3. 3P International: Select a Video Standard and Resolution setting appropriate for your
LAY
connected sources (see Section 3.4.1).
4. Choose 1-Out as the active Output Mode for this introductory session (see Section 3.4.2).
5. Click Start Session. The 3P
Figure 11
Assuming you have correctly connected the 3P-10 control surface, the standard Desktop will be
shown.
Note: If the Dashboard (Figure 12) appears at lower-right on the Desktop, this normally indicates
that the 3P-10 control surface was not detected on launch. Exit the Desktop by clicking the [x]
Close button at upper-right, remove and reconnect the 3P-10, and open another New Session.
If a connection problem persists, please contact NewTek Tech Support for assistance. (See Section
6.4.9 for information on the Dashboard.)
Figure 12
Desktop will appear on your screen (Figure 11).
LAY
