/CS173/CS163 3-45...
  • Page 118 Touch [Y] under "Set Individual Zoom", and then use the keypad to type in the desired zoom ratio (between 25.0% and 400.0%) for the Y direction. – To cancel changes to the settings, touch [Cancel]. Touch [OK], and then touch [OK] in the next screen that appears. The Basic screen appears again. 3-46 CS193/CS173/CS163...

  • Page 119: Selecting A Stored Zoom Ratio

    Stored zoom ratios can be changed to desired zoom ratios. For details on storing zoom ratios, refer to "Storing the desired zoom ratio" on page 3-48. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch the button for the desired zoom ratio under "Set Zoom Ratio". Touch [OK]. The Basic screen appears again. CS193/CS173/CS163 3-47...

  • Page 120: Storing The Desired Zoom Ratio

    If a button stored with a zoom ratio is not touched before [OK] is touched, no setting is changed. In the Basic screen, touch [Zoom]. The Zoom screen appears. Touch [XY Zoom]. 3-48 CS193/CS173/CS163...
  • Page 121 Touch the button or [Minimal] where the new zoom ratio is to be stored. – To cancel the setting and select the default, press the [Reset] key. The specified zoom ratio is stored. Touch [OK], and then touch [OK] in the next two screens that appear. The Basic screen appears again. CS193/CS173/CS163 3-49...

  • Page 122: Selecting An Original > Copy Setting

    2-Sided > 1-Sided Select this setting to produce two single-sided copies from one double-sided original. 2-Sided > 2-Sided Select this setting to produce double-sided copies from double-sided origi- nals. The following procedures describe how to select Original and Copy settings. 3-50 CS193/CS173/CS163...

  • Page 123: Selecting Single-Sided Copies

    Touch [1-Sided > 1-Sided] or [2-Sided > 1-Sided]. – If "2-Sided > 1-Sided" is selected, specify the position of the binding margin and the orientation of the loaded original, otherwise the copies will not be printed as desired. CS193/CS173/CS163 3-51...
  • Page 124 Touch [Original Direction], select the orientation of the loaded original, and then touch [OK]. – For details on specifying the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. Touch [OK]. The Basic screen appears again. 3-52 CS193/CS173/CS163...

  • Page 125: Selecting Double-Sided Copies

    If the original length is more than 297 mm, a binding position along the short side of the paper is selected. – If the binding position for the copy is set to "Auto", the binding position is set at the top or at the left. CS193/CS173/CS163 3-53...
  • Page 126 Touch [Original Direction], select the orientation of the loaded original, and then touch [OK]. – For details on specifying the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. Touch [OK]. The Basic screen appears again. 3-54 CS193/CS173/CS163...

  • Page 127: Selecting A Combined Copy Setting

    Vertical 8in1 Select this setting to print eight original Horizontal pages on one page. The page arrange- ment (Numbering Direction setting) can be specified. Vertical The following procedure describes how to select a combined copy setting. CS193/CS173/CS163 3-55...

  • Page 128: Copying Multiple Original Pages Onto A Single Page (Combined Copy Settings)

    (Binding Position settings)" on page 3-27. For details on specifying the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. In the Basic screen, touch [Duplex/Combine]. The Duplex/Combine screen appears. Select the desired combined copy setting. 3-56 CS193/CS173/CS163...
  • Page 129 If "2in1" was selected, the pages will be arranged as shown below. Horizontal Vertical – If "4in1 / 8in1" was selected, the 4in1/8in1 screen appears. Touch [Vertical] or [Horizontal] to select the page arrangement. – To cancel the setting, touch [No]. CS193/CS173/CS163 3-57...

  • Page 130: Selecting The Quality Of The Original

    The copied text is reproduced so that it is darker, making it easier to read. Dot Matrix Original Select this setting when copying images (originals) printed with this machine. Copied Paper The following procedure describes how to select an Original Type setting. 3-58 CS193/CS173/CS163...

  • Page 131: To Select An Original Type Setting

    For details on positioning the original, refer to "Feeding the original" on page 3-8. In the Basic screen, touch [Quality/Density]. The Quality/Density screen appears. Touch the button for the quality setting most appropriate for the loaded original. – For an original that contains only text, touch [Text]. CS193/CS173/CS163 3-59...
  • Page 132 [OK]. – For an original that contains maps, touch [Map]. – For an original that contains faint text, touch [Dot Matrix Original]. – For an original printed with this machine, touch [Copied Paper]. The Quality/Density screen appears again. 3-60 CS193/CS173/CS163...

  • Page 133: Selecting The Density Settings

    Touch [Standard] to select the middle setting of the nine levels. The following procedures describe how to specify the density settings. 3.11.1 Adjusting the print density (Density settings) In the Basic screen, touch [Quality/Density]. The Quality/Density screen appears. CS193/CS173/CS163 3-61...
  • Page 134 Each time [Light] or [Dark] is touched, the density is lightened or darkened by one level. – To select the center setting (default setting), touch [Standard]. – To cancel the setting and select the default, press the [Reset] key. Touch [OK]. 3-62 CS193/CS173/CS163...

  • Page 135: Adjusting The Background Density (Background Removal Settings)

    Basic copy operations 3.11.2 Adjusting the background density (Background Removal settings) In the Basic screen, touch [Quality/Density]. The Quality/Density screen appears. Touch [Background Removal]. The Background Removal screen appears. Select the desired Background Removal setting. CS193/CS173/CS163 3-63...

  • Page 136: Adjusting The Reproduction Quality Of Text

    To cancel the setting and select the default, press the [Reset] key. Touch [OK]. 3.11.3 Adjusting the reproduction quality of text As the factory default, "0" is selected. In the Basic screen, touch [Quality/Density]. The Quality/Density screen appears. Touch [Text Enhancement]. The Text Enhancement screen appears. 3-64 CS193/CS173/CS163...
  • Page 137 Each time [Lighter Text] or [Darker Text] is touched, the density is lightened or darkened by one level. To select the middle setting of the nine levels ("0"), touch [Standard]. – To cancel the setting and select the default, press the [Reset] key. Touch [OK]. CS193/CS173/CS163 3-65...

  • Page 138: Printing With A Glossy Finish ("Glossy" Setting)

    Printing with a glossy finish ("Glossy" setting) In the Basic screen, touch [Quality/Density]. The Quality/Density screen appears. Touch [Glossy]. – To cancel the "Glossy" setting, touch [Glossy] again to deselect it. – To cancel the setting and select the default, press the [Reset] key. 3-66 CS193/CS173/CS163...

  • Page 139: Selecting Finishing Settings

    If a finisher or a separator is installed The copies are fed out and stacked on top of each other with each set shifted to separate CS193/CS173/CS163 3-67...
  • Page 140 Available Finishing Settings Finisher Finisher Finisher Finisher Separator + Punch kit + Punch kit + Punch kit + Saddle + Mailbin stitcher Sort Group Offset Staple Punch Center Staple & Fold Half-Fold Select Output Tray o: Possible e: Not possible 3-68 CS193/CS173/CS163...

  • Page 141: Separating Copies By Sets ("Sort" Setting)

    In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Sort]. – To separate each set of copies, touch [Yes] under "Offset". Touch [OK]. The Basic screen appears again. CS193/CS173/CS163 3-69...

  • Page 142: Separating Copies By Pages ("Group" Setting)

    In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Group]. – To separate each set of pages, touch [Yes] under "Offset". Touch [OK]. The Basic screen appears again. 3-70 CS193/CS173/CS163...

  • Page 143: Selecting The Output Tray

    The output tray can be selected only if optional finisher is installed. In the Basic screen, touch [Finishing]. The Finishing screen appears. Touch [Output Tray]. Select the output tray where copies are to be fed, and then touch [OK]. CS193/CS173/CS163 3-71...

  • Page 144: Stapling Copies (Staple Settings)

    Examples of the possible number of bound pages are listed below. 50 sheets of 90 g/m paper 2 sheets of 209 g/m paper + 48 sheets of 90 g/m paper Maximum of 30 sheets of 91 to 120 g/m paper 3-72 CS193/CS173/CS163...
  • Page 145 In the Basic screen, touch [Finishing]. The Finishing screen appears. Under "Staple", touch either [Corner] or [2 Position]. – To cancel the Staple setting, touch [None]. Touch [Position Setting]. – Select the stapling position, and then touch [OK]. CS193/CS173/CS163 3-73...
  • Page 146 If desired, touch [Original Direction], and then select the setting appropriate for the original. – For details on specifying the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. Touch [OK]. The Basic screen appears again. 3-74 CS193/CS173/CS163...

  • Page 147: Punching Holes In Copies (Punch Settings)

    Paper weight Paper size Plain paper (60 g/m to 90 g/m A3 w, A4 v, B5 w Thick paper 1/2 (91 g/m to 209 g/m In the Basic screen, touch [Finishing]. The Finishing screen appears. Under "Punch", touch [4-Hole]. CS193/CS173/CS163 3-75...
  • Page 148 If desired, touch [Original Direction], and then select the setting appropriate for the original. – For details on specifying the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. Touch [OK]. The Basic screen appears again. 3-76 CS193/CS173/CS163...

  • Page 149: Selecting A Folding Setting

    In order for copies to be bound at the center or folded in half, all of the following conditions must be met. The paper width must be between 182 mm and 297 mm. The paper length must be between 257 mm and 431.8 mm. CS193/CS173/CS163 3-77...
  • Page 150 The Center Staple/Fold screen appears. Touch [Yes] below "Half-Fold". – As the factory default, the "Booklet" function is automatically specified when Half-Fold is selected. – To cancel the "Half-Fold" setting, touch [No] or the button for a different setting. 3-78 CS193/CS173/CS163...

  • Page 151: Binding Copies At The Center ("Center Staple & Fold" Setting)

    In order for copies to be bound at the center or folded in half, all of the following conditions must be met. The paper width must be between 182 mm and 297 mm. The paper length must be between 257 mm and 431.8 mm. In the Basic screen, touch [Center Staple/Fold]. The Center Staple/Fold screen appears. CS193/CS173/CS163 3-79...
  • Page 152 When the "Center Staple & Fold" setting is selected, the following Finishing settings are not available. Group Offset Staple Punch – To cancel the "Center Staple & Fold" setting, touch [No] or the button for a different setting. Touch [OK], and then touch [OK] again. 3-80 CS193/CS173/CS163...

  • Page 153: Selecting Not To Rotate The Image

    Copies can be printed with the image not rotated to fit the orientation of the loaded paper. Original Auto Rotate OFF Auto Rotate Note Depending on the paper size and zoom ratio, some parts of the image may be lost. In the Basic screen, touch [Auto Rotate OFF]. CS193/CS173/CS163 3-81...

  • Page 154: Scanning The Next Original To Be Copied While A Copy Job Is Being Printed (Next Job Reservation)

    Basic screen. – For details on specifying the screen that appears while printing, refer to "Custom Display Settings" on page 12-17. Press the [Start] key. After the current copy job is finished, the next copy job begins. 3-82 CS193/CS173/CS163...

  • Page 155: Temporarily Stopping Scanning/Printing

    For details on deleting a temporarily stopped job, refer to "Deleting a paused job" on page 3-84. Press the [Stop] key while an original is being scanned or a job is being printed. Scanning/printing stops. The Stopped Jobs screen appears. To continue all stopped jobs, press the [Start] key. CS193/CS173/CS163 3-83...

  • Page 156: Deleting A Paused Job

    Press the [Stop] key while an original is being scanned or a job is being printed. Scanning/printing stops. The Stopped Jobs screen appears. Select the job to be deleted, and then touch [Delete]. The selected job is deleted. 3-84 CS193/CS173/CS163...

  • Page 157: Additional Copy Operations

    Additional copy operations...

  • Page 159: Checking The Copy Settings (Check Job)

    From the Check Job Details screens, the current copy settings can be checked and changed if desired. 4.1.1 To check the settings Touch [Check Job] in the left panel, and then touch [Check Details]. The Check Job Settings screen appears. CS193/CS173/CS163...
  • Page 160 Additional copy operations CS193/CS173/CS163...
  • Page 161 To display the previous screen, touch [ Back]. To display the next screen, touch [Forward If the setting for a function has been changed from the default, the button for that function appears with a colored box around it. CS193/CS173/CS163...

  • Page 162: To Change The Settings

    ] until the button for the function to be changed is displayed. Touch the button for the function whose setting is to be changed. The screen for specifying the setting appears. Follow the appropriate procedure to change the setting. CS193/CS173/CS163...

  • Page 163: Printing A Proof To Check The Settings (Proof Copy)

    After one minute (when "System Auto Reset" is set to "OFF") For details on stored jobs, refer to page 11-13. If "System Auto Reset" is set to "OFF", the job is stored if no operation is performed for 1 minute. CS193/CS173/CS163...
  • Page 164 Press the [Proof Copy] key to print another proof copy. – To stop the proof copy while scanning or printing, perform the operation described in "Temporarily stopping scanning/printing" on page 3-83. Touch [Print]. The remaining copies are queued as a copy job. CS193/CS173/CS163...

  • Page 165: Interrupting A Copy Job (Interrupt Mode)

    After the interrupting job has finished printing, press the [Interrupt] key. The indicator on the [Interrupt] key goes off. The copy settings return to those specified before printing was interrupted. Note If the interrupting job is cancelled, printing for the interrupted job automatically restarts. CS193/CS173/CS163...

  • Page 166: Registering Copy Programs (Mode Memory)

    – If 30 copy programs have been registered, delete an unnecessary copy program. For details on deleting copy programs, refer to "Deleting a copy program" on page 4-13. The Register Copy Program screen appears. 4-10 CS193/CS173/CS163...
  • Page 167 The copy program can be given the same name as a copy program that has already been registered. – To stop specifying the name of the copy program, touch [Cancel]. The Recall Copy Program screen appears again. The copy program is registered and a button with the entered copy program name appears. CS193/CS173/CS163 4-11...
  • Page 168 Otherwise, continue to touch [Cancel] until the Basic screen is displayed. The settings of a copy program cannot be changed. If the copy program that was selected has been locked, [Edit Name] and [Delete] do not appear. For details, refer to "System Settings" on page 12-23. 4-12 CS193/CS173/CS163...

