4069-XXX
Connector
J12 Transport Motor
J13 Autoconnect
(Options)
J14 Autoconnect
(Options)
Pin No.
Signal
1
+24 V dc
2
+24 V dc Return
3
+24 V dc Return
4
Motor3
5
Motor4
6
Dir
7
Motor1
8
+5 V dc
9
Motor2
10
Ground
11
Motor0
1
RXDIN
2
Ground
3
+5 V dc
4
Ground
5
Ground
1
RXDIN
2
Ground
3
+5 V dc
4
Ground
5
Ground
Connector Locations
5-7
