- Page 1 EMX-PNV Intel® Atom™ PNV-M/ PNV-D Mini ITX Motherboard with Intel® ICH8-M Chipset User’s Manual Ed – September 23, 2010...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 3 User’s Manual otherwise specified. Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. Life Support Policy Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN...
- Page 4 Avalue Technology Inc. Room 805, Building 9,No.99 Tianzhou Rd., 2F keduka-Bldg, 2-27-3 Taito, Caohejing Development Area, Taito-Ku, Tokyo 110-0016 Japan Xuhui District, Shanghai Tel: +81-3-5807-2321 Tel: +86-21-5169-3609 Fax:+86-21-5445-3266 Fax: +81-3-5807-2322 Information: sales.china@avalue.com.cn Information: sales.japan@avalue.com.tw Service: service@avalue.com.tw Service: service@avalue.com.tw 4 EMX-PNV User’s Manual...
- Page 5 (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. EMX-PNV User’s Manual 5...
-
Page 6: Table Of Contents
2.4.18 ATX power connector (PWR1) ....................31 2.4.19 4W/ 5W/ 8W touch mode select (TSW1) ................... 31 2.4.20 Touch panel connector (TOUCH1) .................... 32 3. BIOS Setup ........................33 Introduction ......................34 Starting Setup ......................34 Using Setup ......................35 6 EMX-PNV User’s Manual... -
Page 7: Emx-Pnv User's Manual
PCIPnp............................55 3.6.3 Boot settings ..........................56 3.6.4 Security settings .......................... 59 3.6.5 Advanced Chipset Settings......................60 3.6.6 Exit Options ..........................65 3.6.7 4. Drivers Installation.......................66 Install Ethernet Driver (For Intel 82574L) ..............67 5. Mechanical Drawing ....................69 EMX-PNV User’s Manual 7... -
Page 8: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EMX-PNV Mini ITX Main Board 1 x DVD-ROM contains the followings: - User’s manual in pdf file - Driver 2 x SATA &... -
Page 9: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment September Initial Release 2010 EMX-PNV User’s Manual 9... -
Page 10: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with EMX-PNV series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 11: System Specifications
User’s Manual 1.5 System Specifications System Onboard Intel PNV-M SC N450 1.6GHz(EMX-PNX-N450) Onboard Intel PNV-D SC D410 / D510 (EMX-PNV-D410/D510) AMI EFI BIOS (8Mbit SPI) BIOS ICH8M System Chipset Winbond 83627DHG I/O Chip Support one SODIMM, max. 2GB, DDR2 667 MHz. - Page 12 Intel® 82583V PCI-E Gigabit LAN LAN2 Mechanical & Environmental ATX/ AT Power Requirement 0~60°C (32~140°F) Operation Temperature 0%~90% relative humidity, non-condensing Operating Humidity 6.69" x 6.69" (170 mm x 170 mm) Size ( L x W ) 0.88lbs (0.4Kg) Weight 12 EMX-PNV User’s Manual...
-
Page 13: Architecture Overview - Block Diagram
User’s Manual 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of EMX-PNV. EMX-PNV User’s Manual 13... -
Page 14: Hardware Configuration
EMX-PNV 2. Hardware Configuration 14 EMX-PNV User’s Manual... -
Page 15: Product Overview
User’s Manual 2.1 Product Overview EMX-PNV User’s Manual 15... -
Page 16: Installation Procedure
Note: Make sure the heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause the system to hang or unstable 16 EMX-PNV User’s Manual... -
Page 17: Main Memory
User’s Manual 2.2.1 Main Memory EMX-PNV provides 1 x 200-pin SODIMM and supports up to DDR2 667MHz SDRAM. The total maximum memory size is 2GB. (Rear side) Make sure to unplug the power supply before adding or removing SODIMMs or other system components. Failure to do so may cause severe damage to both the board and the components. - Page 18 (2) Static electricity can damage the electronic components of the computer or optional boards. Before starting these procedures, ensure that you are discharged of static electricity by touching a grounded metal object briefly. 18 EMX-PNV User’s Manual...
-
Page 19: Jumper And Connector List
Serial port 2 pin 9 signal select – Ring, 3 x 2 header, pitch 2.0 mm +5V, +12V power select Serial port 1 pin 9 signal select – Ring, 3 x 2 header, pitch 2.0 mm +5V, +12V power select EMX-PNV User’s Manual 19... - Page 20 Serial ATA connector 2 SATA2 Touch panel connector 5 x 2 header, pitch 2.54 mm TOUCH1 4W/5W/8W touch mode select DIP-SW, 6P TSW1 VGA connector D-sub 15-pin, female VGA1 LCD backlight brightness adjustment 3 x 1 header, pitch 2.54mm 20 EMX-PNV User’s Manual...
