4069-XXX
Connector
J5 Bin Full/Near Full
Dual Sensor
J6 Jumper Connector
J6 Connector Jumper Locations
High-Capacity
Stacker Board
Upper Unit Board
Lower Unit Board
Pin No.
Signal
1
Ground
2
Ground
3
binful
4
binful
5
RVsnsr
1
Upper Unit
2
Upper/Lower Unit
3
Lower Unit
Pin 1
Pin 2
X
X
Not Used
X
Pin 3
Not Used
X
Connector Locations
