Summary of Contents for Avalue Technology EMX-H110P
- Page 1 EMX-H110P Intel® Core™ Processors with Intel® H110 Mini ITX Motherboard User’s Manual Ed – 03 January 2017 Part No. E2047MX1102R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
-
Page 3: Technical Support
Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. -
Page 4: Product Warranty
A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 EMX-H110P User’s Manual... -
Page 5: Table Of Contents
2.3.19 CPU fan connector (CPUFAN1) ....................28 2.3.20 System fan connector (SYSFAN1) .................... 29 2.3.21 ATX 12V power connector (ATX12V1) ..................29 2.3.22 Gigabit LAN (RJ-45) connector (LAN1/2) .................. 30 3.BIOS Setup ........................31 Introduction ......................32 EMX-H110P User’s Manual... - Page 6 3.6.2.14 USB Configuration ......................... 54 3.6.3 Chipset............................55 3.6.3.1 System Agent (SA) Configuration ..................55 3.6.3.1.1 Graphics Configuration ......................56 3.6.3.1.2 DMI/OPI Configuration ......................57 3.6.3.1.3 PEG Port Configuration ......................58 3.6.3.1.4 Memory Configuration ......................59 6 EMX-H110P User’s Manual...
- Page 7 Install Chipset Driver ....................69 Install VGA Driver ....................70 Install ME Driver ...................... 72 Install Audio Driver (For Realtek ALC892 HD Audio) ..........73 Install LAN Driver ....................74 Install RST Driver ....................75 5. Mechanical Drawing ....................77 EMX-H110P User’s Manual...
-
Page 8: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EMX-H110P motherboard 2 x SATA cable 1 x I/O Shield ... -
Page 9: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment April 2016 Avalue Initial Release October 2016 Avalue Update BIOS Setup January 2017 Avalue Update BIOS Setup EMX-H110P User’s Manual... -
Page 10: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up EMX-H110P or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 11: System Specifications
- 3 SATAIII Internal I/O 1 x Half Size Mini PCI-e Connector COM 1 Pin9 power selection: - 1 x 2 x 3 pin, pitch 2.00mm connector for COM 1 support RS232 with Pin 9, +5V/+12V/RI COM 2: EMX-H110P User’s Manual 11... - Page 12 COM1 support RS-232 DB9 connector, Pin 9 with / +5V/+12V/RI Supported 1 x Line-out,1 x Mic-In,1 x Line-in 1 x PS/2 Keyboard or PS/2 Mouse with Dual deck USB 2.0 Mechanical & Environmental Power +12V / +5V / 5VSB /+3.3V/ -12V Requirement 12 EMX-H110P User’s Manual...
- Page 13 Humidity Size (L x W) 6.7" x 6.7" (170mm x 170mm) Weight 0.40 kg Note: 1. The Windows 7 & Windows 8 must be Setup USB 3.0 driver. 2. Specifications are subject to change without notice. EMX-H110P User’s Manual 13...
-
Page 14: Architecture Overview-Block Diagram
EMX-H110P User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EMX-H110P. 14 EMX-H110P User’s Manual... -
Page 15: Hardware Configuration
User’s Manual 2. Hardware Configuration EMX-H110P User’s Manual 15... -
Page 16: Product Overview
EMX-H110P User’s Manual 2.1 Product Overview 16 EMX-H110P User’s Manual... -
Page 17: Jumper And Connector List
5 x 2 header, pitch 2.54 mm SODIMM1/2 260-pin DDR4 DIMM socket AUDIO1 Line out, Mic in, Line out JAUDIO2 Front Audio connector 5 x 2 header, pitch 2.54 mm JBKL1 LCD Inverter connector 5 x 1 wafer, pitch 2.00mm EMX-H110P User’s Manual 17... - Page 18 Half size Mini-PCI-e connector 2 10 x 2 wafer, pitch 4.20mm ATXPWR1 ATX Power connector ATX12V1 ATX 12V power connector 2 x 2 wafer, pitch 4.20mm Serial ATA III connector 1~4 SATA1~4 HDMI connector HDMI1 DP connector VGA1 VGA connector 18 EMX-H110P User’s Manual...