-
Page 21: Setting Jumpers & Connectors
PIN PIN Signal SB_LED+ AUX TIN +3.3V BUZZER HDD_LED * Default PWR_LED+ RESET Note: AUXTIN is usually a port you can add an Open: AT auxiliary sensor to, to monitor HDD or Chipset PWRBTN Short: ATX* temperatures. EMX-PNV User’s Manual 21... -
Page 22: Serial Port 3/ 4/ 2/ 1 Pin 9 Signal Select (Jp1/ Jp2/ Jp3/ Jp4)
EMX-PNV 2.4.3 Serial port 3/ 4/ 2/ 1 pin 9 signal select (JP1/ JP2/ JP3/ JP4) JP2/ 3/ 4 Ring* Ring* +12V +12V * Default 2.4.4 Speaker out connector (CN1) Signal AMP_OUT_LP AMP_OUT_LN AMP_OUT_RN AMP_OUT_RP 22 EMX-PNV User’s Manual... -
Page 23: Usb Connector 4 & 5/ 6 & 7 (Cn2/ Cn3)
User’s Manual 2.4.5 USB connector 4 & 5/ 6 & 7 (CN2/ CN3) Signal PIN PIN Signal P4-/P6- P4+/P6+ P5+/P7+ P5-/P7- 2.4.6 SPI connector (CN4) Signal PIN PIN Signal +3.3V SPI_CS0# SPI_CLK SPI_SO SPI_SI EMX-PNV User’s Manual 23... -
Page 24: Serial Port 4/ 3 Connector (Cn5/ Cn7)
EMX-PNV 2.4.7 Serial port 4/ 3 connector (CN5/ CN7) Signal PIN PIN Signal 2.4.8 LCD backlight brightness adjustment (VR1) Signal BRIGHT Variation Resistor (Recommended: 4.7KΩ, >1/16W) 24 EMX-PNV User’s Manual... -
Page 25: Lcd Inverter Connector (Cn6)
VR signal controlled by VR1. Please see the VR1 section for detailed circuitry information 2.4.9.1 Signal Description – LCD Inverter Connector (CN6) Signal Signal Description BRIGHT Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) LBKLT_EN LCD backlight ON/OFF control signal EMX-PNV User’s Manual 25... -
Page 26: Cd-Rom Audio Connector (Cn8)
EMX-PNV 2.4.10 CD-ROM Audio Connector (CN8) Signal 2.4.11 Front audio connector (CN9) Signal PIN PIN Signal MIC2_L MIC2_R +3.3V LINE2_R MIC2_JD SENSE_B LINE2_L LINE2_JD 26 EMX-PNV User’s Manual... -
Page 27: General Purpose I/O Connector (Dio1)
User’s Manual 2.4.12 General purpose I/O connector (DIO1) Signal Signal SMB_CLK SMB_DAT EMX-PNV User’s Manual 27... -
Page 28: Cpu Fan Connector (Cpu_Fan)
EMX-PNV 2.4.13 CPU fan connector (CPU_FAN) FAN2 FAN1 Signal +12V FAN_TAC1 2.4.14 VGA power connector (JVGA1) Signal Signal +12V +12V +12V +12V +3.3V +3.3V 28 EMX-PNV User’s Manual... -
Page 29: Vga Connector (Jvga2)
User’s Manual 2.4.15 VGA connector (JVGA2) Signal Signal 2.4.16 Print port connector (LPT1) Signal Signal P_-STB P_AFD# P_ERR# P_INIT# P_SLIN# P_ACK# P_BUSY P_PE P_SLCT EMX-PNV User’s Manual 29... -
Page 30: Lvds Connector (Lvds1)
EMX-PNV 2.4.17 LVDS connector (LVDS1) Signal Signal LVDSA_CLK- LVDSA_CLK+ LVDSA_D2- LVDSA_D2+ LVDSA_D1- LVDSA_D0- LVDSA_D1+ LVDSA_D0+ LCDSA_DDC_SC LCDSA_DDC_SD +3.3V +3.3V 30 EMX-PNV User’s Manual... -
Page 31: Atx Power Connector (Pwr1)
User’s Manual 2.4.18 ATX power connector (PWR1) Signal Signal +3.3V +3.3V -12V +3.3V PS_ON# +12V 2.4.19 4W/ 5W/ 8W touch mode select (TSW1) TSW1 4-WIRE 5-WIRE 8-WIRE No function EMX-PNV User’s Manual 31... -
Page 32: Touch Panel Connector (Touch1)
EMX-PNV 2.4.20 Touch panel connector (TOUCH1) Signal Signal PROBE Touch1 4-WIRE 5-WIRE 8-WIRE Right Excite Right Right Sense Bottom Excite Bottom Bottom Sense Sense Left Excite Left Left Sense Top Excite Top Sense 32 EMX-PNV User’s Manual... -
Page 33: Bios Setup
User’s Manual 3. BIOS Setup EMX-PNV User’s Manual 33... -
Page 34: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 34 EMX-PNV User’s Manual... -
Page 35: Using Setup
Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “ ” pointer marks all sub menus. EMX-PNV User’s Manual 35... -
Page 36: Getting Help
Award and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 36 EMX-PNV User’s Manual... -
Page 37: Bios Setup
Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. EMX-PNV User’s Manual 37... -
Page 38: Advanced Settings
EMX-PNV 3.6.2 Advanced Settings This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 38 EMX-PNV User’s Manual... - Page 39 Intel ® C-STATE tech Enabled actual power management adheres to the platform and CPU shared resources Disabled, This item allows you to enable or disable Enhanced C-States Enabled Enhanced C-States EMX-PNV User’s Manual 39...
