- Page 1 EMX-PNVB Intel® Atom™D525 Processor with ICH8M Chipset Mini ITX Motherboard User’s Manual Ed – 15 October 2013 Part No. E2047PNVB00R...
-
Page 2: Technical Support
Avalue has come to be known. Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To ensure you get the full benefit of our services, please follow the instructions below carefully. -
Page 3: Table Of Contents
2.4.18 System Fan connector (SFAN1) ............26 2.4.3 IDE connector (IDE1) ................27 2.4.20 Keyboard & Mouse connector (JKB_MS) ..........28 2.4.21 System Management Bus controller (JSM_BUS) ........28 2.4.22 ATX Power connector (ATXPWR1) ............29 EMX-PNVB User’s Manual 3... - Page 4 3.6.6.2 Save Changes and Reset .............. 52 3.6.6.3 Discard Changes and Reset ............52 3.6.6.4 Save Changes................52 3.6.6.5 Discard Changes ................52 4. Drivers Installation....................... 53 Install Chipset Driver ..................54 Install VGA Driver ..................55 4 EMX-PNVB User’s Manual...
-
Page 5: Emx-Pnvb User's Manual
EMX-PNVB User’s Manual Install LAN Driver (For Realtek 8111E Gigabit Ethernet) ......57 Install Audio Driver (For Realtek ALC661 HD Audio) ........58 5. Mechanical Drawing ....................59 EMX-PNVB User’s Manual 5... -
Page 6: Getting Started
Driver/Utility CD X 1 Serial ATA Signal Cable X 1 COM Port X 1 Screw X 2 Motherboard X 1 Front Audio cable X 1 IO Shield X 1 6 EMX-PNVB User’s Manual... -
Page 7: Document Amendment History
EMX-PNVB User’s Manual 1.3 Document Amendment History Revision Date Comment October 2013 Avalue Initial Release EMX-PNVB User’s Manual 7... -
Page 8: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up EMX-PNVB series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 9: Specifications
1 x 2 x 5 pin, pitch 2.54mm connector for front Audio 1 x 2 x 22 pin, pitch 2.00mm connector for IDE 5 x 2 x 5 pin, pitch 2.00mm connector for COM port EMX-PNVB User’s Manual 9... - Page 10 ACPI 3.0 Compliant Operating Temp. 0°C ~60°C Storage Temp. -40°C ~75°C Operating 0%~90% relative humidity, non-condensing Humidity Size (L x W) 6.7" x 6.7" (170mm x 170mm) Weight 0.40 kg 10 EMX-PNVB User’s Manual...
-
Page 11: Architecture Overview-Block Diagram
EMX-PNVB User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EMX-PNVB. EMX-PNVB User’s Manual 11... -
Page 12: Hardware Configuration
EMX-PNVB User’s Manual 2. Hardware Configuration 12 EMX-PNVB User’s Manual... -
Page 13: Product Overview
EMX-PNVB User’s Manual 2.1 Product Overview EMX-PNVB User’s Manual 13... -
Page 14: Installation Procedure
6. Enter the BIOS setup by pressing the delete key during boot up. Use the "Save & Exit \ Restore Defaults" feature. 7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before connecting the display cable and turning on the power. 14 EMX-PNVB User’s Manual... -
Page 15: Jumper And Connector List
JC11/21/31/41/51/61 PIN 9 selector JBAT1 Clear CMOS 1 x 3 header, pitch2.54 mm JS1~2 Jumper for MPCIE & MSATA selection 2 x 3 header, pitch 2.54 mm Jumper for MPCIE PWR selection 1 x 3 header, pitch 2.54 mm EMX-PNVB User’s Manual 15... - Page 16 1 x 3 header, pitch 2.54 mm Jumper for Serial port 1~6 pin9 power 1 x 3 header, pitch 2.54 mm JC11/21/31/41/51/61 selection JKB_MS Keyboard & Mouse connector 2 x 5 header, pitch 2.54 mm AUDIO1 Line-Out & Mic-In connector 16 EMX-PNVB User’s Manual...
