Figure 9
Again, ideally both the cameras and the 3P
the same source as the 3P
involve frames being dropped or inserted to maintain sync, which is not as desirable.
Note: For a deeper explanation of genlocking, please see Section 6.4.2.4.

4.4.5 NETWORK CONNECTION

Connecting 3P to a local area network (LAN) may require additional steps beyond those
LAY
mentioned back when we discussed Microsoft Windows ™ activation (Section 4.2). Here is the
basic procedure involved in joining a workgroup:
1. Connect an Ethernet cable from the port on 3P
connection or router.
2. (If necessary) – close the 3P
Screen's Shutdown pane to go to the Microsoft Windows™ desktop.
3. Right-click on the My Computer icon, and select Properties.
4. Scroll down in the right hand pane of the System panel that opens to find the Computer
name, domain and workgroups settings area.
5. Click the Change Settings link at right.
6. Click the Computer Name tab of the System Properties panel that opens.
need to be genlocked. If they are not genlocked to
LAY
output, a TBC (Time Base Correction) operation is applied - this can
LAY
Desktop, and use Exit to Windows in the Administration
LAY
Page 23
's back plate to your external network
