Lexmark Optra T 4069 series Service Manual page 242

4069-XXX
Connector
J18 Auto Compensator
J19 MPT Paper Out
J20 Interconnect Board
J21 Smart Cartridge
Pin No. Signal
1 +24 V dc
2 N/A
3 Ground
4 Ground
5 N/A
6 +5 V dc
1 Ground
2 POSENSE
3 +5 V dc
N/A N/A
1 Scart
2 Scart Ground
3 Ground
Connector Locations
5-9