  • Page 169: Deleting A Copy Program

    Touch [Delete]. A message appears, requesting confirmation to delete the copy program. Touch [Yes], and then touch [OK]. The Recall Copy Program screen appears again. The copy settings registered in the copy program are erased. CS193/CS173/CS163 4-13...

  • Page 170: Copying With Programmed Copy Settings (Mode Memory)

    – If the copy settings in the selected copy program are not to be checked, continue with step 8. – If the copy program to be recalled is not displayed, touch until the desired copy program is displayed. 4-14 CS193/CS173/CS163...
  • Page 171 The programmed copy settings are recalled and the Basic screen appears again. Press the [Start] key. Copying begins with the recalled copy settings. Note To stop recalling a copy program, press the [Reset] key or the [Mode Memory] key or touch [Cancel]. CS193/CS173/CS163 4-15...

  • Page 172: Displaying Function Descriptions (Help)

    To display the next screen higher in the menu structure, touch [Close]. Touch [Exit] to exit the Help mode and return to the screen that was displayed before the [Help] key was pressed. 4-16 CS193/CS173/CS163...
  • Page 173 Displays the first Help screen for each description. [Job List] Detail The items displayed in the Help menu for the name and function of each part differ depending on the options that are installed. Help screen (bottom level) (Example: Function % Copy % Color) CS193/CS173/CS163 4-17...
  • Page 174 To display the Help screen for "Function" that contains the selected item, touch [Close] in the Help screen displayed by selecting an item in a Function Map screen. To quit the Help mode, press the [Help] key or touch [Exit]. 4-18 CS193/CS173/CS163...

  • Page 175: Displaying Main Help Screens

    Is there more information about the buttons of the Help screens? % Refer to "Overview of Help screens" on page 4-16. Touch [Copy] or [Open], or press the [1] key in the keypad. The Copy Help screen appears. CS193/CS173/CS163 4-19...
  • Page 176 Touch [Open] or the right of the desired information, or press the key in the keypad for the number to the left of the desired information to display the corresponding Help screen. After checking the Help information, touch [Exit] or press the [Help] key again. The Basic screen appears again. 4-20 CS193/CS173/CS163...

  • Page 177: Specifying Control Panel Settings (Accessibility Mode)

    Touch [Touch Panel Adjustment] or press the [1] key in the keypad. The Touch Panel Adjustment. screen appears. Why does the machine not respond when [Touch Panel Adjustment.] is touched? The touch sensors are not aligned on the touch panel. % Press the [1] key in the keypad. CS193/CS173/CS163 4-21...
  • Page 178 Touch [Close] or press the [Accessibility] key. The Basic screen appears again. Note If the touch panel cannot be adjusted, contact the service representative. Detail To cancel the touch panel adjustment, press the [Stop] key or the [Reset] key. 4-22 CS193/CS173/CS163...

  • Page 179: Setting The Key Repeat Start/Interval Time Functions

    Setting screen" on page 4-21. Touch [Key Repeat Start/Interval Time] or press the [2] key in the keypad. The Key Repeat Start/Interval Time screen appears. Touch [+] and [-] to specify the starting time and the interval for the key repeat feature. CS193/CS173/CS163 4-23...

  • Page 180: Setting The "System Auto Reset Confirmation" Function

    Display the Accessibility Setting screen. – For details on displaying the Accessibility Setting screen, refer to "Displaying the Accessibility Setting screen" on page 4-21. For details on the automatic system reset operation, refer to "Automatically conserving energy (Sleep mode)" on page 2-28. 4-24 CS193/CS173/CS163...
  • Page 181 The Enlarge Display mode is compatible with basic copy, scanning and fax functions. With the Enlarge Display mode, text and illustrations are displayed at a larger size so that they can be seen more easily. For details, refer to the User manual – Enlarge Display Operations. As the factory default, "No" is selected. CS193/CS173/CS163 4-25...

  • Page 182: Setting The "Auto Reset Confirmation" Function

    Display the Accessibility Setting screen. – For details on displaying the Accessibility Setting screen, refer to "Displaying the Accessibility Setting screen" on page 4-21. Touch [Auto Reset Confirmation] or press the [4] key in the keypad. The Auto Reset Confirmation screen appears. 4-26 CS193/CS173/CS163...
  • Page 183 If the time setting is the same for the automatic panel reset operation and the automatic system reset operation, the display of the message requesting confirmation to exit Enlarge Display mode is given priority and the message requesting confirmation to reset the settings in Enlarge Display mode is not displayed. CS193/CS173/CS163 4-27...

  • Page 184: Setting The "Enlarge Display Mode Confirmation" Function

    For details on displaying the Accessibility Setting screen, refer to "Displaying the Accessibility Setting screen" on page 4-21. Touch [Enlarge Display Mode Confirmation] or press the [5] key in the keypad. The Enlarge Display Mode Confirmation screen appears 4-28 CS193/CS173/CS163...
  • Page 185 Display mode, text and illustrations are displayed at a larger size so that they can be seen more easily. For details on the Enlarge Display mode, refer to the User manual – Enlarge Display Operations. If "OFF" is selected in the Enlarge Display Mode Confirmation screen, the screen is not displayed. CS193/CS173/CS163 4-29...

  • Page 186: Setting The "Message Display Time" Function

    – To cancel changes to the settings, press the [Reset] key. All changes to the settings are canceled. Touch [OK]. The Accessibility Setting screen appears again. Touch [Close] or press the [Accessibility] key. The Basic screen appears again. 4-30 CS193/CS173/CS163...

  • Page 187: Setting The "Sound Setting" Functions

    – For details on displaying the Accessibility Setting screen, refer to "Displaying the Accessibility Setting screen" on page 4-21. Touch [Sound Setting] or press the [2] key in the keypad. The Sound Setting screen appears. CS193/CS173/CS163 4-31...
  • Page 188 To cancel changes to the settings, press the [Reset] key. All changes to the settings are canceled. Touch [OK]. The Sound Setting screen appears again. Touch [Close]. The Accessibility Setting screen appears again. Touch [Close] or press the [Accessibility] key. The Basic screen appears again. 4-32 CS193/CS173/CS163...

  • Page 189: Troubleshooting

    Troubleshooting...

  • Page 191: When An Error Code Appears

    Display in Enlarge Display mode If the internal error occurs, the screen shown below appears. Reminder Since the machine may be damaged, contact the service representative according to the procedure described below as soon as the call service representative screen appears. CS193/CS173/CS163...
  • Page 192 Write down the trouble code (for example, C-0001) in the call service representative screen. Turn the machine off by using the [Power] (auxiliary power) key and the main power switch. Unplug the machine. Contact the service representative, and inform them of the trouble code. CS193/CS173/CS163...

  • Page 193: When The Message "Misfeed Detected." Appears

    If a paper misfeed occurs, the screen shown below appears. Note The procedure for clearing misfed paper differs depending on where the misfeed occurs. Determine the misfeed location by looking at the illustration displayed with the error message, and then clear the misfeed according to the appropriate procedure. CS193/CS173/CS163...

  • Page 194: Paper Misfeed Indications

    The illustration above shows the main unit with optional finisher, mailbin kit and the double paper feed cabinet installed. The illustration above shows optional finisher, saddle stitcher and the LCT installed. The illustration above shows optional separator and the double paper feed cabinet installed. CS193/CS173/CS163...
  • Page 195 Paper misfeed in tray 4 (p. 5-35) Paper misfeed in the finisher (p. 5-42) Paper misfeed in a mailbin (p. 5-44) Paper misfeed in the LCT (p. 5-36) Paper misfeed in the saddle stitcher (p. 5-46) Paper misfeed in separator (p. 5-47) CS193/CS173/CS163...

  • Page 196: Clearing A Paper Misfeed In The Adf (Feed Section)

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Remove all original pages remaining in the original feed tray. Open the left-side cover. Raise the original feed tray as far as possible. CS193/CS173/CS163...
  • Page 197 When pulling out misfed paper, be sure to pull it in the feed direction. Return the original feed tray to its original position. Close the left-side cover. Load the original into the original feed tray according to the instructions that appear on the screen. CS193/CS173/CS163...

  • Page 198: Clearing A Paper Misfeed In The Adf (Transport Section)

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Remove all original pages remaining in the original feed tray. Open the left-side cover. Raise the original feed tray as far as possible. 5-10 CS193/CS173/CS163...
  • Page 199 If the misfeed occurred with the second side of a double- sided original, open the transparent guide in the left-side cover, and then turn misfeed-clearing dial 2 in the direction of the arrow to feed out the page. Misfeed-clearing dial 2 CS193/CS173/CS163 5-11...
  • Page 200 Troubleshooting Return the original feed tray to its original position. Close the left-side cover. Load the original into the original feed tray according to the instructions that appear on the screen. 5-12 CS193/CS173/CS163...

  • Page 201: Clearing A Paper Misfeed In The Adf (Scanning Section)

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Remove all original pages remaining in the original feed tray. Open the left-side cover. Raise the original feed tray as far as possible. CS193/CS173/CS163 5-13...
  • Page 202 If the edge of the paper is not visible in the original output tray, open the guide and pull out the edge of the paper, and then turn misfeed-clearing dial 1 in the direction of the arrow to feed out the original page. 5-14 CS193/CS173/CS163...
  • Page 203 Troubleshooting Close the ADF. Return the original feed tray to its original position. Close the left-side cover. Load the original into the original feed tray according to the instructions that appear on the screen. CS193/CS173/CS163 5-15...

  • Page 204: Clearing A Paper Misfeed In The Adf (Output Section)

    Remove all original pages remaining in the original feed tray. Raise the original feed tray as far as possible, and then slowly pull out any misfed original pages. If the misfed paper could not be removed, open the ADF. 5-16 CS193/CS173/CS163...
  • Page 205 Close the ADF. Return the original feed tray to its original position. Load the original into the original feed tray according to the instructions that appear on the screen. CS193/CS173/CS163 5-17...

  • Page 206: Clearing A Paper Misfeed In The Adf (Turnover Section)

    Raise the original output tray as far as possible, and then pull out any misfed original pages. – Raise the original feed tray as far as possible, and then raise the original output tray as far as possible. 5-18 CS193/CS173/CS163...
  • Page 207 Return the original output tray to its original position. Return the original feed tray to its original position. Load the original into the original feed tray according to the instructions that appear on the screen. CS193/CS173/CS163 5-19...

  • Page 208: Clearing A Paper Misfeed In The Fusing Unit

    If the paper cannot be removed by pulling it down, open the fusing unit, and then pull it up. – If the paper is zigzag folded and jammed in the fusing unit, open the fusing unit, and then remove the paper. 5-20 CS193/CS173/CS163...
  • Page 209 The area around the fusing unit is extremely hot. %Touching anything other than the indicated levers and dials may result in burns. If you get burnt, immediately cool the skin under cold water, and then seek professional medical attention. Fusing unit CS193/CS173/CS163 5-21...
  • Page 210 Decreased image quality may result if the surface of the image transfer belt or image transfer roller is touched. Be careful not to touch the surface of the image transfer belt or the image transfer roller. Image transfer belt Image transfer roller Be careful not to touch the film with your hands. 5-22 CS193/CS173/CS163...

  • Page 211: Clearing A Paper Misfeed In The Main Unit

    If the edge of the paper is around the timing roller, open the internal cover M1. Slowly remove any misfed paper from the timing roller. – Toner that did not pass through the fusing unit may get on your hands or clothes. Be extremely careful when removing the paper. CS193/CS173/CS163 5-23...
  • Page 212 The area around the fusing unit is extremely hot. %Touching anything other than the indicated levers and dials may result in burns. If you get burnt, immediately cool the skin under cold water, and then seek professional medical attention. Fusing unit 5-24 CS193/CS173/CS163...

  • Page 213: Clearing A Paper Misfeed In The Automatic Duplex Unit

    Be careful not to touch the film with your hands. 5.2.10 Clearing a paper misfeed in the automatic duplex unit Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Open the door of the automatic duplex unit. CS193/CS173/CS163 5-25...
  • Page 214 Slowly remove any misfed paper from the automatic duplex unit. Close the door of the automatic duplex unit. Pull out the tray being used. Remove any misfed paper. Close the tray. Reminder Be careful not to touch the film with your hands. 5-26 CS193/CS173/CS163...

  • Page 215: Clearing A Paper Misfeed In The Bypass Tray

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Remove the paper from the bypass tray. Open the upper right-side door. Open the internal cover M1. Slowly remove any misfeed paper. CS193/CS173/CS163 5-27...
  • Page 216 Be careful not to spill toner inside the machine or get toner on your clothes or hands. If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. 5-28 CS193/CS173/CS163...

  • Page 217: Clearing A Paper Misfeed In The Paper Transport Section

    Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Pull up the center right-side door release lever, and then open the center right-side door. Carefully pull out any misfed paper. CS193/CS173/CS163 5-29...
  • Page 218 Troubleshooting Close the center right-side door. Pull out the tray being used. Remove any misfed paper. Close the tray. Reminder Be careful not to touch the film. 5-30 CS193/CS173/CS163...

  • Page 219: Clearing A Paper Misfeed In Tray 1

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Pull up the upper right-side door release lever, and then open the upper right-side door. Open the internal cover M1. Carefully pull out any misfed paper. Close the upper right-side door. CS193/CS173/CS163 5-31...
  • Page 220 Be careful not to spill toner inside the machine or get toner on your clothes or hands. If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. 5-32 CS193/CS173/CS163...

  • Page 221: Clearing A Paper Misfeed In Tray 2

    Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Pull up the center right-side door release lever, and then open the center right-side door. Carefully pull out any misfed paper. CS193/CS173/CS163 5-33...
  • Page 222 Troubleshooting Close the center right-side door. Pull out tray 2. Remove any misfed paper. Close the tray. Reminder Be careful not to touch the film. 5-34 CS193/CS173/CS163...

