7. Parts Catalog

How To Use This Parts Catalog

•
SIMILAR ASSEMBLIES: If two assemblies contain a majority of
identical parts, they are shown on the same list. Common parts
are shown by one index number. Parts peculiar to one or the
other of the assemblies are listed separately and identified by
description.
•
AR: (As Required) in the Units column indicates that the
quantity is not the same for all machines.
•
CC: (Color Code) in the Description column indicates the part is
identified by a color marking on the part.
•
NS: (Not Shown) in the Asm-Index column indicates that the
part is procurable but is not pictured in the illustration.
•
PP: (Parts Packet) in the Description column indicates the part
is contained in a parts packet.