-
Page 19: Setting Jumpers & Connectors
2.3 Setting Jumpers & Connectors 2.3.1 Serial port 1 pin9 signal select (JRI1) Ring* +12V * Default Note: Max Current 1A. 2.3.2 Serial port 2 pin9 signal select (JRI2) Ring* +12V * Default Note: Max Current 1A. EMX-H110P User’s Manual 19... -
Page 20: At/Atx Power Mode Select (Jatatx1)
EMX-H110P User’s Manual 2.3.3 AT/ATX Power Mode Select (JATATX1) ATX* * Default 2.3.4 Clear CMOS (JCMOS1) Protect* Clear CMOS * Default 20 EMX-H110P User’s Manual... -
Page 21: Lcd Inverter Connector (Jbkl1)
LCD Inverter connector (JBKL1) Signal Max current +12V BKLEN VBRIGHT Note: Mapping connector PHR5. 2.3.6 Serial port 2/3/4/5/6 connector (JCOM2/3/4/5/6) JCOM2 JCOM3 JCOM4 JCOM5 JCOM6 Signal PIN PIN Signal NRXD NDCD# NDTR# NTXD NDSR# NCTS# NRTS# NRI# EMX-H110P User’s Manual 21... -
Page 22: Com2 Rs485/422 Connector (Jcom2_422_485)
Signal PIN PIN Signal 422TX- 422RX- 422TX+ 422RX+ RS-485 Signal PIN PIN Signal Note: DATA- Max Current 1A. DATA+ 2.3.8 General purpose I/O connector (JDIO1) Signal PIN PIN Signal SMB_CLK_9555 10 SMB_DATA_9555 Note: Max Current 1A. 22 EMX-H110P User’s Manual... -
Page 23: Atx Power Connector (Atxpwr1)
User’s Manual 2.3.9 ATX Power connector (ATXPWR1) Signal Signal +3.3V +3.3V +3.3V -12V PSON# PG_ATX +V5SB_DP +12V 2.3.10 USB 2.0 connector 1 (JUSB1) Signal Signal USB_R_DP6 USB_R_DP5 USB_R_DN6 USB_R_DN5 EMX-H110P User’s Manual 23... -
Page 24: Battery Connector (Jbat1)
EMX-H110P User’s Manual 2.3.11 Battery connector (JBAT1) Signal RTC_VBAT_1 2.3.12 LPC connector (JLPC1) Signal PIN PIN Signal LPC_AD0 +3.3V LPC_AD1 BUF_PLT_RST# LPC_AD2 LPC_FRAME# LPC_AD3 LPC_CLK LPC_SERIRQ 24 EMX-H110P User’s Manual... -
Page 25: Lvds Connector (Jlvds1)
LVDS_DATA2_P 16 15 LVDS_DATA3_P LVDS_DATA2_N 18 17 LVDS_DATA3_N Note: Mapping connector DF13-40DS-1.25C (1.0mm). LVDS_DATA4_P 22 21 LVDS_DATA5_P LVDS_DATA4_N 24 23 LVDS_DATA5_N LVDS_DATA6_P 28 27 LVDS_DATA7_P LVDS_DATA6_N 30 29 LVDS_DATA7_N LVDS_CLK1_P LVDS_CLK2_P LVDS_ CLK1_N LVDS_ CLK2_N +12V +12V EMX-H110P User’s Manual 25... -
Page 26: Front Audio Connector (Jaudio2)
MIC2_LIN 2.3.14.1 Signal Description –Audio connector 2 (JAUDIO2) Signal Signal Description LINE2_JD AUDIO IN (LINE_RIN/LIN)sense pin MIC2_JD MIC IN (MIC_RIN/LIN) sense pin 2.3.15 SPI connector (JSPI1) Signal PIN PIN Signal +3.3V SSPI_CS0#_R SSPI_SCLK_R SSPI_SO_R SSPI_SI_R SSPI_HOLD#0 26 EMX-H110P User’s Manual... -
Page 27: Amplifier Connector (Jspk1)
2.3.16 Amplifier connector (JSPK1) Signal SPK_L+ SPK_L- SPK_R+ SPK_R- Note: Support 6W x 2 speakers. Mapping Connector PHR-4. 2.3.17 Front panel setting connector (JFP1) Signal PIN PIN Signal +HD_LED +PWR_LED -HD_LED -PWE_LED +Reset +PWR_BNT -Reset -PWR_BNT EMX-H110P User’s Manual 27... -
Page 28: Lan1& Lan 2 Active Led Connector (Jlanled1)
EMX-H110P User’s Manual 2.3.18 LAN1& LAN 2 active LED connector (JLANLED1) Signal PIN PIN Signal LAN2_ACT# LAN1_ACT# FRONT_LAN2_ACT FRONT_LAN1_ACT 2.3.19 CPU fan connector (CPUFAN1) Signal +12V CPUFANIN CPUFANOUT 28 EMX-H110P User’s Manual... -
Page 29: System Fan Connector (Sysfan1)
User’s Manual 2.3.20 System fan connector (SYSFAN1) Signal +12V SYSFANIN SYSFANOUT 2.3.21 ATX 12V power connector (ATX12V1) Signal Signal +12V +12V EMX-H110P User’s Manual 29... -
Page 30: Gigabit Lan (Rj-45) Connector (Lan1/2)
Linked Green connection Note: 1Gbps Blinking Data activity Orange This port allows Gigabit connection to a Local Area connection Network (LAN) through a network hub. Refer to the table below for the LAN port LED indications. 30 EMX-H110P User’s Manual... -
Page 31: Bios Setup
User’s Manual 3.BIOS Setup EMX-H110P User’s Manual 31... -
Page 32: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 32 EMX-H110P User’s Manual... -
Page 33: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. EMX-H110P User’s Manual 33... -
