4069-XXX
Connector
J15 Integrated Paper
Tray - Paper Size Sensor
J16 Fuser
J17 MPT Pick
5-8
Service Manual
Pin No.
Signal
1
+5 V dc
2
PSIZE2
3
Ground
4
PSIZE1
5
+24 V dc
6
Ground
7
POUT
8
+5 V dc
9
Paper Low
10
+5 V dc
1
Exit Sensor
2
Thumpret
3
+5 V dc
4
Thumpleft
5
Ground
6
Therm
7
Thermgnd
8
Narmedia
1
MPT Pick
2
+24 V dc