  • Page 223: Clearing A Paper Misfeed In Paper Feed Cabinet (Tray 3/4)

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Pull up the lower right-side door release lever, and then open the lower right-side door. Carefully pull out any misfed paper. Close the lower right-side door. Pull out paper tray. CS193/CS173/CS163 5-35...

  • Page 224: Clearing A Paper Misfeed In The Lct

    Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Pull up the lower right-side door release lever, and then open the lower right-side door. Carefully pull out any misfed paper. 5-36 CS193/CS173/CS163...
  • Page 225 Troubleshooting Close the lower right-side door. Press the tray release button, and then pull out the LCT. Remove any misfed paper. Close the LCT. Reminder Be careful not to touch the film. CS193/CS173/CS163 5-37...

  • Page 226: To Clear A Banner Paper Misfeed

    – If the end of the paper cannot be seen or cannot be grabbed, pull out the paper in the direction of the arrow. Open inside cover M1. Pull out any paper caught in the timing roller section. 5-38 CS193/CS173/CS163...
  • Page 227 Troubleshooting Push up the fusing unit, and then pull out any misfed paper. Open the fusing unit cover M2. Pull out any misfed paper. Pull out any paper caught in the fusing unit. CS193/CS173/CS163 5-39...
  • Page 228 Troubleshooting Close the fusing unit cover M2. Close the fusing unit. Close the upper right-side door. 5-40 CS193/CS173/CS163...
  • Page 229 Decreased image quality may result if the surface of the image transfer belt or the image transfer roller is touched. Be careful not to touch the surface of the image transfer belt or the image transfer roller. Image transfer belt Image transfer roller CS193/CS173/CS163 5-41...

  • Page 230: Clearing A Paper Misfeed In Finisher

    To move the finisher away from the main unit, be sure to grab it at "2". Do not grab the mailbins or saddle stitcher to move the finisher, otherwise they may be damaged. Open the front door. Raise lever FN1, turn dial FN2, and then pull out any paper. 5-42 CS193/CS173/CS163...
  • Page 231 If the punch kit is installed, insert the hole-punch waste container FN3.1 into its original position. Turn dial FN4 to feed the paper, open the transport unit cover, and then pull out any paper. Turn dial FN5 or dial FN6, and then pull out any paper. CS193/CS173/CS163 5-43...

  • Page 232: Clearing A Paper Misfeed In The Mailbin

    5.2.19 Clearing a paper misfeed in the mailbin Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Open the front door. 5-44 CS193/CS173/CS163...
  • Page 233 Turn dial FN5 or dial FN6 to feed out the paper. While pressing down lever FN7, pull out any paper. Pull handle FN8 to open the misfeed-clearing door. Pull out any paper in the mailbin. Close the misfeed-clearing door. Close the front door. CS193/CS173/CS163 5-45...

  • Page 234: Clearing A Paper Misfeed In The Saddle Stitcher

    For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Open the front door. Turn dial FN5 or dial FN6 to feed out the paper. Remove all paper from the finishing tray. Open the misfeed-clearing door, and then pull out any paper. 5-46 CS193/CS173/CS163...

  • Page 235: Clearing A Paper Misfeed In The Separator

    Clearing a paper misfeed in the separator Detail For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6. Open the misfeed-clearing cover. Turn the dial to feed out the paper. Pull out the paper from the output tray. CS193/CS173/CS163 5-47...
  • Page 236 Troubleshooting Close the misfeed-clearing cover. 5-48 CS193/CS173/CS163...

  • Page 237: When The Message "Unable To Staple." Appears

    Troubleshooting When the message "Unable to staple." appears If a staple jam occurs in the finisher, the message shown below appears. Display in Enlarge Display mode Reminder Be careful when clearing jammed staples since injuries may result. CS193/CS173/CS163 5-49...

  • Page 238: Clearing Jammed Staples In Finisher

    Remove all paper from the finisher. Open the front door. Turn the dial to the left to move the stapler toward the front. Remove the staple cartridge holder. – Pull the staple cartridge holder toward you to remove it. 5-50 CS193/CS173/CS163...
  • Page 239 Insert the staple cartridge holder, sliding it along the rails in the compartment. – Check that the staple cartridge holder is securely inserted as far as possible. Close the front door. Reminder If stapling still cannot be resumed, even after performing the above procedure, contact your service representative. CS193/CS173/CS163 5-51...

  • Page 240: Clearing Jammed Staples In The Saddle Stitcher

    Raise the output tray, and then push down the staple cartridge holder to remove it. Raise the shutter of the staple cartridge holder, and then pull out one sheet of staples. Return the shutter of the staple cartridge holder to its original position. 5-52 CS193/CS173/CS163...

  • Page 241: When The Message "Replenish Paper." Appears

    Check which paper tray is indicated in color, and then load it with paper. Detail For details on loading paper, refer to "Loading paper into tray 1/2/3/4" on page 2-43, and "Loading paper into the LCT" on page 2-45, and "Loading paper into the bypass tray" on page 2-47. CS193/CS173/CS163 5-53...

  • Page 242: When The Message

    If the amount of memory available becomes limited while copy operations are being performed, the scanned job is erased. Check the number of pages counted for the original, and then adjust the number of pages in the original to be scanned. 5-54 CS193/CS173/CS163...

  • Page 243: When The Message "Please Replace Following Unit(S)." Appears

    The number of pages that can be printed after the message "Please replace following unit(s)." appears and before the message "XXXX needs to be replaced." appears differs depending on the printing conditions, the consumables and the part to be replaced. CS193/CS173/CS163 5-55...

  • Page 244: When The Message "Xxxx Needs To Be Replaced." Appears

    Note When the message appears, replace the specified consumables or part according to your maintenance agreement. Detail Do not throw away used consumables or parts. Instead, keep them in their boxes to be collected by your service representative. 5-56 CS193/CS173/CS163...

  • Page 245: When The Message "Now Remote Operating. Please Do Not Turn Off The Power." Appears

    This message appears when the machine is being accessed in Administrator mode of Web Connection. Reminder Do not turn off the machine while this message is displayed. After access to the machine with Web Connection has ended, the Basic screen appears again. CS193/CS173/CS163 5-57...

  • Page 246: Simple Troubleshooting

    Touch [Light] on the Back- ground Removal screen to select a lighter background density. (See p. 3-53.) Is the electrostatic charger wire Use the charger-cleaning tool to dirty? clean the electrostatic charger. (See p. 10-5.) 5-58 CS193/CS173/CS163...
  • Page 247 Is the original one that does not Check that the original is one that meet the specifications? can be loaded into the ADF. (See p. 7-21 and p. 7-22.) Is the original correctly loaded? Position the original correctly. (See p. 3-8.) CS193/CS173/CS163 5-59...
  • Page 248 (when the punch kit is installed on the finisher) If any message other than those listed above appears, perform the operation described in the message. If the problem is not corrected after the described operation is performed, contact your service representative. 5-60 CS193/CS173/CS163...

  • Page 249: Main Messages And Their Remedies

    Service Rep. your service representative with the An internal error occurred. Turn the error code displayed on the screen. main switch OFF and ON. If the trou- ble code appears again, contact your Service Rep. CS193/CS173/CS163 5-61...
  • Page 250 Turn off the main power switch, and tion attempts have failed the then wait about 10 seconds before specified number of times. turning it on again. If any message other than those listed above appears, perform the operation described in the message. 5-62 CS193/CS173/CS163...

  • Page 251: Specifications

    Specifications...

  • Page 253: Main Unit

    Specifications Specifications Specifications 6.1.1 Main unit Specifications CS163 CS173 CS193 Type Desktop/freestanding scanner/printer Original holder Stationary (mirror scanning) Photoconductor Luminous source White inert gas fluorescent lamp Copying system Laser electrostatic copy method Developing system Dry-type dual-component HMT developing method Fusing system...

  • Page 254: Automatic Duplex Unit

    Specifications Specifications CS163 CS173 CS193 Copy speed Full color: 20.0 ppm (single- Full color: 25.0 ppm (single- Full color: 35.3 ppm (single- sided), 20.0 sides/min. (dou- sided), 25.0 sides/min. (dou- sided), 34.6 sides/min. (dou- ble-sided) ble-sided) ble-sided) Black: 20.0 ppm (single-sid- Black: 25.0 ppm (single-sid-...

  • Page 255: Automatic Document Feeder Df-611

    There are five Foolscap sizes: 220 e 330 mm w, 8-1/2 e 13 w, 8-1/4 e 13 w, 8-1/8 e 13-1/4 w and 8 e 13 w. Any one of these sizes can be selected. For details, contact your service representative. CS193/CS173/CS163...

  • Page 256: Paper Feed Cabinet Pc-204

    ), OHP, postcards, envelopes, or label sheets, letterheads: 20 sheets Amount of shift 30 mm Staple settings Paper sizes (no. of bound pages): A3 w to A5 v (Plain paper: 2 to 50 sheets/Thick paper1: 2 to 30 sheets) CS193/CS173/CS163...

  • Page 257: Punch Kit Pk-515

    Plain paper (50 to 90 g/m Paper sizes A4 v, B5 v, A5 w Paper capacity Maximum 125 sheets per bin Dimensions 340 mm (W) e 509 mm (D) e 387 mm (H) Weight Approx. 8 kg (unit weight) Power requirements Supplied from finisher CS193/CS173/CS163...

  • Page 258: Job Separator Js-505

    A3 w to B5 w, 11 e 17 w to 8-1/2 e 11w/v Dimensions 413 mm/500 mm (Length in parentheses is with the paper tray pulled out) (W) e 477 mm (D) e 129 mm (H) Weight Approx. 5 kg CS193/CS173/CS163...

  • Page 259: Copy Paper/Originals

    Copy paper/originals...

  • Page 261: Copy Paper

    There are five Foolscap sizes: 220 e 330 mm w, 8-1/2 e 13 w, 8-1/4 e 13 w, 8-1/8 e 13-1/4 w and 8 e 13 w. Any one of these sizes can be selected. For details, contact your service representative. Can be used when the optional punch kit is installed on the finisher. CS193/CS173/CS163...

  • Page 262: Paper Types And Paper Capacities

    Paper setting is specified. Thick 2 Select this setting when the thick paper that is loaded has a weight of 151 to 209 g/m A paper tray with this setting is not automatically selected when the "Auto" Paper setting is specified. CS193/CS173/CS163...

  • Page 263: Precautions For Paper

    Paper that has not been loaded should be kept wrapped or placed in a plastic bag and stored in a cool, dark location with little humidity. Store the paper laying flat, not standing on its edge. Curled paper may cause paper misfeeds. Keep paper out of the reach of children. CS193/CS173/CS163...

  • Page 264: Auto Tray Switch Feature

    % Bypass tray Appears only when the optional paper feed cabinet is installed. Appears only when the optional LCT is installed. Detail To change the order in which the paper trays are selected, refer to "System Settings" on page 12-23. CS193/CS173/CS163...

  • Page 265: Selecting The Paper Settings

    In the Basic screen, touch [Paper]. The Paper screen appears. Touch the button for tray 1. – To select the automatic paper detection setting for tray 2/3/4 or the bypass tray, touch the button for the corresponding paper tray. Touch [Change Tray Settings]. CS193/CS173/CS163...

  • Page 266: Selecting A Paper Size Setting (Size Setting)

    This is useful, for example, when the size of the paper that is loaded cannot be automatically detected (such as with postcards or paper in inch sizes). The following procedure describes how to specify the setting for postcards loaded into the bypass tray. In the Basic screen, touch [Paper]. The Paper screen appears. CS193/CS173/CS163...
  • Page 267 Copy paper/originals Select the button for the bypass tray. Touch [Change Tray Settings]. Touch [Standard Size]. The Standard Size screen appears. Touch twice, and then touch [A6Cardw]. – Touch until the button for the desired paper size is displayed. CS193/CS173/CS163...

  • Page 268: Specifying A Non-Standard Paper Size (Custom Size Settings)

    Non-standard-sized paper can be loaded into the bypass tray. If wide paper is loaded, it will be necessary to enter the paper size. In the Basic screen, touch [Paper]. The Paper screen appears. Select the button for the bypass tray. 7-10 CS193/CS173/CS163...
  • Page 269 % For details on storing paper sizes, refer to "Storing a non-standard paper size (Custom Size settings)" on page 7-12. Touch [OK], and then touch [OK] in the next two screens that appear. The Basic screen appears again. CS193/CS173/CS163 7-11...

  • Page 270: Storing A Non-Standard Paper Size (Custom Size Settings)

    Storing paper sizes that are used often allows the paper size to be quickly selected, without having to re- enter the setting. In the Basic screen, touch [Paper]. The Paper screen appears. Select the button for the bypass tray. Touch [Change Tray Settings]. 7-12 CS193/CS173/CS163...
  • Page 271 If a value outside the allowable range is specified, the message "Input error" appears. Type a value within the allowable range. – If the value was incorrectly entered, press the [C] (clear) key in the keypad to erase the value, and then specify the correct value. To cancel changes to the settings, touch [Cancel]. CS193/CS173/CS163 7-13...
  • Page 272 Using the keyboard that appears, type in the name of the key, touch [OK], and then touch [Close]. For details on typing in text, refer to "Entering text" on page 13-3. Touch [OK], and then touch [OK] in the next three screens that appear. The Basic screen appears again. 7-14 CS193/CS173/CS163...

  • Page 273: Selecting A Setting For Oversized Paper (Wide Paper Settings)

    In the Basic screen, touch [Paper]. The Paper screen appears. Touch the button for the bypass tray. – To set the paper size for tray 1/2/3/4, touch the button for the corresponding paper tray. Touch [Change Tray Settings]. CS193/CS173/CS163 7-15...
  • Page 274 In addition, do not enter the same size for "X" and "Y". – If the value was incorrectly entered, press the [C] (clear) key in the keypad to erase the value, and then specify the correct value. 7-16 CS193/CS173/CS163...