Page 34: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 34 EMX-H110P User’s Manual... -
Page 35: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. EMX-H110P User’s Manual 35... -
Page 36: System Language
Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 36 EMX-H110P User’s Manual... -
Page 37: Trusted Computing
3.6.2.1 Trusted Computing Item Options Description Enables or Disables BIOS support for security Disable, Security Device Support device. O.S. will not show Security Device. TCG EFI Enable[Default] protocol and INT1Ainterface will not be available. 3.6.2.2 APCI Settings EMX-H110P User’s Manual 37... - Page 38 Enable/Disable system waked up by Disabled Wake Up by Ring Ring signal from standby states Enabled[Default], (S3~S5). Enable/Disable USB Power delivery in Disabled USB Power state in S3-S5 S3 (Sleep), S4 (Hibernate) and S5 (Soft Enabled[Default], Off) States. 38 EMX-H110P User’s Manual...
-
Page 39: Pch-Fw Configuration
Selects TPM device: dTPM – The discrete TPM chip. PTT – Intel Platform Trust Technology. Warning! If dTPM Chip[Default], TPM Device Selection PTT/dTPM was disabled, All data saved on it will be lost. 3.6.2.3.1 Firmware Update Configuration EMX-H110P User’s Manual 39... -
Page 40: Super Io Configuration
Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). 40 EMX-H110P User’s Manual... -
Page 41: Serial Port 1 Configuration
User’s Manual 3.6.2.4.1 Serial Port 1 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], Change Settings Auto[Default] Select an optimal setting for Super IO Device. 3.6.2.4.2 Serial Port 2 Configuration EMX-H110P User’s Manual 41... -
Page 42: Serial Port 3 Configuration
Set COM Port as RS232, RS422 or RS485 mode. RS485 3.6.2.4.3 Serial Port 3 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], Select an optimal setting for super IO Change Settings Auto[Default] Device. 42 EMX-H110P User’s Manual... -
Page 43: Serial Port 4 Configuration
User’s Manual 3.6.2.4.4 Serial Port 4 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], Change Settings Auto[Default] Select an optimal setting for super IO Device. 3.6.2.4.5 Serial Port 5 Configuration EMX-H110P User’s Manual 43... -
Page 44: Serial Port 6 Configuration
Select an optimal setting for super IO Device. 3.6.2.4.6 Serial Port 6 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], Change Settings Auto[Default] Select an optimal setting for super IO Device. 44 EMX-H110P User’s Manual... -
Page 45: Nct6106D H/W Monitor
SmartFan IV Smart Fan), SmartFan IV™ Mode. CPU Fan Manual Duty 0-255[Default] CPU Fan manual output duty: 0 to 255. Manual Smart Fan Mode Selection: Manual Mode (No SYSFAN1 Mode SmartFan IV[Default], Smart Fan), SmartFan IV™ Mode. EMX-H110P User’s Manual 45... -
Page 46: S5 Rtc Wake Settings
Disabled[Default], Fixed Time, system will wake on the hr::min::sec Wake system from S5 Fixed Time specified. Select Dynamic Time, System will wake on the Dynamic Time current time + Increase minute(s). 3.6.2.7 Serial Port Console Redirection 46 EMX-H110P User’s Manual... -
Page 47: Legacy Console Redirection Settings
Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled 3.6.2.7.1 Legacy Console Redirection Settings Item Option Description Select a COM port to display redirection of Legacy Serial Redirection Port COM1[Default] Legacy OS and Legacy OPROM Messages. EMX-H110P User’s Manual 47... -
Page 48: Cpu Configuration
EMX-H110P User’s Manual 3.6.2.8 CPU Configuration Use the CPU configuration menu to view detailed CPU specification and configure the CPU. Item Options Description All[Default], Number of cores to enable in each processor Active Processor Cores package. 48 EMX-H110P User’s Manual... -
Page 49: Intel Txt Configuration
