7.1.6 CONNECT TO A NETWORK?

Please refer to Section 4.4.5.
7.2

SESSIONS

7.2.1 START AN SD SESSION?

1. Connect your SD sources to 3P
2. Connect your SD monitors to 3P
3. Select New Session in the Administration Screen (see Section 5.1 and 6.3.1).
4. 3P International only: choose your local Video Standard (NTSC, NTSC-J or PAL).
LAY
5. Choose either SD 4:3 or SD 16:9 (widescreen) for Resolution.
6. Click Open Session.
7. Open I/O Configuration by clicking the little gear icon in the 3P
configure the video source type for each input (see Section 5.2 and 6.4.2).

7.2.2 START AN HD SESSION?

1. Connect your HD sources to 3P
2. Connect your HD monitors to 3P
3. Select New Session in the Administration Panel (see Section 5.1 and 6.3.1).
4. 3P International only: choose your local Video Standard (NTSC, NTSC-J or PAL).
LAY
5. Select either HD 720P or HD 1080i for Resolution.
's input connectors (see Section 4.4.1).
LAY
's output connectors (see Section 4.4.2).
LAY
's input connectors (see Section 4.4.1).
LAY
's output connectors (see Section 4.4.2).
LAY
Page 86
Desktop titlebar, and
LAY