-
Page 17: Setting Jumpers & Connectors
EMX-PNVB User’s Manual 2.4 Setting Jumpers & Connectors 2.4.1 Clear CMOS (JBAT1) Normal* Clear CMOS Define Normal * Default Clear CMOS 2.4.2 Keyboard power select jumper (JKB1) Disabled* Enabled Define * Default Disabled Enabled EMX-PNVB User’s Manual 17... -
Page 18: Jumper For Com2 Or Ir Selection (Jir1~2)
EMX-PNVB User’s Manual 2.4.3 Jumper for COM2 or IR selection (JIR1~2) COM2* JIR2 JIR1 Define COM2 Note: IR is not functional. * Default 2.4.4 Jumper for LVDS PWR selection (JP1) 3.3V* Define Max current 3.3V * Default 18 EMX-PNVB User’s Manual... -
Page 19: Jumper For Mpcie Selection (Js1~2)
EMX-PNVB User’s Manual 2.4.5 Jumper for MPCIE selection (JS1~2) M-SATA* MINIPCIE Define * Default M-SATA MINIPCIE 2.4.6 Jumper for MPCIE PWR selection (JS3) 3.3V* Define Max current 3.3V * Default EMX-PNVB User’s Manual 19... -
Page 20: Serial Port 1~6 Or Ri, Use Jc11/21/31/41/51/61 Pin 9 Selector
JC32 JC52 JC62 USE JC11_JC61 JC12 PIN Option Define CLOSE OPEN USE JC11_JC61 * Default 2.4.8 Jumper for Serial port 1~6 pin9 power selection (JC11/21/31/41/51/61) JC21 JC31 JC41 +12V JC51 JC61 JC11 Define Max current +12V 20 EMX-PNVB User’s Manual... -
Page 21: General Purpose I/O (Jgpio1)
General Purpose I/O (JGPIO1) Signal PIN PIN Signal GPIO GPIO GPIO GPIO GPIO GPIO GPIO GPIO +12V 2.4.10 Front Panel Switches (FPANEL1) Signal PIN PIN Signal 5VSB +HD_LED +P_LED -HD_LED -P_LED PS_ON +SPEAK -PS_ON RESET -RESET -SPEAK +SLPLED -SLPLED EMX-PNVB User’s Manual 21... -
Page 22: Lvds Connector (Lvds1)
EMX-PNVB User’s Manual 2.4.11 LVDS connector (LVDS1) Signal PIN PIN Signal LVDS_VCON Note: LVDS_DDCPCLK 32 LVDS_DDCPDATA Mapping connector DF13-40DS-1.25C (1.0mm). LVDS0_CLKP LVDS0_CLKN LVDS0_P2 LVDS0_N2 LVDS0_P1 LVDS0_N1 LVDS0_P0 LVDS0_N0 VDDSAFE VDDSAFE VDDSAFE VDDSAFE 22 EMX-PNVB User’s Manual... -
Page 23: Vga Connector (Jvga2)
EMX-PNVB User’s Manual 2.4.12 VGA connector (JVGA2) Signal PIN PIN Signal DDC_CLK DDC_DATA VSYNC HSYNC BLUE GREEN Note: I t can be used either D-SUB connector or Pin Header 2.4.13 Inverter connector (INCN1) Signal Max current BLEN EMX-PNVB User’s Manual 23... -
Page 24: Front Panel Audio Connection Header (F_Audio)
EMX-PNVB User’s Manual 2.4.14 Front Panel Audio Connection Header (F_AUDIO) Signal Signal AUD_RET_L FRONT_OUT_L AUD_RET_R FRONT_OUT_R VREF_OUT FRONT_MIC Note: Please use the attached audio cable for front audio daughter board. 24 EMX-PNVB User’s Manual... -
Page 25: Serial Port 2~6 Connector (Com2~6)
EMX-PNVB User’s Manual 2.4.15 Serial port 2~6 connector (COM2~6) COM2 COM3 COM4 COM5 COM6 Signal PIN PIN Signal 2.4.16 USB connector 1~2 (FUSB1~2) Signal Signal Data 0- Data 1 Data 0+ Data 1 FUSB1 FUSB2 EMX-PNVB User’s Manual 25... -
Page 26: Sony/Philips Digital Interface (Jspdif1)
EMX-PNVB User’s Manual 2.4.17 Sony/Philips Digital Interface (JSPDIF1) Signal 2.4.18 System Fan connector (SFAN1) Signal Ground +12V Control 26 EMX-PNVB User’s Manual... -
Page 27: Ide Connector (Ide1)
DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 IO WRITE IO READ HD READY HDACK 0 IDE IRQ IOCS16 ADDR 1 ADDR 0 ADDR 2 HARD DISK HARD DISK SELECTO SELECT 1* IDE ACTIVE EMX-PNVB User’s Manual 27... -
Page 28: Keyboard & Mouse Connector (Jkb_Ms)
EMX-PNVB User’s Manual 2.4.20 Keyboard & Mouse connector (JKB_MS) Signal Signal EMSDT EMSCL MSDT MSCK EKBDT EKBCK KBDT KBCK KB_5V 2.4.21 System Management Bus controller (JSM_BUS) Signal SMB_CLK_S SMB_DATA_S 28 EMX-PNVB User’s Manual... -
Page 29: Atx Power Connector (Atxpwr1)
EMX-PNVB User’s Manual 2.4.22 ATX Power connector (ATXPWR1) Signal PIN PIN Signal +3.3V +3.3V +3.3V -12V PS-ON PWR OK +5VSB +12V EMX-PNVB User’s Manual 29... -
Page 30: Bios Setup
EMX-PNVB User’s Manual 3.BIOS Setup 30 EMX-PNVB User’s Manual... -
Page 31: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press DEL to enter setup, F11 to popup menu EMX-PNVB User’s Manual 31... -