  • Page 275: Specifying A Setting For Special Paper

    If paper other than plain paper, such as OHP transparencies or special paper, is loaded in a paper tray, be sure to change the paper type setting for that tray. The following procedure describes how to specify the setting for special paper loaded into tray 1. In the Basic screen, touch [Paper]. The Paper screen appears. CS193/CS173/CS163 7-17...
  • Page 276 Touch [OK], and then touch [OK] in the next screen that appears. The Basic screen appears again. Reminder If special paper is loaded into the paper tray, be sure to select the corresponding paper type, otherwise a paper misfeed may occur. 7-18 CS193/CS173/CS163...

  • Page 277: Printing Double-Sided Copies Manually

    In the Basic screen, touch [Paper]. The Paper screen appears. Touch the button for the bypass tray. – A paper tray set to "2nd Side" is not selected when the "Auto" Paper setting is selected. Touch [Change Tray Settings]. CS193/CS173/CS163 7-19...
  • Page 278 Copy paper/originals Select the type of paper to be loaded. Touch [Duplex 2nd Side]. Touch [OK], and then touch [OK] in the next screen that appears. The Basic screen appears again. 7-20 CS193/CS173/CS163...

  • Page 279: Originals

    —: Not possible Detail Indicates the width of the widest original size of the mixed originals (width of the adjustable lateral guides of the automatic document feeder). Indicates original sizes that can be specified together with the maximum original width. CS193/CS173/CS163 7-21...

  • Page 280: Precautions For Loading Originals Into The Adf

    Do not place objects exceeding 2 kg on the original glass, otherwise the original glass may be damaged. Do not press down extremely hard on a book spread on the original glass, otherwise the original glass may be damaged. 7-22 CS193/CS173/CS163...

  • Page 281: Application Functions

    Application functions...

  • Page 283: Color Adjust Parameters And Samples

    (p. 8-19) original (p. 8-21) Since the print samples provided are photographs, they may slightly differ in color with actual color copies. CS193/CS173/CS163...

  • Page 284: General Information About Color

    As opposed to hue and brightness, saturation is the characteristic that indicates the degree of vividness. CS193/CS173/CS163...
  • Page 285 2. Although the level of saturation differs for each hue and degree of brightness, creating a complex color model, we can get a better understanding of the conditions under which the hue, brightness and saturation vary. CS193/CS173/CS163...

  • Page 286: Red" Parameter

    Application functions 8.1.2 "Red" parameter This parameter can be used to adjust the degree of red in the image to one of 19 levels. For details on the setting procedure, refer to page 8-48. CS193/CS173/CS163...

  • Page 287: Green" Parameter

    Application functions 8.1.3 "Green" parameter This parameter can be used to adjust the degree of green in the image to one of 19 levels. For details on the setting procedure, refer to page 8-48. CS193/CS173/CS163...

  • Page 288: Blue" Parameter

    Application functions 8.1.4 "Blue" parameter This parameter can be used to adjust the degree of blue in the image to one of 19 levels. For details on the setting procedure, refer to page 8-48. CS193/CS173/CS163...

  • Page 289: Color Balance" Parameter (Cmyk Color Adjustment)

    Changing the amount of each color of toner enables the tints in the copy to be finely adjusted. Each color can be adjusted to any of 19 levels. For details on the setting procedure, refer to page 8-48. Adjusting the black tinge Increasing the amount of black Decreasing the amount of black Black CS193/CS173/CS163...
  • Page 290 Application functions 8-10 CS193/CS173/CS163...

  • Page 291: Brightness" Parameter

    Application functions 8.1.6 "Brightness" parameter This parameter can be used to finely adjust the brightness of the image to one of 19 levels. For details on the setting procedure, refer to page 8-48. CS193/CS173/CS163 8-11...

  • Page 292: Contrast" Parameter

    Application functions 8.1.7 "Contrast" parameter This parameter can be used to finely adjust the image to one of 19 levels between soft/smooth and crisp. For details on the setting procedure, refer to page 8-48. 8-12 CS193/CS173/CS163...

  • Page 293: Saturation" Parameter

    Application functions 8.1.8 "Saturation" parameter This parameter can be used to finely adjust the vividness of the image to one of 19 levels. For details on the setting procedure, refer to page 8-48. CS193/CS173/CS163 8-13...

  • Page 294: Sharpness" Parameter

    Application functions 8.1.9 "Sharpness" parameter This parameter can be used to adjust the amount of contours in text and images to one of 7 levels. For details on the setting procedure, refer to page 8-48. 8-14 CS193/CS173/CS163...

  • Page 295: Hue" Parameter

    Application functions 8.1.10 "Hue" parameter This parameter can be used to finely adjust the hue of the image to one of 19 levels. For details on the setting procedure, refer to page 8-48. CS193/CS173/CS163 8-15...

  • Page 296: Copy Density" Parameter

    Application functions 8.1.11 "Copy Density" parameter This parameter can be used to finely adjust the light and shading of the image to one of 19 levels. For details on the setting procedure, refer to page 8-48. 8-16 CS193/CS173/CS163...

  • Page 297: Single Color" Function

    This function allows you to copy an original using only one of the 21 colors available. For details on the setting procedure, refer to page 3-34. Sepia 1 Yellow Sepia 2 Magenta Camel Cyan Brown Forest Green Green Maroon Orange Copper Pumpkin Plum Yellow Green Purple Blue Pink Teal Aquamarine CS193/CS173/CS163 8-17...

  • Page 298: Color" Function

    This setting allows you to produce copies with the black areas of the original printed in black and the color areas of the original printed in one of the six colors available. For details on the setting procedure, refer to page 3-34. Cyan Green Magenta Blue Yellow 8-18 CS193/CS173/CS163...

  • Page 299: Background Color" Function

    This function allows you to copy an original using one of the 18 colors available as the color of the background (blank areas). For details on the setting procedure, refer to page 8-46. Yellow Camel Brown Magenta Cyan Forest Green Maroon Green Plum Purple Orange Pumpkin Pink Yellow Green Aquamarine Blue Teal CS193/CS173/CS163 8-19...

  • Page 300: Neg-/Pos. Reverse" Function

    For details on the setting procedure, refer to page 8-41. Monotone copy Sepia 1 Yellow Sepia 2 Magenta Camel Cyan Brown Forest Green Green Maroon Orange Copper Pumpkin Plum Yellow Green Purple Blue Pink Teal Aquamarine Full-color copy and "Background Color" function 8-20 CS193/CS173/CS163...

  • Page 301: Mirror Image" Function

    Application functions 8.1.16 "Mirror Image" function This function allows you to copy a mirror image of the original. For details on the setting procedure, refer to page 8-43. CS193/CS173/CS163 8-21...

  • Page 302: Inserting Paper Between Ohp Transparencies ("Ohp Interleave" Function)

    Use interleaf paper with the same size as the OHP transparencies. Select [Transparency] as the paper type for the bypass tray, and then touch [OK]. – For details on specifying the paper type settings, refer to "Specifying a setting for special paper" on page 7-17. 8-22 CS193/CS173/CS163...
  • Page 303 Touch [Application], and then touch [Sheet/Cover/Chapter Insert]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. Touch [OHP Interleave]. The OHP Interleave screen appears. CS193/CS173/CS163 8-23...
  • Page 304 To cancel the setting and select the default, press the [Reset] key. – To cancel the "OHP Interleave" function, touch [No]. Touch [OK]. Specify any other desired copy settings. – The number of copies is set to "1" and cannot be changed. Press the [Start] key. 8-24 CS193/CS173/CS163...

  • Page 305: Adding Cover Pages ("Cover Sheet" Function)

    Load the paper for the cover pages and the paper for the main body of the original into separate paper trays. – Use paper with the same size for the cover pages and for the main body of the original, and load them in the same orientation. CS193/CS173/CS163 8-25...
  • Page 306 7-4 and "Loading paper into the bypass tray" on page 2-47. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. Touch [Cover Sheet]. The Cover Sheet screen appears. 8-26 CS193/CS173/CS163...
  • Page 307 Select the paper tray loaded with the paper for the cover pages. Touch [OK], and then touch [OK] in the next two screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. CS193/CS173/CS163 8-27...

  • Page 308: Inserting Different Paper Into Copies ("Insert Sheet" Function)

    The specified paper can be inserted at a maximum of 30 locations within an original of up to 999 pages. In double-sided originals, one double-sided page is considered to be two pages (one for the front and one for the back). 8-28 CS193/CS173/CS163...
  • Page 309 7-4 and "Loading paper into the bypass tray" on page 2-47. – To cancel the setting and select the default, press the [Reset] key. The Sheet/Cover/Chapter Insert screen appears. Touch [Insert Sheet]. – To cancel the "Insert Sheet" function, touch [No]. The Insert Sheet screen appears. CS193/CS173/CS163 8-29...
  • Page 310 If "Blank" is selected, the specified paper is inserted after the specified page. Touch [OK], and then touch [OK] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-30 CS193/CS173/CS163...

  • Page 311: Inserting Copies Of A Different Original For A Specified Page ("Insert Image" Function)

    ("Separate Scan" setting)" on page 3-11. Touch [Application], and then touch [Sheet/Cover/Chapter Insert]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. CS193/CS173/CS163 8-31...
  • Page 312 Touch [OK], and then touch [OK] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. 8-32 CS193/CS173/CS163...
  • Page 313 Press the [Start] key. Scanning begins. Touch [Finish]. – To insert a multi-page original, repeat steps 9 and 10 until all pages of the insertion original are scanned in the order that they are to be inserted. Press the [Start] key. CS193/CS173/CS163 8-33...

  • Page 314: Specifying Pages To Be Printed On The Front Side ("Chapters" Function)

    Position the original to be copied. – For details on positioning the original, refer to "Feeding the original" on page 3-8. – For an original that exceeds 100 pages, refer to "Scanning the original in separate batches ("Separate Scan" setting)" on page 3-11. 8-34 CS193/CS173/CS163...
  • Page 315 To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. Touch [Chapters]. The Chapter screen (for editing) appears. Using the keypad, specify the first page of the chapters. CS193/CS173/CS163 8-35...
  • Page 316 [OK]. Touch [OK], and then touch [OK] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-36 CS193/CS173/CS163...

  • Page 317: Scanning Originals With Different Settings And Printing Copies All Together ("Program Jobs" Function)

    Touch [Application], and then touch [Sheet/Cover/Chapter Insert]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Sheet/Cover/Chapter Insert screen appears. CS193/CS173/CS163 8-37...
  • Page 318 Touch [Fix], and then touch [OK]. – If the original was loaded on the original glass, touch [Finish] in the screen that appears, requesting confirmation that scanning is finished. – If "Retry" was selected, touch [Change Setting] to change the copy settings. 8-38 CS193/CS173/CS163...
  • Page 319 Scanning begins. After scanning is finished, touch [Fix], and then touch [OK]. Is there more information about the settings? % Refer to the appropriate section. After all original pages have been scanned, touch [Finish]. A message appears, requesting confirmation that scanning is finished. CS193/CS173/CS163 8-39...
  • Page 320 If "No" was selected, touch [Change Setting] to change the copy settings. Specify any other desired copy settings. – Touch [Print List], and then specify the printing method for the entire scanned original. Is there more information about the settings? % Refer to the appropriate section. 8-40 CS193/CS173/CS163...

  • Page 321: Copying With Image Colors Inversed ("Neg./Pos. Reverse" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Edit Color]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. CS193/CS173/CS163 8-41...
  • Page 322 Touch [Neg./Pos. Reverse], and then touch [OK]. To cancel the "Neg./Pos. Reverse" function % Touch [Neg./Pos. Reverse] again. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-42 CS193/CS173/CS163...

  • Page 323: Copying In A Mirror Image ("Mirror Image" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Edit Color]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. Touch [Mirror Image]. CS193/CS173/CS163 8-43...
  • Page 324 If a non-standard-sized original is loaded, the original size cannot be detected. Therefore, specify the original size in the Custom Size screen, and then press the [Start] key. – To cancel the "Mirror Image" function, touch [No]. To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen 8-44 CS193/CS173/CS163...
  • Page 325 [C] (clear) key in the keypad, and then specify the correct value. Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. CS193/CS173/CS163 8-45...

  • Page 326: Adding A Background Color To Copies ("Background Color" Function)

    Touch [Application], and then touch [Edit Color]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. Touch [Background Color]. The Background Color screen appears. 8-46 CS193/CS173/CS163...
  • Page 327 To cancel the "Background Color" function, touch [No]. Can other background colors be displayed? % Touch to display a different list of colors. Touch [OK]. Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. CS193/CS173/CS163 8-47...

  • Page 328: Adjusting The Copy Color Quality (Color Adjust Parameters)

    Increasing the yellow tinge increases the amount of yellow or decreases the amount of magenta and cyan. • Increasing the black tinge increases the amount of black. Detail For sample images of the Color Adjust parameters, refer to "Color Adjust parameters and samples" on page 8-3. 8-48 CS193/CS173/CS163...

  • Page 329: To Adjust The Color Adjust Parameters

    Touch [Application], and then touch [Edit Color]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Edit Color screen appears. Touch [Color Adjust]. The Color Adjustment screen appears. CS193/CS173/CS163 8-49...
  • Page 330 Copy]. For details about proof copies, refer to "Checking the print result of the Color Adjust settings (Sample Copy)" on page 8-51. Note Even though the setting can be specified in 1/3-step increments, the setting will appear at the nearest full increment in the Color Adjustment screen. 8-50 CS193/CS173/CS163...

  • Page 331: Checking The Print Result Of The Color Adjust Settings (Sample Copy)

    The Sample Copy screen appears. Load paper of a size listed under "Paper that can be used" into the paper tray. Place the original within the sample area of the original glass. Press the [Start] key. The sample copy is printed. CS193/CS173/CS163 8-51...