- Page 40 This allows you to select the time out value for IDE Detect Time Out (Sec) detecting ATA/ ATAPI devices. Host & Device, This item allows you to select ATA cable Host, ATA (PI) 80Pin Cable Detection detection mode. Device 40 EMX-PNV User’s Manual...
- Page 41 Use the Parallel IRQ selection to set the IRQ5,IRQ7 Parallel Port IRQ parallel port interrupt address Use the Serial Port3/4 IRQ option to select the 4, 9, 10, 11 Serial Port 3/ 4 IRQ interrupt address for serial port 3~4 EMX-PNV User’s Manual 41...
- Page 42 This section shows the operating temperature, fan speed and system voltage. The following system temperature, fan speed and voltage are monitored. System Temperature: Shutdown Temperature System Temperature CPU Temperature Fan speed: CPUFAN speed Voltage: Vcore AVCC 3VCC V1.5 VGFX VDDR V5.0 VBAT 42 EMX-PNV User’s Manual...
- Page 43 User’s Manual 3.6.2.5 ACPI configuration Defines interfaces for hardware discovery, configuration, power management and monitoring. EMX-PNV User’s Manual 43...
- Page 44 Use the Suspend Mode option to specify the S3 (STR), sleep state the system enters when it is not being Suspend Mode Auto used. This item allows you to invoke VA BIOS POST Repost Video on S3 Resume on S3/ STR resume. 44 EMX-PNV User’s Manual...
- Page 45 RSDT (Root System Description Table) to add a pointer to an OEMB table in the RSDT Enabled, table and AMI OEMB table Disabled the Extended System Description Table (XSDT). Disabled, Enable/ Disable Headless operation mode Headless mode Enabled through ACPI. EMX-PNV User’s Manual 45...
- Page 46 To enable/ disable APIC ACPI SCI IRQ. APIC ACPI SCI IRQ Enabled Disabled, This section helps to set high performance High Performance Event Timer Enabled event timer. FES00000h, This item allows selecting HPET memory FES01000h, HPET Memory Address address. FES02000h 46 EMX-PNV User’s Manual...
- Page 47 User’s Manual 3.6.2.6 AHCI Settings This is a system memory structure to exchange data between host system memory and attached storage devices. EMX-PNV User’s Manual 47...
- Page 48 EMX-PNV 3.6.2.6.1 AHCI Port0 Item Options Description Auto, Serial port 0 mode selection. SATA Port0 Not Installed Disabled, Select the smart monitoring, analysis, and S.M.A.R.T. Enabled reporting technology. 48 EMX-PNV User’s Manual...
- Page 49 User’s Manual 3.6.2.6.2 AHCI Port1 Item Options Description Auto, Serial port 1 mode select. SATA Port1 Not Installed Disabled, Select the smart monitoring, analysis, and S.M.A.R.T. Enabled reporting technology. EMX-PNV User’s Manual 49...
- Page 50 EMX-PNV 3.6.2.6.3 AHCI Port2 Item Options Description Auto, Serial port 2 mode select. SATA Port2 Not Installed Disabled, Select the smart monitoring, analysis, and S.M.A.R.T. Enabled reporting technology. 50 EMX-PNV User’s Manual...
- Page 51 User’s Manual 3.6.2.7 Trusted Computing To Enable/disable TPM TCG (TPM 1.1/1.2) supp in BIOS Item Options Description To enable or disable TCG/TPM TCG/TPM SUPPORT [Press Enter] Resets the TPM to an unowned state Clearing the TPM EMX-PNV User’s Manual 51...
- Page 52 The EHCI ownership BIOS EHCI Hand-Off Disabled change should be claimed by EHCI driver. The USB FDD is a slim type floppy disk drive (FDD) with a Universal Serial Bus (USB) Auto Hotplug USB FDD Support interface. 52 EMX-PNV User’s Manual...