Page 32: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. 32 EMX-PNVB User’s Manual... -
Page 33: Getting Help
AMI and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. EMX-PNVB User’s Manual 33... -
Page 34: Bios Setup
Note: BIOS setup screens shown in this chapter are for reference only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 34 EMX-PNVB User’s Manual... -
Page 35: Advanced Bios Settings
This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 3.6.2.1 CPU Configuration Use the CPU configuration menu to view detailed CPU specification and configure the CPU. EMX-PNVB User’s Manual 35... -
Page 36: Ide Configuration
Enable or Disable C2 and above. Enabled 3.6.2.2 IDE Configuration Item Options Description Disabled Compatible Select ATA or IDE configuration. ATA Or IDE Configuration Enhanced[Default] IDE[Default] RAID Select a configuration for SATA controller. Configure SATA As AHCI 36 EMX-PNVB User’s Manual... -
Page 37: Usb Configuration
DISABLE option will keep USB Auto devices available only for EFI applications. This is a workaround for OSes without EHCI Disabled[Default] EHCI Hand-off hand-off support. The EHCI ownership change Enabled should be claimed by EHCI driver. EMX-PNVB User’s Manual 37... -
Page 38: Watchdogtimer Setting
EMX-PNVB User’s Manual 3.6.2.4 WatchDogTimer Setting Item Options Description Enabled WatchDogTimer WatchDogTimer Setting. Disabled[Default] 3.6.2.5 COM/LPT Configuration 38 EMX-PNVB User’s Manual... -
Page 39: Serial Port 1 Configuration
Serial Port 1 Configuration Item Option Description Disabled[Default] Enable or Disable Serial Port Serial Port Enabled (COM). Auto[Default] IO=3F8h; IRQ=4; IO=3F8h; IRQ=3,4,5,6,7,10,11,12; Select an optimal setting for Change Settings IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=3E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,10,11,12; EMX-PNVB User’s Manual 39... -
Page 40: Serial Port 2 Configuration
Select an optimal setting for Change Settings IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=3E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,10,11,12; Standard Serial Port Mode[Default] Change the Serial Port mode. Device Mode None use Select <High Speed> or <Normal None use mode> mode. 40 EMX-PNVB User’s Manual... -
Page 41: Serial Port 3 Configuration
Description Disabled[Default] Enable or Disable Serial Port Serial Port Enabled (COM). Auto[Default] IO=3E8h; IRQ=7; IO=3F8h; IRQ=3,4,5,6,7,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Select an optimal setting for Change Settings IO=3E8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=2E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,10,11,12; EMX-PNVB User’s Manual 41... -
Page 42: Serial Port 4 Configuration
Description Disabled[Default] Enable or Disable Serial Port Serial Port Enabled (COM). Auto[Default] IO=2E8h; IRQ=7; IO=3F8h; IRQ=3,4,5,6,7,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Select an optimal setting for Change Settings IO=3E8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=2E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,10,11,12; 42 EMX-PNVB User’s Manual... -
Page 43: Serial Port 5 Configuration
Description Disabled[Default] Enable or Disable Serial Port Serial Port Enabled (COM). Auto[Default] IO=2E0h; IRQ=10; IO=3F8h; IRQ=3,4,5,6,7,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Select an optimal setting for Change Settings IO=3E8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=2E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,10,11,12; EMX-PNVB User’s Manual 43... -
Page 44: Serial Port 6 Configuration
Description Disabled[Default] Enable or Disable Serial Port Serial Port Enabled (COM). Auto[Default] IO=2F0h; IRQ=10; IO=3F8h; IRQ=3,4,5,6,7,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Select an optimal setting for Change Settings IO=3E8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=2E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E0h; IRQ=3,4,5,6,7,10,11,12; IO=2F0h; IRQ=3,4,5,6,7,10,11,12; 44 EMX-PNVB User’s Manual... -