  • Page 332: Producing Separate Copies Of Each Page In A Page Spread ("Book Copy" Function)

    How are the front and back covers copied? % Scan the front cover, then the back cover, and then scan the remainder of the original. Load the paper to be used into the desired paper tray. 8-52 CS193/CS173/CS163...
  • Page 333 To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Book Copy/Repeat screen appears. Touch [Book Copy]. – [Booklet Original] does not appear if optional finisher is not installed. The Book Copy screen appears. CS193/CS173/CS163 8-53...
  • Page 334 % The message "Input error" appears. If "Input error" appears or if the erased width was incorrectly entered, press the [C] (clear) key in the keypad, and then specify the correct value. Touch [OK], and then touch [Close]. 8-54 CS193/CS173/CS163...
  • Page 335 If "Front Cover" or "Front and Back Cover" is selected, continue with step 11. After all original pages have been scanned, touch [Finish]. – If "Front and Back Cover" was selected, the back cover is scanned after the front cover, and then all page spreads are scanned in order. CS193/CS173/CS163 8-55...
  • Page 336 Application functions – If "Front Cover" was selected, all page spreads are scanned in order after the front cover. Press the [Start] key. 8-56 CS193/CS173/CS163...

  • Page 337: Tiling Copy Images ("Image Repeat" Function)

    Load the paper to be used into the desired paper tray. Touch [Application], and then touch [Book Copy/Repeat]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Book Copy/Repeat screen appears. CS193/CS173/CS163 8-57...
  • Page 338 Under "Layout", touch [With Margin] or [Without Margin], or touch [2/4/8 Repeat]. – To cancel the "Image Repeat" function, touch [No]. – Touching [2/4/8 Repeat] displays the 2/4/8 Repeat screen, where the number of repeats and the interval can be selected. 8-58 CS193/CS173/CS163...
  • Page 339 Range], and then specify the scanning area from any of the screens. – Touch [Photo Size] to display the Photo Size screen. To cancel changes to the settings, touch [Cancel]. Set Range screen Custom Size screen Photo Size screen CS193/CS173/CS163 8-59...
  • Page 340 Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-60 CS193/CS173/CS163...

  • Page 341: Copying An Enlarged Image On Multiple Pages ("Poster Mode" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Book Copy/Repeat screen appears. Touch [Poster Mode]. – [Booklet Original] does not appear if optional finisher is not installed. The Poster Mode screen appears. CS193/CS173/CS163 8-61...
  • Page 342 Touching [Custom Size] displays the Custom Size screen. Touch [X] or [Y] to select the dimension, and then use the keypad to specify the desired value. – Touch [Paper Size], select the finished paper size, and then touch [OK]. – Touch to display a different list of paper sizes. 8-62 CS193/CS173/CS163...
  • Page 343 If the original size cannot be detected automatically or to specify the original size, touch [Original Size], and then specify the original size from any of the screens. – Touch [Photo Size] to display the Photo Size screen. To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen CS193/CS173/CS163 8-63...
  • Page 344 % The message "Input error" appears. If "Input error" appears or if the value was incorrectly entered, press the [C] (clear) key in the keypad, and then specify the correct value. Specify any other desired copy settings. – The number of copies is set to "1" and cannot be changed. Press the [Start] key. 8-64 CS193/CS173/CS163...

  • Page 345: Copying Booklets ("Booklet Original" Function)

    When using the original glass, position the pages in order, starting with the side that includes the first page, then the side that includes the second page, then the side that includes the third page. – When using the ADF, load the pages with the side that includes the first page on top. CS193/CS173/CS163 8-65...
  • Page 346 For details on scanning an original from the original glass, refer to "Scanning a multi-page original from the original glass" on page 3-15. After all original pages have been scanned, touch [Finish] and then press the [Start] key. 8-66 CS193/CS173/CS163...

  • Page 347: Adding A Binding Margin To Copies ("Page Margin" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Page Margin]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Page Margin screen appears. CS193/CS173/CS163 8-67...
  • Page 348 [C] (clear) key in the keypad, and then specify the correct value. How can the entered margin position be corrected? % Without changing the margin width, change the margin position. If necessary, touch [Image Shift]. The Image Shift screen appears. 8-68 CS193/CS173/CS163...
  • Page 349 For details on specifying the original orientation, refer to "Selecting the original orientation (Original Direction settings)" on page 3-24. Touch [OK]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. CS193/CS173/CS163 8-69...

  • Page 350: Adjusting The Image To Fit The Paper (Image Adjust Settings)

    If "Full Size" or "Center Zoom" is to be set, position the original on the original glass. Touch [Application], and then touch [Image Adjust]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Image Adjust screen appears. 8-70 CS193/CS173/CS163...
  • Page 351 If the original size cannot be detected automatically or to specify the original size, touch [Original Size], and then specify the original size from any of the screens. To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen CS193/CS173/CS163 8-71...
  • Page 352 [C] (clear) key in the keypad, and then specify the correct value. Specify any other desired copy settings. – To cancel the setting and select the default, press the [Reset] key. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-72 CS193/CS173/CS163...

  • Page 353: Copying With The Page Layout Of A Booklet ("Booklet" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Booklet]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. CS193/CS173/CS163 8-73...
  • Page 354 To cancel the setting and select the default, press the [Reset] key. – To cancel the "Booklet" function, touch [No]. Touch [OK]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-74 CS193/CS173/CS163...

  • Page 355: Erasing Specified Areas Of Copies ("Frame Erase" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Frame Erase screen appears. Touch the button for the desired position to be erased. – To cancel the setting and select the default, press the [Reset] key. CS193/CS173/CS163 8-75...
  • Page 356 % The message "Input error" appears. If "Input error" appears or if the erased width was incorrectly entered, press the [C] (clear) key in the keypad, and then specify the correct value. Touch [OK]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-76 CS193/CS173/CS163...

  • Page 357: Printing The Date/Time Or Page Number On Copies (Stamp/Composition Functions)

    For details on printing a copy protection stamp, refer to page 8-89. For details on printing a repeating stamp, refer to page 8-97. For details on printing an overlay, refer to page 8-108. For details on printing a header/footer, refer to page 8-109. CS193/CS173/CS163 8-77...

  • Page 358: Printing The Date/Time ("Date/Time" Function)

    Touch [Application], and then touch [Stamp/Composition]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Stamp/Composition screen appears. Touch [Date/Time]. The Date/Time screen appears. 8-78 CS193/CS173/CS163...
  • Page 359 The stamp will not be printed on blank pages inserted using the "Cover Sheet", "Insert Sheet" and "Chapters" functions. Can the time be omitted? % If "None" is selected, the time is not printed. Touch [Print Position], and then select the printing position. CS193/CS173/CS163 8-79...
  • Page 360 % The message "Input error" appears. If "Input error" appears or if the adjustment value was incorrectly entered, touch [No Adjustment] or press the [C] (clear) key, and then specify the correct value. If necessary, specify the other settings. – To specify the text color, touch [Text Color], and then select the color. 8-80 CS193/CS173/CS163...

  • Page 361: Printing The Page Number ("Page Number" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Stamp/Composition]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Stamp/Composition screen appears. CS193/CS173/CS163 8-81...
  • Page 362 To print multiple chapters, specify the first page of each chapter using the "Chapters" function.For details, refer to "Specifying pages to be printed on the front side ("Chapters" function)" on page 8-34. – To cancel the "Page Number" function, touch [No]. Select a setting under "Page Number Type". 8-82 CS193/CS173/CS163...
  • Page 363 What happens when a value outside of the allowable range is specified? % The message "Input error" appears. If "Input error" appears or if the adjustment value was incorrectly entered, touch [No Adjustment] or press the [C] (clear) key, and then specify the correct value. CS193/CS173/CS163 8-83...
  • Page 364 If "Do Not Print #" is selected, inserted pages are only counted, but page numbers are not printed on them. If "Skip the Page(s)" is selected, inserted pages are not counted and page numbers are not printed on them. – To specify the text color, touch [Text Color], and then select the color. 8-84 CS193/CS173/CS163...

  • Page 365: Printing Previously Registered Stamps ("Stamp" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Stamp/Composition]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Stamp/Composition screen appears. CS193/CS173/CS163 8-85...
  • Page 366 Select the desired setting under "Pages". – To print the stamp only on the front cover, touch [1st Page Only]. – The stamp will not be printed on blank pages inserted using the "Cover Sheet", "Insert Sheet" and "Chapters" functions. 8-86 CS193/CS173/CS163...
  • Page 367 What happens when a value outside of the allowable range is specified? % The message "Input error" appears. If "Input error" appears or if the adjustment value was incorrectly entered, touch [No Adjustment] or press the [C] (clear) key, and then specify the correct value. CS193/CS173/CS163 8-87...
  • Page 368 2 Color count of the Meter Count. If "Color" is set to "2 Color", copies where the second color is different from the stamp text color are included in the Full Color count of the Meter Count. 8-88 CS193/CS173/CS163...

  • Page 369: Printing Copy Protection Text ("Copy Protect" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Stamp/Composition]. – To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. The Stamp/Composition screen appears. Touch [Copy Protect]. CS193/CS173/CS163 8-89...
  • Page 370 Copy Protection Utility. – The selected copy protection text formats appear in a column at the center of the screen. Up to eight text lines can be combined. – Multiple registered stamps or preset stamps cannot be selected. 8-90 CS193/CS173/CS163...
  • Page 371 To print the serial number of this machine, touch [Yes] under "Serial Number". For details on specifying settings for the serial number, contact your service representative. – To print the copy distribution number, touch [Yes] under "Distribution Contorol Number". A distribution number between 1 and 99,999,999 can be specified. CS193/CS173/CS163 8-91...
  • Page 372 Text/Background Color: Black; Density: Std.; Copy Protect Pattern: Emboss Text; Text Size: Std.; Pattern Overwrite: Front (Overwrite); Background Pattern: Pattern 1 – The setting under "Pattern Contrast" in the Copy Protect Pattern screen can only be specified in single increments between –2 and +2. Text/Background Color screen Density screen 8-92 CS193/CS173/CS163...
  • Page 373 Application functions Copy Protect Pattern screen Text Size screen Pattern Overwrite screen CS193/CS173/CS163 8-93...
  • Page 374 If there are no more than four lines in the selected copy protection text, the angle can be changed. Position screen – If desired, touch [Change Pos./Delete] in the Position screen, and then change the arrangement of the text. 8-94 CS193/CS173/CS163...
  • Page 375 To add a space to the copy protection text, touch [Insert Space]. Touch either [Up] or [Down] to move the round mark that appeared beside the specified copy protection text type, and then touch [Insert]. Insert Space screen CS193/CS173/CS163 8-95...
  • Page 376 2 Color count of the Meter Count. If "Color" is set to "2 Color", copies where the second color is different from the color of the copy protection text are included in the Full Color count of the Meter Count. 8-96 CS193/CS173/CS163...

  • Page 377: Printing Repeating Stamps ("Stamp Repeat" Function)

    For details on positioning the original, refer to "Feeding the original" on page 3-8. Touch [Application], and then touch [Stamp/Composition]. – To cancel all settings for the Application functions, press the [Reset] key. The Stamp/Composition screen appears. Touch [Stamp Repeat]. The Stamp Repeat screen appears. CS193/CS173/CS163 8-97...
  • Page 378 – Multiple registered stamps or preset stamps cannot be selected. – Touching [Date/Time] displays the Stamp Repeat > Date/Time screen. Select the desired settings under "Date Type" and "Time Type", and then touch [OK]. 8-98 CS193/CS173/CS163...
  • Page 379 To print the serial number of this machine, touch [Yes] under "Serial Number". For details on specifying settings for the serial number, contact your service representative. – To print the copy distribution number, touch [Yes] under "Destribution Control Number". A distribution number between 1 and 99,999,999 can be specified. CS193/CS173/CS163 8-99...
  • Page 380 Detail Settings screen, and then change the setting in the screen that appears. – As the factory default, the following settings are selected. Text Color: Black; Density: Std.; Text Size: Std.; Pattern Overwrite: Font (Overwrite) Text Color screen Density screen 8-100 CS193/CS173/CS163...
  • Page 381 If there are no more than four lines in the selected repeating stamp, the angle can be changed. Position screen – If desired, touch [Change Pos./Delete] in the Position screen, and then change the arrangement of the text. CS193/CS173/CS163 8-101...
  • Page 382 Change Position screen – To add a space to the repeating stamp, touch [Insert Space]. Touch either [Up] or [Down] to move the round mark that appeared beside the specified repeating stamp type, and then touch [Insert]. Insert Space screen 8-102 CS193/CS173/CS163...

  • Page 383: Printing The Image Scanned First Overlapped By The Remaining Original Pages ("Overlay" Function)

    ("Overlay" function) Copies can be printed with the contents of the first scanned original page overlapped by the remaining original pages. In addition, a scanned original can be stored as a registered overlay and recalled and used later. CS193/CS173/CS163 8-103...
  • Page 384 – To cancel the "Overlay" function, touch [No]. The Overlay screen appears. Select the desired settings for "Pages" and [Color]. – To print the overlay image only on the first copied page, touch [1st Page Only] under "Pages". 8-104 CS193/CS173/CS163...
  • Page 385 To cancel changes to the settings, touch [Cancel]. Original Size screen Custom Size screen Photo Size screen Touch [Close]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. CS193/CS173/CS163 8-105...

  • Page 386: Saving A Scanned Image As A Registered Overlay ("Overlay" Function)

    [Overwrite]. – To delete a registered overlay, select a registered overlay, and then touch [Delete]. – After touching the button for the registered overlay, the date that the overlay was registered appears. The Image Name Registration screen appears. 8-106 CS193/CS173/CS163...
  • Page 387 Touch the buttons in the keyboard that appears in the screen to type. For details on typing in text, refer to "Entering text" on page 13-3. Touch [OK], and then touch [Close]. Specify any other desired copy settings. Press the [Start] key. The original is scanned, then saved as a registered overlay. CS193/CS173/CS163 8-107...

  • Page 388: Using A Registered Overlay ("Overlay" Function)

    After touching the button for the registered overlay, the date that the overlay was registered appears. Touch [OK] and then touch [Close] in the next screen that appears. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-108 CS193/CS173/CS163...

