Avalue has come to be known. Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To ensure you get the full benefit of our services, please follow the instructions below carefully.
Driver/Utility CD X 1 Serial ATA Signal Cable X 1 COM Port X 1 Screw X 2 Motherboard X 1 Front Audio cable X 1 IO Shield X 1 EMX-PNVB Quick Installation Guide 3...
Page 6
JBAT1 Clear CMOS 1 x 3 header, pitch2.54 mm JS1~2 Jumper for MPCIE & MSATA selection 2 x 3 header, pitch 2.54 mm Jumper for MPCIE PWR selection 1 x 3 header, pitch 2.54 mm 6 EMX-PNVB Quick Installation Guide...
Page 7
1 x 3 header, pitch 2.54 mm Jumper for Serial port 1~6 pin9 power 1 x 3 header, pitch 2.54 mm JC11/21/31/41/51/61 selection JKB_MS Keyboard & Mouse connector 2 x 5 header, pitch 2.54 mm AUDIO1 Line-Out & Mic-In connector EMX-PNVB Quick Installation Guide 7...
Page 9
EMX-PNVB Quick Installation Guide 2.3.3 Jumper for COM2 or IR selection (JIR1~2) COM2* JIR2 JIR1 Define COM2 Note: IR is not functional. * Default 2.3.4 Jumper for LVDS PWR selection (JP1) 3.3V* Define Max current 3.3V * Default EMX-PNVB Quick Installation Guide 9...
Page 10
EMX-PNVB Quick Installation Guide 2.3.5 Jumper for MPCIE selection (JS1~2) M-SATA* MINIPCIE Define * Default M-SATA MINIPCIE 2.3.6 Jumper for MPCIE PWR selection (JS3) 3.3V* Define Max current 3.3V * Default 10 EMX-PNVB Quick Installation Guide...
Page 11
JC52 JC62 USE JC11_JC61 JC12 PIN Option Define CLOSE OPEN USE JC11_JC61 * Default 2.3.8 Jumper for Serial port 1~6 pin9 power selection (JC11/21/31/41/51/61) JC21 JC31 JC41 +12V JC51 JC61 JC11 Define Max current +12V EMX-PNVB Quick Installation Guide 11...
Page 12
Signal PIN PIN Signal GPIO GPIO GPIO GPIO GPIO GPIO GPIO GPIO +12V 2.3.10 Front Panel Switches (FPANEL1) Signal PIN PIN Signal 5VSB +HD_LED +P_LED -HD_LED -P_LED PS_ON +SPEAK -PS_ON RESET -RESET -SPEAK +SLPLED -SLPLED 12 EMX-PNVB Quick Installation Guide...
Page 14
EMX-PNVB Quick Installation Guide 2.3.12 VGA connector (JVGA2) Signal PIN PIN Signal DDC_CLK DDC_DATA VSYNC HSYNC BLUE GREEN Note: I t can only use either D-SUB connector or Pin Header 2.3.13 Inverter connector (INCN1) Signal Max current BLEN 14 EMX-PNVB Quick Installation Guide...
Page 15
EMX-PNVB Quick Installation Guide 2.3.14 Front Panel Audio Connection Header (F_AUDIO) Signal Signal AUD_RET_L FRONT_OUT_L AUD_RET_R FRONT_OUT_R VREF_OUT FRONT_MIC Note: Please use the attached audio cable for front audio daughter board. EMX-PNVB Quick Installation Guide 15...
Page 16
EMX-PNVB Quick Installation Guide 2.3.15 Serial port 2~6 connector (COM2~6) COM2 COM3 COM4 COM5 COM6 Signal PIN PIN Signal 2.3.16 USB connector 1~2 (FUSB1~2) Signal Signal Data 0- Data 1 Data 0+ Data 1 FUSB1 FUSB2 16 EMX-PNVB Quick Installation Guide...
Page 17
EMX-PNVB Quick Installation Guide 2.3.17 Sony/Philips Digital Interface (JSPDIF1) Signal 2.3.18 System Fan connector (SFAN1) Signal Ground +12V Control EMX-PNVB Quick Installation Guide 17...
Page 18
DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 IO WRITE IO READ HD READY HDACK 0 IDE IRQ IOCS16 ADDR 1 ADDR 0 ADDR 2 HARD DISK HARD DISK SELECTO SELECT 1* IDE ACTIVE 18 EMX-PNVB Quick Installation Guide...
Page 19
EMX-PNVB Quick Installation Guide 2.3.20 Keyboard & Mouse connector (JKB_MS) Signal Signal EMSDT EMSCL MSDT MSCK EKBDT EKBCK KBDT KBCK KB_5V 2.3.21 System Management Bus controller (JSM_BUS) Signal SMB_CLK_S SMB_DATA_S EMX-PNVB Quick Installation Guide 19...
Page 20
EMX-PNVB Quick Installation Guide 2.3.22 ATX Power connector (ATXPWR1) Signal PIN PIN Signal +3.3V +3.3V +3.3V -12V PS-ON PWR OK +5VSB +12V 20 EMX-PNVB Quick Installation Guide...