Allows more than two frequency ranges to be Intel® SpeedStep™ Enabled[Default] supported. Disabled Turbo Mode Turbo Mode. Enabled[Default] Disabled CPU C states Enable or disable CPU C states. Enabled[Default] C0/C1 Package C State limit Package C State limit. AUTO[Default] 3.6.2.9 Intel TXT Configuration EMX-H110P User’s Manual 49... -
Page 50: Sata Configuration
Determines how SATA controller(s) operate. RAID Disabled, SATA Port Enable or Disable SATA Port. Enabled[Default] Hard Disk Drive[Default] Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. 50 EMX-H110P User’s Manual... -
Page 51: Software Feature Mask Configuration
User’s Manual 3.6.2.10.1 Software Feature Mask Configuration Item Option Description Disabled If enabled, indicates that the HDD password unlock HDD Unlock Enabled[Default], in the OS is enabled. 3.6.2.11 AMI Graphic Output Protocol Policy EMX-H110P User’s Manual 51... -
Page 52: Network Stack Configuration
EMX-H110P User’s Manual 3.6.2.12 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 3.6.2.13 CSM Configuration BIOS Default: 52 EMX-H110P User’s Manual... - Page 53 Legacy Do not launch Controls the execution of UEFI and Legacy Storage UEFI Storage OpROM. Legacy[Default] Do not launch Determines OpROM execution policy for devices Other PCI devices UEFI other than Network, Storage, or Video. Legacy[Default] EMX-H110P User’s Manual 53...
-
Page 54: Usb Configuration
Mass storage device emulation type. ‘AUTO’ Auto[Default] Floppy enumerates devices according to their media format. Optical drives are emulated as ‘CDROM’, Mass Storage Devices Forced FDD Hard Disk drives with no media will be emulated according CD-ROM to a drive type. 54 EMX-H110P User’s Manual... -
Page 55: Chipset
User’s Manual 3.6.3 Chipset 3.6.3.1 System Agent (SA) Configuration Item Option Description Enabled[Default] VT-d VT-d capability. Disabled EMX-H110P User’s Manual 55... -
Page 56: Graphics Configuration
Primary Display IGFX device should be Primary Display Or select SG for Switchable Gfx. Auto [Default] Keep IGFX enabled based on the setup Internal Graphics Disabled options. Enabled No LVDS[Default] Active LFP Configuring LFP usage. eDP Port-A 56 EMX-H110P User’s Manual... -
Page 57: Dmi/Opi Configuration
1366x768 18/1 1024x600 18/1 1280x800 18/1 1920x1200 24/2 Port1-EDP to LVDS (Chrotel 7511) CH7511 EDID Panel Option 1920x1080 18/2 Panel EDID Option. 1280x1024 24/2 1440x900 18/2 1600x1200 24/2 1366x768 24/1 1920x1080 24/2 1680x1050 24/2 3.6.3.1.2 DMI/OPI Configuration EMX-H110P User’s Manual 57... -
Page 58: Peg Port Configuration
Gen3 Disabled[Default] Detect Non-Compliance PCI Express Device Detect Non-Compliance Device Enabled in PEG. Enabled: PCIe ASPM will be programmed Disabled[Default] Program PCIe ASPM after OpROM after OpROM. Disabled: PCIe ASPM will be Enabled programmed before OpROM. 58 EMX-H110P User’s Manual... -
Page 59: Memory Configuration
User’s Manual 3.6.3.1.4 Memory Configuration Item Option Description Auto[Default] 1067/1200/1333/1400/1600 Maximum Memory Maximum Memory Frequency Selections in /1800/1867/2000/2133/2200 Frequency Mhz. /2400/2600/2667/2800/2933 /3000/3200 3.6.3.2 PCH-IO Configuration EMX-H110P User’s Manual 59... -
Page 60: Pci Express Configuration
Option Description Disabled Enable or disable OnBoard PCH LAN PHY LAN PHY Controller Enabled[Default] Controller. Quiet Serial IRQ Mode Configure Serial IRQ Mode. Continuous[Default] 3.6.3.2.1 PCI Express Configuration 3.6.3.2.1.1 Intel I211 LAN Chip (PCI-E Port 8) 60 EMX-H110P User’s Manual... - Page 61 DISABLE – Disables ASPM. L0sL1 Auto Auto[Default] PCIe Speed Gen1 Select PCI Express port speed. Gen2 Detect Non-Compliance PCI Express Disabled[Default] Detect Non-Compliance Device Device. If enable, it will take more time at Enabled, POST time. EMX-H110P User’s Manual 61...