  • Page 389: Printing A Header/Footer ("Header/Footer" Function)

    To cancel changes to the settings for all Application functions, press the [Reset] key. All changes to the settings are canceled. – If no header/footer is registered in Administrator mode, [Header/Footer] does not appear. The Header/Footer screen appears. CS193/CS173/CS163 8-109...
  • Page 390 – To check or temporarily change the header/footer settings, touch [Check/Change Temporarily]. Touch [OK], and then touch [Close]. Specify any other desired copy settings. Using the keypad, type in the desired number of copies. Press the [Start] key. 8-110 CS193/CS173/CS163...

  • Page 391: Saving The Scanned Original In A User Box ("Save In User Box" Function)

    For details on the user box settings, refer to the User manual – Box Operations. Position the original to be copied. Touch [Application], and then touch [Save in User Box]. Touch [User Box]. A screen for selecting a user box appears. CS193/CS173/CS163 8-111...
  • Page 392 User boxes can be searched for by the first letter of their name. Touch [etc] or the button that includes the first letter of the user box name to display a list of user boxes starting with the selected letter. A user box can be selected from this screen. Touch [OK]. 8-112 CS193/CS173/CS163...
  • Page 393 For details on typing in text, refer to "Entering text" on page 13-3. Select whether or not a copy will also be printed when the data is saved. To print a copy, touch [Yes] beside "Save & Print". CS193/CS173/CS163 8-113...
  • Page 394 If [No] beside "Page Print" was selected, the data for the scanned original is saved in the specified user box. Detail For details on using documents saved in user boxes, refer to the User manual – Box Operations. 8-114 CS193/CS173/CS163...

  • Page 395: Replacing Toner Cartridges And Staple Cartridges And Emptying Punch Scrap Box

    Replacing toner cartridges and staple cartridges and emptying punch scrap box...

  • Page 397: Replacing The Toner Cartridge

    In addition, do not replace the toner cartridge for any color not indicated in the message. If toner other than black is empty, printing can continue in black. Touch [Continue Operation], and then select the job to be printed. CS193/CS173/CS163...
  • Page 398 Be careful not to spill toner inside the machine or get toner on your clothes or hands. If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. CS193/CS173/CS163...

  • Page 399: To Replace The Toner Cartridge

    5 to 10 times. – The toner within the toner cartridge may have become compacted. If it has, be sure to shake the toner cartridge until the toner is mostly broken up before installing the cartridge. CS193/CS173/CS163...
  • Page 400 Slowly pull out the charger-cleaning tool as far as possible. Next, slowly push in the charger-cleaning tool as far as possible. Repeat the above operations three times. Close the front door. Reminder When replacing the black toner cartridge, always clean the electrostatic charger wire. CS193/CS173/CS163...

  • Page 401: Replacing The Waste Toner Box

    When it is time to replace the waste toner box (and if it is replaceable by the user), the message "Waste toner box needs to be replaced. Replace it following the instructions." appears and the machine stops operating. CS193/CS173/CS163...
  • Page 402 Replacing toner cartridges and staple cartridges and emptying punch scrap box Display in Enlarge Display mode When it is almost time to replace the waste toner box, the screen shown below appears. When the time to replace the part is reached, the following screen appears. CS193/CS173/CS163...

  • Page 403: To Replace The Waste Toner Box

    Replacing toner cartridges and staple cartridges and emptying punch scrap box 9.2.1 To replace the waste toner box Open the machine’s front door. Lift up and remove the waste toner box. Install the new waste toner box. Close the front door. CS193/CS173/CS163...
  • Page 404 If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. Do not tilt the removed waste toner box, otherwise waste toner may spill. Do not throw away used waste toner boxes. Instead, keep them in their boxes to be collected by your service representative. 9-10 CS193/CS173/CS163...

  • Page 405: Replacing An Imaging Unit

    If it is time to replace an imaging unit other than the black imaging unit, printing can continue in black. Touch [Continue Operation], and then select the job to be printed. Detail For details on replacing the imaging unit, refer to "To replace the imaging unit" on page 9-13. CS193/CS173/CS163 9-11...
  • Page 406 Be sure to replace the imaging unit only after the message "Please replace following unit(s)." appears. In addition, do not replace the imaging unit of any color other than the one indicated in the message on the touch panel. 9-12 CS193/CS173/CS163...

  • Page 407: To Replace The Imaging Unit

    – Do not hold the top part of the imaging unit, otherwise the PC drum may be damaged, resulting in decreased image quality. CS193/CS173/CS163 9-13...
  • Page 408 Tilt the imaging unit to the left and lightly shake it twice in the direction of the tilt, and then tilt the unit to the right and lightly shake it twice in the direction of the tilt. Peel off the tape. 9-14 CS193/CS173/CS163...
  • Page 409 Do not insert the imaging unit into its compartment at an angle. – Make sure that the imaging unit is fully inserted into its compartment. Slowly pull out the handle of the protective sheet for the PC drum. Push the imaging unit until it bottoms. CS193/CS173/CS163 9-15...
  • Page 410 If your hands become soiled with toner, immediately wash them with soap and water. If toner gets in your eyes, immediately flush them with water, and then seek professional medical attention. Reminder Be careful not to touch the PC drum. 9-16 CS193/CS173/CS163...

  • Page 411: Replacing The Staple Cartridge

    When the staple cartridge is empty, the message "Replace staple cartridge." appears. Replace the staple cartridge. Display in Enlarge Display mode Reminder Be sure to replace the staple cartridge only after the message appears, otherwise the machine may be damaged. CS193/CS173/CS163 9-17...

  • Page 412: To Replace The Staple Cartridge In The Finisher

    Remove the empty cartridge from the staple cartridge holder. Load the new staple cartridge into the staple cartridge holder. – Do not remove the remaining staples, otherwise the machine will not be able to staple after the cartridge is replaced. 9-18 CS193/CS173/CS163...
  • Page 413 Check that the staple cartridge holder is securely installed. Close the front door. Reminder Replace the staple cartridge only after the message has appeared. If the staple cartridge is replaced before the message appears, the machine may be damaged. CS193/CS173/CS163 9-19...

  • Page 414: To Replace The Staple Cartridge In Saddle Stitcher

    Raise the copy output tray, and then push down the staple cartridge holder and remove it. Press in the area marked "PUSH" to unlock the staple cartridge holder. Remove the empty staple cartridge from the staple cartridge holder. 9-20 CS193/CS173/CS163...
  • Page 415 When inserting the staple cartridge holder, be sure to insert it so that it faces the correct direction. Return the copy output tray to its original position. Pull the handle of the misfeed-clearing door to open it, and then close it. CS193/CS173/CS163 9-21...

  • Page 416: Emptying The Punch Scrap Box

    The setting for emptying the punch scrap box should be specified by the service representative. For details, contact the service representative. The default setting is "Service". If a message appears, immediately contact the service representative. Screen when a Punch setting is selected 9-22 CS193/CS173/CS163...
  • Page 417 If the punch scrap box has become full while a job is being performed, the job being performed is paused. To continue the job, touch [Cancel Punching]. However, the continued job is printed without holes being punched. Display in Enlarge Display mode CS193/CS173/CS163 9-23...

  • Page 418: To Empty The Punch Scrap Box In The Finisher

    Follow the procedure described below to empty the punch scrap box. Open the front door. Pull out the punch scrap box FN3.1. Empty the punch scrap box. Insert the punch scrap box into its original position. Close the front door. 9-24 CS193/CS173/CS163...

  • Page 419: Care Of The Machine

    Care of the machine...

  • Page 421: Cleaning

    Never use solvents, such as benzene or thinner, to clean the housing. 10.1.2 Original glass Clean the surface of the original glass by wiping it with a soft, dry cloth. Reminder Never use solvents, such as benzene or thinner, to clean the original glass. CS193/CS173/CS163 10-3...

  • Page 422: Left Partition Glass

    Pressing too hard on a key in the control panel or on the touch panel may damage them. In addition, never use a mild household detergent, glass cleaner, benzene or thinner to clean the control panel or touch panel. 10-4 CS193/CS173/CS163...

  • Page 423: Original Pad

    Slowly pull out the charger-cleaning tool as far as possible. Next, slowly push in the charger-cleaning tool as far as possible. Repeat the above operations three times. Securely insert the charger-cleaning tool, and then close the front door. CS193/CS173/CS163 10-5...

  • Page 424: Print Head

    Remove the print head glass cleaning tool from the front door of the machine. Insert the print head glass cleaning tool into the print head cleaning opening, pull it out, and then repeat this back-and- forth movement twice or three times. 10-6 CS193/CS173/CS163...

  • Page 425: Viewing Counters (Meter Count)

    % Touch [Print List], select the paper size, and then press the [Start] key. Touch [Close], and then touch [Close] in the next screen that appears. The Basic screen appears again. Note The list of counters can be displayed even while the machine is copying or printing. CS193/CS173/CS163 10-7...

  • Page 426: Viewing The Coverage Rate

    The amount of toner that was used can be viewed in the Coverage Rate screen. Press the [Utility/Counter] key. Touch [Meter Count], and then touch [Check Details] in the left panel. The Meter Count screen appears. Touch [Coverage Rate]. 10-8 CS193/CS173/CS163...

  • Page 427: When The Message "It Is Time For The Scheduled Inspection Of The Device." Appears

    When the message "It is time for the scheduled inspection of the device." appears If the message "It is time for the scheduled inspection of the device." appears, contact your service representative and request a periodic maintenance inspection. CS193/CS173/CS163 10-9...
  • Page 428 Care of the machine 10-10 CS193/CS173/CS163...

  • Page 429: Managing Jobs

    Managing jobs...

  • Page 431: Overview Of Job List Screen

    *The values listed above are for reference and may differ from the actual values depending on other settings. When one job is finished being printed, the next queued job automatically begins. Note Up to 251 jobs, including print jobs, scanner transmission jobs, fax transmission jobs and received fax/save jobs, can be queued. CS193/CS173/CS163 11-3...

  • Page 432: Job List Screens

    Job History list. The types of jobs that can be selected differ depending on the selected tab. The function of each button in the Job List screens is described below. 11-4 CS193/CS173/CS163...
  • Page 433 (higher or lower in the printing order). [Close] button Touch to quit Job List mode and returns to the screen that was displayed before [Job List] was touched. Displayed when the Current Jobs list is displayed. CS193/CS173/CS163 11-5...
  • Page 434 With jobs listed as "Printing" in the Current Jobs list, a count of the number of Copies printed is displayed. Result (Job History list only) Displays the result of the operation (Job Complete, Deleted Due To Error, De- leted by User, Reset Modes). 11-6 CS193/CS173/CS163...

  • Page 435: Left Panel Job List

    As the factory default, the display for the sub display area is that when "Job Display Setting" is set to "List Display". For details on specifying the default display for the left panel and the display method for the left panel Job List, refer to "Custom Display Settings" on page 12-17. CS193/CS173/CS163 11-7...

  • Page 436: Performing Operations On Jobs

    – If an incorrect job was selected, select a different job or touch the button for the selected job again to deselect it. A message requesting confirmation to delete the job appears. 11-8 CS193/CS173/CS163...

  • Page 437: Checking Job Settings

    The upper number to the left of [ Back] indicates the number of the currently displayed screen. The lower number indicates the total number of screens. – To display the previous screen, touch [ Back]. To display the next screen, touch [Forward CS193/CS173/CS163 11-9...

  • Page 438: Checking Job Details

    Displayed only for jobs on the Currently Jobs list transmitted to multiple destinations Displayed only with external server authentication Touch [Job List] in the left panel, and then touch [Job Details]. The Job List screen appears. Display the list containing the job whose details are to be checked. 11-10 CS193/CS173/CS163...

  • Page 439: Displaying The Current Jobs List (Stored Jobs And Active Jobs)

    The Current Jobs list of received print jobs for Copy mode and Fax mode and for computer printing is displayed. Touch [Job List] in the left panel, and then touch [Job Details]. The Job List screen appears. Touch the button for the desired list. CS193/CS173/CS163 11-11...

  • Page 440: Displaying The Job History List

    The Job History list of the Print tab appears. Touch the button for the desired list. – Deleted Jobs: Displays only jobs that were deleted before they were finished. – Finished Jobs: Displays only jobs that were correctly completed. – All Jobs: Displays all jobs. 11-12 CS193/CS173/CS163...

  • Page 441: Printing A Proof Copy Of A Stored Job

    How is printing of a proof copy stopped? % Press the [Stop] key. Detail To change the settings, touch [Check Job Set.] in the Release Held Job screen. For details, refer to "Printing a stored job" on page 11-14. CS193/CS173/CS163 11-13...

  • Page 442: Printing A Stored Job

    If an incorrect job was selected, select a different job or touch the button for the selected job again to deselect it. – To continue without changing the specified copy settings, continue with step 5. Touch [Change Setting]. The Change Setting screen appears. 11-14 CS193/CS173/CS163...
  • Page 443 In the Release Held Job screen, touch [OK] or press the [Start] key. The stored job appears in the Current Jobs list and is printed. How is the removal of a job from the Held Jobs list stopped? % Touch [Cancel]. CS193/CS173/CS163 11-15...

  • Page 444: Increasing Printing Priority

    If an incorrect job was selected, select a different job or touch the button for the selected job again to deselect it. The selected job moves to the top of the list and printing of the job begins. How can the change in the printing priority be stopped? % Touch [Cancel]. 11-16 CS193/CS173/CS163...

  • Page 445: Utility Mode

    Utility mode...