Page 45: Parallel Port Configuration
None use STD Printer Mode[Default] SPP Mode EPP -1.9 and SPP Mode Device Mode EPP -1.7 and SPP Mode Change the Printer Port mode. ECP Mode ECP and EPP 1.9 Mode ECP and EPP 1.7 Mode EMX-PNVB User’s Manual 45... -
Page 46: Hw Monitor
The H/W Monitor shows the operating temperature, fan speeds and system voltages. 3.6.2.7 Power Management Item Options Description Suspend Disabled Select the highest ACPI sleep state the ACPI Sleep State S1 (CPU Stop system will enter, when the SUSPEND Clock)[Default] button is pressed. 46 EMX-PNVB User’s Manual... -
Page 47: Chipset
Enable or disable System wake on alarm Wake system with Dynamic Disabled[Default] event. When enabled, System will wake on Enabled Time the current time + Increase minute(s). 3.6.3 Chipset Item Description North Bridge Host Bridge parameters. South Bridge South Bridge parameters. EMX-PNVB User’s Manual 47... -
Page 48: North Bridge
CRT+LFP[Default] 640x480 18/1[Default] 800x600 18/1 1024x768 18/1 800x400 18/1 Select LCD panel used by Internal Graphics LVDS Panel Type 1024x600 18/1 Device by selecting the appropriate setup None use item. None use None use 1280x800 18/1 48 EMX-PNVB User’s Manual... -
Page 49: South Bridge
HD Audio Controller. Enabled[Default] Disabled USB Function Enable or disable USB Function. Enabled[Default] Auto[Default] Onboard LAN1/2 Controller Enabled Onboard LAN1/2 Controller. Disabled Disabled Enable or Disable Boot Option for Legacy Network Lan Boot Rom Enabled[Default] Devices. EMX-PNVB User’s Manual 49... -
Page 50: Boot Settings
Boot settings Item Option Description Bootup Numlock State Select the keyboard NumLock state. Off[Default] Disabled[Default] Display Logo Enables or disables Quiet Boot option. Enabled 3.6.5 Security Use the Security menu to set system and user password. 50 EMX-PNVB User’s Manual... -
Page 51: Administrator Password
Administrator's password is set, then this only limits access to the BIOS setup program and is only asked for when entering the BIOS setup program. By default, no password is specified. 3.6.6 Save & Exit EMX-PNVB User’s Manual 51... -
Page 52: Restore Defaults
The setup program then exits and reboots the controller. 3.6.6.4 Save Changes Save Changes done so far to any of the setup options. 3.6.6.5 Discard Changes Discard Changes done so far to any of the setup options. 52 EMX-PNVB User’s Manual... -
Page 53: Drivers Installation
EMX-PNVB User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EMX-PNVB User’s Manual 53... -
Page 54: Install Chipset Driver
4.1 Install Chipset Driver Insert the Supporting DVD-ROM to DVD-ROM drive, click on “start” icon and it should show the index page of Avalue’s products automatically. If not, locate the folder HTML and choose the product from the targeted folder. -
Page 55: Install Vga Driver
4.2 Install VGA Driver Insert the Supporting DVD-ROM to DVD-ROM drive, click on “start” icon and it should show the index page of Avalue’s products automatically. If not, locate the folder HTML and choose the product from the targeted folder. - Page 56 EMX-PNVB User’s Manual Step 7. Select Finish to complete Installation. 56 EMX-PNVB User’s Manual...
-
Page 57: Install Lan Driver (For Realtek 8111E Gigabit Ethernet)
4.3 Install LAN Driver (For Realtek 8111E Gigabit Ethernet) Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or... -
Page 58: Install Audio Driver (For Realtek Alc661 Hd Audio)
4.4 Install Audio Driver (For Realtek ALC661 HD Audio) Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Driver_Audio\Realtek\ALC661\EMX-PNVB_Audio. -
Page 59: Mechanical Drawing
EMX-PNVB User’s Manual 5. Mechanical Drawing EMX-PNVB User’s Manual 59... -
Page 60: Emx-Pnvb User's Manual
EMX-PNVB User’s Manual 60 EMX-PNVB User’s Manual Unit: mm... - Page 61 EMX-PNVB User’s Manual Unit: mm EMX-PNVB User’s Manual 61...
