Export to an External Drive? ................................................................................................... 91
Improve Performance? .......................................................................................................... 92
Update My 3Play? .................................................................................................................. 92
Registration and Tech Support ................................................................................................... 92
Register 3Play? ....................................................................................................................... 92
Access Technical Support? ..................................................................................................... 93
Miscellaneous ............................................................................................................................ 93
Access Windows..................................................................................................................... 93
Return to 3Play from Windows .............................................................................................. 93
7.1

CONNECTIONS

7.1.1 CONNECT CAMERAS?

1. Connect video sources to the appropriate BNC input connectors on 3P
according to your camera's video output connection type (see Section 4.4.1).
2. Open a 3P
LAY
panel (by clicking the small 'gear' icon at upper-right in the titlebar of the 3P
3. In the Input 1-3 groups, set the Video Connection type to suit the connected sources (see
Section 4.4.3).

7.1.2 CONNECT MONITORS?

7.1.2.1 COMPUTER MONITOR
Connect an external computer monitor to a DVI port (for VGA, use a DVI->VGA adapter) on
3P s's back plate (whichever is appropriate for your monitor connection type).
LAY
7.1.2.2 DOWNSTREAM VIDEO MONITORS/DEVICES
Connected devices must be compatible with the video standard (such as NTSC or PAL) and
resolution you intend to use in the 3P
session from the Administration Screen, and access the I/O Configuration
session (see Section 6.3.1).
LAY
Page 84
's front panel,
LAY
Desktop).
LAY