  • Page 447: Overview Of Utility Mode Parameters

    [2] Custom Display Set- [1] Copier Settings Refer to "Custom Display tings Settings" on page 12-17. [2] Scan/Fax Settings [3] Copy Screen [4] Fax Active Screen [5] Color Selection Set- tings [6] Left Panel Display De- fault [7] Search Option Settings CS193/CS173/CS163 12-3...
  • Page 448 [5] XPS Settings [6] Print Reports [6] Change Password Changes the password for the user who is currently logged on. [7] Change E-Mail Address E-Mail Address Changes the e-mail ad- dress for the user who is currently logged on. 12-4 CS193/CS173/CS163...
  • Page 449 Refer to "Network Set- tings" on page 12-32. [2] NetWare Settings [3] HTTP Server Settings [4] FTP Settings [5] SMB Settings [6] LDAP Settings [7] E-Mail Settings [8] SNMP Settings [9] AppleTalk Settings [0] Bonjour Setting (next screen) CS193/CS173/CS163 12-5...
  • Page 450 [0] Diver Password En- cryption Setting [4] Check Consumable Print List Refer to "Check Consum- Life able Life" on page 12-39. [6] Banner Printing Allow For details on the banner printing, refer to the User Restrict manual – Print Operations. 12-6 CS193/CS173/CS163...

  • Page 451: Access Level

    Access permission levels can be set to one of six levels between 0 and 5, with the higher number indicating higher security. Note The access level that is set for user, destination, and group level on the Limiting Access to Destinations can be used when user authentication settings have been specified. CS193/CS173/CS163 12-7...

  • Page 452: Level Settings

    A destination can be registered in only one group. However, a user can be registered in multiple groups. Access Allow Level 3 User 1 Destination 1 User 3 User 2 Destination 2 12-8 CS193/CS173/CS163...

  • Page 453: Specifying A Group Setting

    The Create Group screen appears. Touch the button for the desired group, and then touch [Edit]. The Edit screen appears. Touch [Group Name]. – For details on typing in text, refer to "Entering text" on page 13-3. The Group Name screen appears. CS193/CS173/CS163 12-9...

  • Page 454: Specifying A Destination Level

    The User Authentication/Account Track screen appears. Touch [7 Limiting Access to Destinations]. The Limiting Access to Destinations screen appears. Touch [2 Apply Levels/Groups to Destinations]. The Apply Levels/Groups to Destinations screen appears. Touch the button for the desired destination. 12-10 CS193/CS173/CS163...
  • Page 455 Either an access permission level or an access permission group can be specified for each destination. – Only one access permission group can be specified for a single destination. – To specify the destination group, touch [Apply Group]. Touch the button for the desired group, and then touch [OK]. CS193/CS173/CS163 12-11...

  • Page 456: Specifying A User Level

    The "Public User Box" and "Personal User Box" settings appear only when access by a public user is permitted. – If use by a public user is permitted, "Public" appears as the user name. As the default, level 0 is specified. 12-12 CS193/CS173/CS163...
  • Page 457 Touch the button for a group, touch [Details], and then check the destinations and names of users belonging to that group. – To specify the user level, touch [Apply Level]. Touch [Yes], touch the button for the desired level, and then touch [OK]. CS193/CS173/CS163 12-13...

  • Page 458: Displaying The Destination Registration Screen

    The One-Touch/User Box Registration screen appears. Note To finish specifying settings in the Utility mode, press the [Utility/Counter] key. Otherwise, exit the Utility mode by touching [Close] in each screen until the screen for the Copy, Fax/Scan or Box mode appears. 12-14 CS193/CS173/CS163...

  • Page 459: Specifying User Settings

    Specify the desired length of time (between 2 and 240 min- 15 minutes utes) until the machine enters Power Save mode. Sleep Mode Settings Specify the desired length of time (between 2 and 240 min- 20 minutes utes) until the machine enters Sleep mode. CS193/CS173/CS163 12-15...
  • Page 460 The original size is determined to be A4, and copies are produced on A4-size paper. • Prohibit Copy: Copies cannot be produced since the original size cannot be detected. Before pressing the [Start] key, the paper tray (paper to be printed on) must be selected. 12-16 CS193/CS173/CS163...

  • Page 461: Custom Display Settings

    Shortcut keys for frequently used Application functions can be added to the Basic screen of Copy mode. Shortcut Key 2 Note If the image controller icon appears in the Basic screen on CS193/CS173, only one shortcut key for the Basic screen can be specified. Scan/Fax Settings Parameter...

  • Page 462: Copier Settings

    "Booklet" function is selected. • Auto Display Zoom Ratio: The following zoom ratios are specified. 2in1, Booklet: 70.7% 4in1: 50.0% 8in1: 35.3% • Off: The zoom ratio is not selected automatically. 12-18 CS193/CS173/CS163...
  • Page 463 Paper setting was selected is selected. • Default Tray: Tray 1 is used. Select Tray for Insert Sheet Select the default paper tray loaded with paper for the cov- Tray 2 er pages (front cover), inserted pages and chapter title pag- CS193/CS173/CS163 12-19...

  • Page 464: Scan/Fax Settings

    12.3.4 Scan/Fax Settings Parameter Description JPEG Compression Level Specify settings for scanning. For details, refer to the User manual – Network Scan/Fax/Network Fax Operations. Black Compression Level TWAIN Lock Time Default Scan/Fax Settings Compact PDF Compression Level 12-20 CS193/CS173/CS163...

  • Page 465: Printer Settings

    The e-mail address for the user who is currently logged on can be changed. This parameter appears only when a user other than a public user is logged on. Note [Change E-Mail Address] appears only if the "Administrator Security Levels" parameter in Administrator mode is set to "Level 2" CS193/CS173/CS163 12-21...

  • Page 466: Displaying The User Settings Screen

    The User Settings screen appears. Note To finish specifying settings in the Utility mode, press the [Utility/Counter] key. Otherwise, exit the Utility mode by touching [Close] in each screen until the screen for the Copy or Box mode appears. 12-22 CS193/CS173/CS163...

  • Page 467: Specifying Administrator Settings

    The "Bin Assignment" parameter is set to "Tray 2" only if the optional output tray is installed. Date/Time Settings Description Default Setting Specify the current date and time. In addition, the time zone can be set between -12:00 Time Zone: +00:00 and 13:00 (in 30-minute increments). CS193/CS173/CS163 12-23...
  • Page 468 Change Regis- Select whether or not to allow registered image Allow tered Overlay overlays to be changed. Restrict Op- Restrict Broad- Select whether to prevent multiple recipients from eration casting being specified for fax transmissions. 12-24 CS193/CS173/CS163...
  • Page 469 Select when a good result was not achieved after "Image Stabilization Mode" was select- Color Regis- Color Registration Adjust the color registration if color shifts can be tration Ad- Adjust (Yellow) seen in the print result. just Color Registration Adjust (Magenta) Color Registration Adjust (Cyan) CS193/CS173/CS163 12-25...
  • Page 470 [Finisher Adjustment] appears only when an optional finisher is installed. Only "Black Image Density" is available for OHP transparencies. List/Counter Parameter Description Management List Job Settings List The machine settings can be printed. Paper Size/Type Counter Store combinations of paper sizes and paper types to be counted. 12-26 CS193/CS173/CS163...
  • Page 471 Enlarge Display mode, the System Auto Reset function is not activated. If user authentication settings have been specified or "Enhanced Security Mode" has been set to "ON", the logoff from Administrator mode or user authentication mode will be performed according to the "System Auto Reset Time" parameter. CS193/CS173/CS163 12-27...

  • Page 472: Administrator/Machine Settings

    As the factory default, the machine name is specified as "KMBT_C203/C253/C353". The registered e-mail address is used with Internet faxing. Note When entering the device name while registering the machine address, do not use characters that cannot be used by the operating system. 12-28 CS193/CS173/CS163...

  • Page 473: One-Touch/User Box Registration

    • Ticket Hold Time Setting: Specify the desired length of holding time (between 1 and 60 minutes) of Kerveros authentication ticket. The holding time setting is applied when Active Directory is selected as the authentication server type. CS193/CS173/CS163 12-29...
  • Page 474 This parameter appears only if user authentication or account track settings have been Tray 1/1-Sided specified. The use for each user or account can be checked. External Server Settings Description Specify the external server that performs user authentication. 12-30 CS193/CS173/CS163...
  • Page 475 The authentication units of the IC card type and the biometric type cannot be installed at the same time. Using Touch & Print, a user can print a job sent from a computer by positioning their finger or IC card on the authentication unit CS193/CS173/CS163 12-31...

  • Page 476: Network Settings

    Operation for printing while a copy operation is being performed. • Accept: Print data and fax data can be accepted and printed. • Receive Only: Print data and fax data is printed after the copy operation is finished. 12-32 CS193/CS173/CS163...

  • Page 477: Printer Settings

    [8 Fax Settings] appears only when the fax kit is installed or when Internet fax functions are available. 12.4.9 System Connection Parameter Description Open API Settings Specify settings for registering network connections. For details, refer to the User manual – Network Scan/Fax/Network Fax Operations. CS193/CS173/CS163 12-33...

  • Page 478: Security Settings

    "Mode 2", this parameter is set to "Mode 2". Mode 1: Type in the ID and password for the confidential doc- ument, and then select the document. Mode 2: Enter the Secure Print ID, select the document, and then enter the password for authentication. 12-34 CS193/CS173/CS163...
  • Page 479 HDD Lock Password Specify the password for protecting data on the hard disk. For details, refer to the User manual – Box Operations. Format HDD Format the hard disk. For details, refer to the User manual – Box Operations. CS193/CS173/CS163 12-35...
  • Page 480 Select whether or not stamps registered for copy protection can be deleted. Driver Password Encryption Setting Description Default Setting The encryption password Use Factory Default for the printer driver can be changed. For details, refer to the User manual – Print Operations. 12-36 CS193/CS173/CS163...

  • Page 481: Displaying The Administrator Settings Screen

    An item can also be selected by pressing the key in the keypad for the number beside the desired button. For [3 Administrator Setting], press the [3] key in the keypad. Type in the administrator password, and then touch [OK]. – For details on typing in text, refer to "Entering text" on page 13-3. CS193/CS173/CS163 12-37...
  • Page 482 The default administrator password is "12345678". The administrator of this machine should change the administrator password. Be sure to keep the administrator password in a safe place. If the administrator password is lost, it must be specified by the service representative. For details, contact the service representative. 12-38 CS193/CS173/CS163...

  • Page 483: Check Consumable Life

    Touch [4 Check Consumable Life]. – An item can also be selected by pressing the key in the keypad for the number beside the desired button. For [4 Check Consumable Life], press the [4] key in the keypad. CS193/CS173/CS163 12-39...

  • Page 484: Overview Of Weekly Timer Settings

    Timer Setting], and correctly specify the necessary settings. Set "Weekly Timer ON/OFF Settings" to "ON". Specify times for "Time Settings". Specify dates for "Date Settings". Specify the desired settings for "Select Time for Power Save" and "Password for Non-Business Hours". The weekly timer is set. 12-40 CS193/CS173/CS163...

  • Page 485: Printer Adjustment

    – If the distance is more than 4.2 mm, touch [-] to reduce the adjustment (between -0.2 mm and -3.0 mm). – Each time [+] or [-] is touched, the value is increased or decreased by one increment. CS193/CS173/CS163 12-41...

  • Page 486: Centering

    The Printer Adjustment screen appears. Touch [2 Centering]. The Centering screen appears. Touch the button for the paper tray to be set. Press the [Start] key. – Only paper loaded into the bypass tray can be used. A test pattern is printed. 12-42 CS193/CS173/CS163...

  • Page 487: Leading Edge Adjustment (Duplex Side 2)

    The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [2 Printer Adjustment]. The Printer Adjustment screen appears. Touch [3 Leading Edge Adjustment (Duplex Side 2)]. The Leading Edge Adjustment (Duplex Side 2) screen appears. CS193/CS173/CS163 12-43...

  • Page 488: Centering (Duplex 2Nd Side)

    Only A4 v paper can be used to adjust the bypass tray. Display the Administrator Settings screen. – For details on displaying the Administrator Settings screen, refer to "Displaying the Administrator Settings screen" on page 12-37. Touch [1 System Settings]. The System Settings screen appears. 12-44 CS193/CS173/CS163...
  • Page 489 If more adjustment is necessary, repeat steps 8 and 9. – To adjust the print position for a different paper tray, return to step 6. Touch [OK]. – To cancel the setting and select the default, press the [Reset] key. The print position is adjusted. CS193/CS173/CS163 12-45...

  • Page 490: Finisher Adjustment

    The Center Staple Position screen appears. Touch the button for the paper size and paper type to be adjusted. – If the paper size to be adjusted is not displayed, touch until the desired paper size is displayed. 12-46 CS193/CS173/CS163...

  • Page 491: Half-Fold Position

    Before making any adjustments, use the "Half-Fold" setting to print a single sample copy. Perform the adjustment while checking the sample that was created. Display the Administrator Settings screen. – For details on displaying the Administrator Settings screen, refer to "Displaying the Administrator Settings screen" on page 12-37. CS193/CS173/CS163 12-47...
  • Page 492 Each time [+] or [-] is touched, the value is increased or decreased by one increment. – If the folding position is too far to the right of the center of the paper, touch [-] to reduce the adjustment (between -1 and -10). 12-48 CS193/CS173/CS163...

  • Page 493: Punch Horizontal Position Adjustment

    Touch [1 System Settings]. The System Settings screen appears. Touch [7 Expert Adjustment]. The Expert Adjustment screen appears. Touch [3 Finisher Adjustment]. The Finisher Adjustment screen appears. Touch [3 Punch Horizontal Position Adjustment]. The Punch Horizontal Position Adjustment screen appears. CS193/CS173/CS163 12-49...

  • Page 494: Punch Regist Loop Size Adjustment

    For details on the Punch settings, refer to "Punching holes in copies (Punch settings)" on page 3-75. Before making any adjustments, use a Punch setting to print a sample copy. Perform the adjustment while checking the sample that was created. 12-50 CS193/CS173/CS163...
  • Page 495 If no adjustment of the angle of the punched holes was necessary in step 6, this completes the procedure. Use a Punch setting to print another sample copy. Check the print result. – Check that the angle of the punched holes was adjusted. – If more adjustment is necessary, repeat steps 6 and 7. CS193/CS173/CS163 12-51...