- Page 62 DISABLE – Disables ASPM. L0sL1 Auto Auto[Default] PCIe Speed Gen1 Select PCI Express port speed. Gen2 Detect Non-Compliance PCI Express Enabled, Detect Non-Compliance Device Device. If enable, it will take more time at Disabled[Default] POST time. 62 EMX-H110P User’s Manual...
-
Page 63: Hd Audio Configuration
HAD will be unconditionally disabled Enabled = HAD will HD Audio Enabled be unconditionally enabled Auto = HAD will be enabled if Auto[Default], present, disabled otherwise. 20dB 26dB[Default] Amplifier Gain Select Amplifier Gain (dB). 32dB 36dB 3.6.4 Security EMX-H110P User’s Manual 63... -
Page 64: Secure Boot Menu
Secure Boot User mode with enrolled Platform Key(PK) 2.CSM Enabled function is disabled. Secure Boot mode selector. ‘Custom’ Mode enables Standard Secure Boot Mode users to change Image Execution policy and manage Custom[Default] Secure Boot Keys. 64 EMX-H110P User’s Manual... -
Page 65: Key Management
Install Factory default Secure Boot Keys Provision Factory Default Keys Disabled[Default] when System is in Setup Mode. 3.6.5 Boot Item Option Description Number of seconds to wait for setup activation Setup Prompt Timeout 1~ 65535 key. 65535(0xFFFF) means indefinite waiting. EMX-H110P User’s Manual 65... -
Page 66: Save And Exit
Has no effect for BBS boot options. Default[Default] Controls the placement of newly detected UEFI New Boot Option Policy Place First boot options. Place Last Boot Option #1 Set the system boot order. 3.6.6 Save and exit 66 EMX-H110P User’s Manual... -
Page 67: Save Changes And Reset
This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. EMX-H110P User’s Manual 67... -
Page 68: Drivers Installation
EMX-H110P User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 68 EMX-H110P User’s Manual... -
Page 69: Install Chipset Driver
Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step1. Click Next. Step 4. Complete setup. Step 2. Click Accept. EMX-H110P User’s Manual 69... -
Page 70: Install Vga Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Step 5. Click Next. Click Yes to accept license agreement. 70 EMX-H110P User’s Manual... - Page 71 User’s Manual Step 6. Click Finish to complete setup. EMX-H110P User’s Manual 71...
-
Page 72: Install Me Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next Step 4. Click Finish to complete the setup Step 1. Click Next to continue setup. Step 2. Click Next. 72 EMX-H110P User’s Manual... -
Page 73: Install Audio Driver (For Realtek Alc892 Hd Audio)
Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step1. Click Next to Install. Step 2. Select Finish to complete Installation. EMX-H110P User’s Manual 73... -
Page 74: Install Lan Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Install. Step 2. Click Next. Step 5. Click Finish to complete setup. 74 EMX-H110P User’s Manual... -
Page 75: Install Rst Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Next. EMX-H110P User’s Manual 75... - Page 76 EMX-H110P User’s Manual Step 6. Click Finish to complete setup. 76 EMX-H110P User’s Manual...
-
Page 77: Mechanical Drawing
User’s Manual 5. Mechanical Drawing EMX-H110P User’s Manual 77... - Page 78 EMX-H110P User’s Manual Unit: mm 78 EMX-H110P User’s Manual...
- Page 79 User’s Manual Unit: mm EMX-H110P User’s Manual 79...