- Page 53 If Auto, USB devices less than 530MB will be emulated as a floppy drive and the remaining as hard drive. Force FDD option can be used to force a Emulation type FDD formatted drive to boot as FDD (Ex. ZIP drive). EMX-PNV User’s Manual 53...
- Page 54 Resume On PCIE Enabled or standby state. Disabled, Use this option to specify the time the system Resume On RTC Alarm Enabled should be roused from a suspend state. 54 EMX-PNV User’s Manual...
-
Page 55: Pcipnp
No to free up an IRQ. This item is designed to solve problems Enable/Disable Palette Snooping caused by some non-standard VGA card. When set to enabled, BIOS uses PCI bus Enable/Disable mastering for reading/writing to IDE drives. PCI IDE BusMaster EMX-PNV User’s Manual 55... -
Page 56: Boot Settings
Use the IRQ# address to specify what IRQs Available, can be assigned to a particular peripheral IRQ3/ 4/ 5/ 7/ 9/ 10/ 11 Reserved device. 3.6.4 Boot settings Use the Boot menu to configure system boot options. 56 EMX-PNV User’s Manual... - Page 57 This BIOS feature allows you to control the Disabled, display of the Hit “DEL” to enter setup Hit “DEL” Message Display Enabled message during memory initialization. Disabled, This item allows options for ROMs to trap Interrupt 19 capture Enabled interrupt 19. EMX-PNV User’s Manual 57...
- Page 58 EMX-PNV 3.6.4.2 Boot device Priority Use the Boot Device Priority menu to specify the boot sequence from the available devices. 3.6.4.3 Removable Drives Specifies boot sequence from the available devices 58 EMX-PNV User’s Manual...
-
Page 59: Security Settings
3.6.4.4 Hard Disk Drives Use the Hard Disk Drives menu to specify the boot sequence of the available devices. 3.6.5 Security settings Security Setup options, such as password protection and virus protection are described in this section. EMX-PNV User’s Manual 59... -
Page 60: Advanced Chipset Settings
Use Clear User Password to delete a user password. Item Options Description Disabled, The boot sector virus protection will warn if Boot Sector Virus protection Enabled any program tries to write to the boot sector. 3.6.6 Advanced Chipset Settings 60 EMX-PNV User’s Manual... - Page 61 Initiate Graphic Adapter PEG/IGD, PEG/PCI as the primary boot device. This option determines the amount of system memory that Enabled 8MB Internal Graphics Mode Select can be used by the internal graphics device. EMX-PNV User’s Manual 61...
- Page 62 64MB, Specifies the amount of DVMT/ 128MB, FIXED system memory to allocate DVMT/ FIXED Memory Maximum DVMT for video memory. VBIOS-Default, CRT, Select boot display device at post Boot Display Device LVDS, stage. CRT+LVDS 62 EMX-PNV User’s Manual...
- Page 63 1024 x 600, 1024 x 768, 1024 x 768, 1024 x 768, 1280 x 800, 1280 x 600, 1366 x 768 Disabled, This item allows you to enable or Spread Spectrum Clock Enabled disable spread spectrum clock. EMX-PNV User’s Manual 63...
- Page 64 This item helps to set PCIE high Enabled, PCIE High Priority Port priority port. Auto Disabled, This helps to enabled or disabled PCIE Port 0/ 1/ 2 IOxAPIC Enabled PCIE port 0/ 1/ 2 IOxAPIC. Enable 64 EMX-PNV User’s Manual...
-
Page 65: Exit Options
3.6.7.5 Load Failsafe Defaults Select this option to replace most of the current BIOS settings with predefined settings (coded into the BIOS) that are intended to put the system into as stable a state as possible EMX-PNV User’s Manual 65... -
Page 66: Drivers Installation
EMX-PNV 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 66 EMX-PNV User’s Manual... -
Page 67: Install Ethernet Driver (For Intel 82574L)
Windows XP operation system. Step 3. Click Next to run the installation. Step 4. Click Accept to continue. Step 1. Locate 「\Driver_Gigabit\Intel\ 82574L」and choose your system OS. Step 2. Click Next. Step 5. Click Next. EMX-PNV User’s Manual 67... - Page 68 EMX-PNV Step 6. Click Install to next step. Step 7. Click Next to next step. Step 8. Click Finish to complete the setup. 68 EMX-PNV User’s Manual...
-
Page 69: Mechanical Drawing
User’s Manual 5. Mechanical Drawing EMX-PNV User’s Manual 69... - Page 70 EMX-PNV Unit: mm 70 EMX-PNV User’s Manual...
- Page 71 User’s Manual EMX-PNV User’s Manual 71...