  • Page 496: Color Registration Adjust

    Load the paper into the bypass tray. Press the [Start] key. A test pattern is printed. Check the distance from the reference black lines to the cyan lines in the test pattern along the X and Y directions. 12-52 CS193/CS173/CS163...
  • Page 497 If there is no shift between the black and cyan lines, continue with step 11. – If more adjustment is necessary, repeat steps 8 and 9. Touch [OK]. – To cancel the setting and select the default, press the [Reset] key. CS193/CS173/CS163 12-53...

  • Page 498: Gradation Adjustment

    The Gradation Adjustment screen appears. Press the [Start] key. – The gradation levels cannot be adjusted if an image stabilization operation is not performed. The image stabilization operation begins. Touch the button for the mode to be adjusted. 12-54 CS193/CS173/CS163...
  • Page 499 Why are blank pages placed on top of the test pattern? % Place 10 sheets of blank paper on top of the test pattern to prevent it from becoming transparent. Otherwise, the gradation levels may not be correctly adjusted. Close the ADF or original cover. CS193/CS173/CS163 12-55...

  • Page 500: Header/Footer Settings

    For details on displaying the Administrator Settings screen, refer to "Displaying the Administrator Settings screen" on page 12-37. Touch [1 System Settings]. The System Settings screen appears. Touch [Forward ], and then touch [2 Stamp Settings]. The Stamp Settings screen appears. Touch [1 Header/Footer Settings]. The Header/Footer Settings screen appears. 12-56 CS193/CS173/CS163...
  • Page 501 The Header/Footer Settings > New screen appears. Touch [Name]. The New > Name screen appears. Type in the header/foot name (up to 16 characters long), and then touch [OK]. – For details on typing in text, refer to "Entering text" on page 13-3. CS193/CS173/CS163 12-57...

  • Page 502: Editing Headers/Footers

    To print the header/footer only on the first page, touch [1st Page Only]. 12.11.2 Editing headers/footers In the Header/Footer Settings screen, touch the button of the header/footer to be edited. Touch [Check/Edit]. – To delete the header/footer, touch [Delete]. The Check/Edit screen appears. Touch [OK]. 12-58 CS193/CS173/CS163...

  • Page 503: Authentication Method

    This setup is used when the machine is used by multiple departments and the use by each employee is managed by each department. With this setup, statistics can be maintained on each employee (each user) and on each department (each account). To manage the use of this machine in this way, specify the following authentication settings. CS193/CS173/CS163 12-59...

  • Page 504: When User Authentication And Account Track Are Used Separately

    Parameter on Authentication Method screen Settings User Authentication Select "ON (External Server)" or "ON (MFP)". Account Track Select "ON", and then specify the account name and pass- word. Synchronize User Authentication & Account Track Select "Do Not Synchronize". 12-60 CS193/CS173/CS163...

  • Page 505: Selecting An Authentication Method

    To allow this machine to be used after the account name and password are entered in the account track screen, touch [Account Name & Password]. – To allow this machine to be used after the password is entered in the account track screen, touch [Password Only]. CS193/CS173/CS163 12-61...
  • Page 506 Active Directory is selected as the authentication server type. Touch [OK]. – If the setting for "User Authentication", "Account Track" or "Number of User Counters Assighed" was changed, the message "Are you sure you want to clear all data?" appears. 12-62 CS193/CS173/CS163...
  • Page 507 Reminder Do not use a name including uppercase and lowercase of the same character for the user name of the external server. Since the CS193/CS173/CS163 cannot differentiate between uppercase and lowercase letters, the operation may not be performed correctly. Note "Synchronize User Authentication &...

  • Page 508: User Authentication Setting

    (The default setting is "Allow".) The following operations can be limited. Copy operations Scan operations Fax operations Printing from a printer Saving documents on the hard disk Printing the transmitted document Saving the document to the external memory 12-64 CS193/CS173/CS163...

  • Page 509: Public User Access

    [Access] key must be pressed first to display the authentication screen. (The default setting is "Restrict".) Display the Administrator Settings screen. – For details on displaying the Administrator Settings screen, refer to "Displaying the Administrator Settings screen" on page 12-37. CS193/CS173/CS163 12-65...

  • Page 510: User Registration

    % [2 User Authentication Settings] is not available if "User Authentication" on the General Settings screen is set to "OFF". Touch [2 User Registration]. Touch the button for the desired user, and then touch [Edit]. The Edit screen for the user appears. 12-66 CS193/CS173/CS163...
  • Page 511 Type in the password (up to 64 characters long), and then touch [OK]. For confirmation, the Password screen appears again. Retype the same password, and then touch [OK]. The user password is set. Touch [E-Mail Address]. The E-Mail Address screen appears. CS193/CS173/CS163 12-67...
  • Page 512 If both color and black printing are restricted, the message "Copying is prohibited." appears, even if authentication was completed correctly. – If "Color" is set to "Restrict" under "Send", color scanning is not possible. Touch [OK]. The output permissions are set. Touch [Max. Allowance Set]. The Max. Allowance Set screen appears. 12-68 CS193/CS173/CS163...
  • Page 513 When using authentication unit (biometric type), place a finger on the authentication unit and register the vein patterns. – When using authentication unit (IC card type), place an IC card on the authentication unit and register the card information. Touch [Function Permission]. The Function Permission screen appears. CS193/CS173/CS163 12-69...
  • Page 514 If no operation is permitted, user authentication cannot be performed. Touch [OK]. The function permissions are set. Touch [OK]. – To cancel the settings in the current screen, touch [Cancel]. – To delete the selected user information, touch [Delete] in the User Registration screen. 12-70 CS193/CS173/CS163...

  • Page 515: User Counter

    Fax TX: Total number of pages transmitted with fax operations Note Counting automatically continues with user counters when using external server authentication. The public user access is counted as "public" of the counter. The user box administrator access is counted as "BoxAdmin" of the counter. CS193/CS173/CS163 12-71...

  • Page 516: Viewing User Counters

    To clear the counters for all users, touch [Reset All Counters] in the User Counter screen. A confirmation message appears, asking whether the counters should be cleared. To clear the counters for all users, touch [Yes] in the confirmation message screen, and then touch [OK]. The maximum number allowed is not cleared. Touch [Close]. 12-72 CS193/CS173/CS163...

  • Page 517: Account Track Setting

    Touch [3 Account Track Settings]. The Account Track Setting screen appears. Touch [1 Account Track Registration]. Touch the button for the desired account, and then touch [OK]. The Edit screen for the account appears. If "Account Name & Password" was selected: CS193/CS173/CS163 12-73...
  • Page 518 If "Account Track Input Method" was set to "Password Only", the same password cannot be registered more than once. The Password screen appears. Type in the password (up to 8 characters long), and then touch [OK]. A screen for retyping the password appears. 12-74 CS193/CS173/CS163...
  • Page 519 If both color and black printing are restricted, the message "Copying is prohibited." appears, even if authentication was completed correctly. – If "Color" is set to "Restrict" under "Send", color scanning is not possible. Touch [OK]. The output permissions are set. Touch [Max. Allowance Set]. The Max. Allowance Set screen appears. CS193/CS173/CS163 12-75...
  • Page 520 At this time, do not turn off the machine with the main power switch. Touch [OK]. The maximum number of prints allowed is set. Touch [OK]. – To delete the selected account information, touch [Delete]. 12-76 CS193/CS173/CS163...

  • Page 521: Account Track Counter

    This counter shows the number of original pages that were scanned. Paper Counter This counter shows the number of pages used for printing. Fax TX Count Total number of pages transmitted with fax operations Note The public user access is counted as "public" of the counter. CS193/CS173/CS163 12-77...

  • Page 522: Viewing Account Counters

    A confirmation message appears, asking whether the counters should be cleared. To clear the counters for all accounts, touch [Yes] in the confirmation message screen, and then touch [OK]. The maximum number allowed is not cleared. Touch [Close]. 12-78 CS193/CS173/CS163...

  • Page 523: Password Rules

    8 alphanumeric characters and symbols • A password that consists of a repetition of the same charac- ter cannot be registered. • The same password as one before being changed cannot be registered. Note Use when specifying account track settings. CS193/CS173/CS163 12-79...
  • Page 524 Limitations on registering/changing 8 alphanumeric characters and symbols • A password that consists of a repetition of the same charac- ter cannot be registered. Note If any password not following the Password Rules, Secure Print cannot be performed. 12-80 CS193/CS173/CS163...

  • Page 525: Enhanced Security Mode

    When Authentication Error/Release Time Settings Detail If "Account Track" is set to "ON" in the General Settings screen, set "Account Track Input Method" to "Account Name & Password". [SSL] appears when a certificate is registered with Web Connection. CS193/CS173/CS163 12-81...
  • Page 526 – Operations. For details on the limitations placed on the user for printing, refer to the User manual Print Operations. – For details on canceling operation restrictions applied when authentication failed, refer to "Security Settings" on page 12-34. 12-82 CS193/CS173/CS163...

  • Page 527: Appendix

    Appendix...

  • Page 529: Entering Text

    The keypad can also be used to type in numbers. Any of the following keyboards may appear. Example Password input screen: Screen for entering the name of a custom paper size: CS193/CS173/CS163 13-3...
  • Page 530 Appendix Touching [Shift] switches the keyboard display between lowercase letters (numbers) and uppercase letters (symbols). 13-4 CS193/CS173/CS163...

  • Page 531: Enlarging The Keyboard

    The keyboard is displayed enlarged. To cancel the enlarged display and return the keyboard to its normal size, touch [Enlarge OFF] while the keyboard is displayed enlarged. Note The keyboard is used in the same way, even when it is displayed enlarged. CS193/CS173/CS163 13-5...

  • Page 532: To Type Text

    To change a character in the entered text, touch [ ] and [ ] to move the cursor to the character to be changed, touch [Delete], and then type in the desired letter or number. 13.1.3 List of available characters Type Characters Alphanumeric charac- ters/symbols 13-6 CS193/CS173/CS163...

  • Page 533: Glossary

    Set this function to print hidden text in order to prevent improper copying. When an original printed with copy protection text is copied, the hidden text appears clearly repeated in all pages of the copies so that the reader knows that it is a copy. CS193/CS173/CS163 13-7...
  • Page 534 Set this function to produce a copy in the mirror image of the original. Mixed Original Select this setting to detect the size of each original page and print a copy on paper of the appropriate size when an original with different page sizes is loaded together into the ADF. 13-8 CS193/CS173/CS163...
  • Page 535 Select this setting when loading thick originals or original pages pasted together into the ADF. If this setting is selected when thick originals are scanned with the ADF, there is a smaller chance of a paper misfeed occurring. CS193/CS173/CS163 13-9...
  • Page 536 Appendix XY Zoom Touch this button to use the keypad to specify the zoom ratio for producing an enlarged/reduced copy of the loaded original. Zoom Specify the zoom ratio of the copy. 13-10 CS193/CS173/CS163...

  • Page 537: Index

    Index...
  • Page 539 8-65 Booklet Original 3-77 Folding Brightness 8-11 8-75 Frame Erase 2-47 5-27 Bypass tray Full Color 3-34 3-41 Full Size Call service representative Fusing unit area Center Staple & Fold 3-77 3-79 Center Staple Position 12-46 12-42 Centering CS193/CS173/CS163 14-3...
  • Page 540 Punch Horizontal Position Adjustment 5-54 5-55 5-56 5-57 5-61 10-9 Message Punch kit PK-515 2-10 4-30 Message Display Time 12-50 Punch Regist Loop Adjustment 10-7 Meter Count 9-22 Punch scrap Minimal 3-43 Punch settings 3-67 3-75 8-21 8-43 Mirror Image 14-4 CS193/CS173/CS163...
  • Page 541 2-18 4-21 2-43 5-31 Tray 1 5-33 Tray 2 5-35 Tray 3 Tray 4 Trouble code 5-58 Troubleshooting 2-31 User authentication User Authentication Setting 12-64 12-29 User Authentication/Account Track 1-12 User manuals 12-15 User Settings 12-3 Utility mode CS193/CS173/CS163 14-5...
  • Page 542 Index 14-6 CS193/CS173/CS163...
  • Page 543 Reader's comment sheet Reader's comment sheet Questions Have you found this manual to be accurate? O Yes O No Were you able to operate the product, after reading this manual? O Yes O No Does this manual provide sufficient background information? O Yes O No Is the format of this manual convenient in size, readability and arrangement (page...
  • Page 544 City: Country: Please return this sheet to: Océ-Technologies B.V. For the attention of ITC User Documentation. P.O. Box 101, 5900 MA Venlo The Netherlands Send your comments by E-mail to: itc-userdoc@oce.com For the addresses of local Océ organisations see: http://www.oce.com...
  • Page 545 Océ-Australia Ltd. Océ-Österreich GmbH P.O. Box 363 Postfach 95 Ferntree Gully MDC 1233 Vienna Vic 3165 Austria Australia http://www.oce.at/ http://www.oce.com.au/ Océ-Belgium N.V./S.A. Océ-Brasil Comércio e Indústria Ltda. J. Bordetlaan 32 Av. das Nações Unidas, 11.857 1140 Brussel Brooklin Novo Belgium São Paulo-SP 04578-000...
  • Page 546 Addresses of local Océ organisations Océ-Hungaria Kft. Océ-Ireland Ltd. 1241 Budapest 3006 Lake Drive Pf.: 237 Citywest Business Campus Hungary Saggart http://www.oce.hu/ Co. Dublin Ireland http://www.oce.ie/ Océ-Italia S.p.A. Océ Japan Corporation Strada Padana Superiore 2/B 3-25-1, Nishi Shinbashi 20063 Cernusco sul Naviglio (MI)
  • Page 547 5450 North Cumberland Avenue Chicago, IL 60656 http://www.oceusa.com/ Note: The web site http://www.oce.com gives the current addresses of the local Océ organisations and distributors. Note: The addresses of local Océ organisations for information about the Wide Format Printing Systems and the Production Printing Systems can be different from the addresses above.

This manual is also suitable for:

Cs173Cs163

Table of Contents
