Lexmark Optra T 4069 series Service Manual page 360

4069-XXX
Asm- Part
Index Number
26-30 99A1741
26-31 99A1727
26-32 99A1728
26-33 99A1731
26-34 99A1729
26-35 99A1730
26-36 99A1789
26-37 99A1720
26-38 99A1732
26-39 99A1738
26-40 99A1722
26-41 99A1787
26-42 99A1721
26-NS 99A1734
26-NS 99A0462
26-NS 99A1715
26-NS 99A1717
26-NS 99A1788
Units Description
4 Spring, Diverter
1 Frame Asm, Right Side
4 Cam, Diverter Actuator
4 Spring, Diverter Actuator
4 Latch, Diverter Actuator
4 Arbor, Diverter Actuator
4 C-Clip
1 Bracket, Attach
4 Solenoid, Diverter
5 Deflector, Paper Exit w/Brush
4 Deflector, Paper
4 Deflector
1 Deflector, Paper Top Bin
1 Spring, Static Ground
1 Grease Packet, IBM #23
1 Roller Asm, Rear Access Door
1 Gear, Drive
1 Retainer, R-Ring
7-101
Parts Catalog
